Presentation Transcript

  1. DSL Jameela Al-Mutairi & samia Al-Mutairi

  2. Definition DSL is (Digital subscriber line) Communication technology is designed for use on regular phone lines and provides high-speed communication, appropriate and safe, can be used to send voice, data and images. * Unit to measure the speed of data networks and shorten the b Kb / s.

  3. Benefits of DSL 1- High-speed 2- Performance 3- Constant contact 4- Ease and continuity

  4. Technical requirements After the delivery of DSL The customer should provide the following : 1- pc 2- Participation of one of DSL service provider .

  5. CONT. 3- DSL modem To browse the Inter Net smoothly . 4- (Filter) You can surf the Internet with the use of the phone the same time without jamming, can be installed on all telephone sockets.

  6. How is the installation of the modem? Reach the other side of the entrance of Ethernet Ethernet cable in your computer. 2 1 Brought the Ethernet cable (special cable modem) the entrance of your Ethernet modem

  7. Enter the filter in the cable phone jack. 3 4 Enter one of the parties at the entrance of cable dsl filter dsl modem.

  8. 5 Enter one of the parties to the telephone at the entrance of the filter on the phone

  9. Enter the two parties outside of the cable dsl filter at the entrance to the modem 6 7 Connect the modem electricity occasion

  10. Ensure the delivery of electrical cable modem 8 9 Take a modem

  11. How is the installation of filter dsl? Dsl filter and a single-Qassam A B Filter dsl dual independent

  12. 1 Enter a dsl filter in the phone jack. 2 Enter one of the parties at the entrance of cable dsl filter Enter the telephone cable in the entrance for the phone in the filter. 3

  13. Be sure to connect the modem and the telephone manner of service are not affected by Asahihpki 4

  14. Enter the phone socket in the Qassams closest to the modem Enter the independent single-filter in any of the slot openings of the Qassam 1 2

  15. Enter the cable modem entrance Balksam vacancy. Enter the telephone entrance cable filter unilateral 3 4

  16. When using another phone at home one-filters used with the phone just to avoid confusion 5

  17. Video video

  18. Rise to the definition of index of modem

  19. Companies in the service provider dsl • Fast telco • kems
