  1. ETHLON LonWorksEthernet Adapter National Engineering Research Center for Process Automation

  2. ETHLON DIRECTLY REPLACES SLTA-10 OR SLTA CONNECTIONS Conventional Approach SIPAI Solution

  3. Product Properties • Connect LonWorks networks to TCP/IP Ethernet networks for commercial, industrial, residential and utility applications • LANLON 100% transparent data flow transfer • Capable of process at least 160 packets per seconds • 10MBaseT Ethernet interface • Static or acquired IP address • Twisted pair (TP/FT-10, TP/XF-1250 and TP/XF-78) LonWorks channel support • Virtual SLTA-10 or SLTA LonWorks network interface • LNS (NSI) or LonManager API (MIP) support • Up to 256 adapters could be connect to one PC • Local or remote configuration, monitor and control support

  4. Remotely Access LonWorks Systems Using Existing Software ETHLON is the ideal way to gain central remote access to several control systems while still using the same software your LonWorks system was designed for. By extending LonWorks access over Internet Protocol (IP), ETHLON acts as a replacement for a LonTalk Serial Adapter such as an SLTA-10 or SLTA, establishing remote access without any major software changes.

  5. office workshop Ethernet ETHLON LonWorks Seamless Enterprise Connectivity • Access to LonWorks networks from any workstation on the LAN, managing your industrial automation systems • Connecting buildings across a factory to a central SCADA workstation • Providing remote management using standard WAN remote access, monitor and maintain your production lines from everywhere • Gateways to existing legacy applications and data

  6. LonWorks ETHLON ETHLON Ethernet Control Everyday Devices Across the room or Across the World • Managing building & home automation systems from a PC across Ethernet • Connecting buildings across a campus to a central management PC • Providing remote BAS management using standard WAN remote access • Look after your home from another city with your notebook

  7. What is VSLA and Why? • VSLA -- Virtual Serial LonTalk Adapter • ETHLON is a VSLA device, redirects Ethernet as a virtual serial port, and recognized as a Serial LonTalk Adapter by LonWorks system • Advantages: • Using standard drivers of SLTA or SLTA-10 and SLTALink from Echelon which are accepted by all LonWorks users • Using universal virtual serial port driver which are widely accepted by IT world • Using all existing LonWorks software without any modify needed • Could connect up to 16 (windows95/98) or 256 (windows2000/NT) devices to ONE PC running LNS/LonManager Server

  8. HOW TO INSTALL? • Physical Installation • ETHLON can be installed in any convenient location where the LonWorks network and Ethernet network physically meet, allowing total flexibility in determining or changing the location of the workstation running LNS/LonManager Server. • Wall or desktop mount • Software Configuration • Device Server • Virtual Serial Port • Port Monitor • SLTA-10 driver and SLTALink • SLTA driver • Hardware Configuration • LNS(NSI) -- LonManager(MIP)

  9. SPECIFICATIONS • Channel Type: TP/XF-78 bus/ring topology twisted pair TP/XF-1250 bus topology twisted pair TP/FT-10 free topology twisted pair • Network Protocols: TCP, UDP, ARP, ICMP • Data Buffer Size: two independent 255-byte buffers (LAN LON) • Unit dimensions(including connectors): 128mm(L)*88mm(W)*38mm(H) • Service Interface: Service switch and LED • Indicators Power ON Ethernet Link Connection Status Service LonWorks Communication • Ethernet Interface: 10MBaseT and RJ45 connector • Temperature Operating: 0 to 55°C Non-operating: -40 to +85 ° C • Operating relative humidity: 10 to 90% • Power Supply: 6-9VDC, 200mA • Certification: CE, FCC

  10. Features would be added in the future include: • Power line channel support, available 30 Sep. • 4 Discrete input/output, available 30 Sep. • DIN routine mount support • Integrated Web Server for configuration

  11. LONEBR - - LonWorks Ethernet Backbone Router COMING SOON... New Products are under developing, available before 1st Oct.

  12. Other LonWorks Products from SIPAI

  13. LonWorks Products Overview Twisted Pair Transceiver WTPT-78 WTPT-1250 Control Module FTT/TP78 Flash / SRAM Control Module WLM-10 Core Module I/O Module Analog Input / Output Discrete Input / Output System Component Real-time Clock Network Component Router & Repeater ETHLON LonWorks Ethernet Adapter WPLA-10/20 PC LonTalk Adapter WSLA-10 Serial LonTalk Adapter Auxiliary Operator Panel Terminator Software Network Management Software Intelligent Instruments Valve Positioner Electro-Magnetism Flowmeter Magnetic floater Liquid Meter Temperature Transducer with Hand-held

  14. THANK YOU! Shanghai Institute of Process Automation Instrumentation National Engineering Research Center for Process Automation Address: 103 Caobao Road, Shanghai P.R.China Postcode: 200233 Tel: +86-21-64368180 Ext. 548 Fax: +86-21-64704009 Email: william@sipai.com http://www.sipai.com
