  1. 4C8 Image Compression

  2. Lossy Compression Effective bit rate = 8 bits/pixel Effective bit rate = 1 bit/pixel (approx)

  3. Transform Coding • In the last set of slides we showed that transforming the image into a difference image reduces the entropy of image. G(x,y) = I(x,y) – I(x-1,y)

  4. Transform Coding • This is because entropy is greatest when uniform Histogram of the original image Histogram of the difference image

  5. Signal Energy

  6. Lossy Transform Coding Lossless Lossy Lossless Lossless

  7. Energy Compaction with Xforms

  8. The Haar Xform LoLo Hi-Lo Lo-Hi Hi-Hi

  9. Implementation Details • When calculating the haar transform for the image the mid gray value is typical. • Colour Images are processed by treating each colour channel as separate gray scale images. • If YUV colourspace is used subsampling of the U and V channels is probable.

  10. Quantisation • After we create the image we quantise the transform coefficients. • Step size is shown by perceptual evaluation • We can assign different step sizes to the different bands. • We can use different step sizes for the different colour channels. • We will consider a uniform step size, Qstep, for each band for now.

  11. Entropy Qstep = 15

  12. Entropy Qstep = 15 • Calculating the overall entropy is trickier • Each coefficient in a band represents 4 pixel locations in the original image. • So bits/pixel = (bits/coefficient)/4 • So the entropy of the transformed and quantised lenna is

  13. Mistake in Fig. 5 of handout Red Dashed Line is the Histogram. Blue bars represent the “entropies” (ie. - p * log2(p) ) and not vice versa

  14. Multilevel Haar Xform

  15. Calculating the Entropy for Level 2 of the transform • One Level 1 coefficient represents 4 pixels • One level 2 coefficient represents 16 pixels Total Entropy = 1.70 bits/pixel Qstep = 15

  16. Multilevel Haar Xform

  17. Calculating the Entropy for Level 3 of the transform • One Level 1 coefficient represents 4 pixels • One level 2 coefficient represents 16 pixels • One level 3 coefficient represents 64 pixels Qstep = 15

  18. Calculating the Entropy for Level 3 of the transform • One Level 1 coefficient represents 4 pixels • One level 2 coefficient represents 16 pixels • One level 3 coefficient represents 64 pixels Total Entropy = 1.62 bits/pixel Qstep = 15

  19. Multilevel Haar Xform Qstep = 15

  20. Measuring Performance • Compression Efficiency - Entropy • Reconstruction Quality – Subjective Analysis Haar Transform Quantisation Quantisation

  21. Reconstruction Qstep = 15

  22. Reconstruction Qstep = 30

  23. Reconstruction Qstep = 30 Original Quantised Haar Transform + Quantisation

  24. Laplacian Pdfs

  25. GOAL – estimate a theoretical value for the entropy of one of the subbands So we can estimate x0 for the band by finding the standard deviation of the coefficient values.

  26. x1 = 0, x2 = Q/2 x1 = (k-1/2)Q, x2 = (k-1/2)Q

  27. See Handout for Missing Steps Here

  28. Measured Entropy is less than what we would expect for a laplacian pdf. This is because the actual decay of the histogram is greater than an exponential decay.

  29. Practical Entropy Coding

  30. Huffman Coding

  31. Practical Results

  32. The code is inefficient because level 0 as a probability >>0.5 (0.8 approx) Remember the ideal codelength So if pk = 0.8, then However, the minimum code length we can use for a symbol is 1 bit. Therefore, we need to find a new way of coding level 0 – use run length coding

  33. RLC

  34. RLC coding to create “events” 13 -5 1 0 0 0 0 0 0 -1 0 0 0 0 0 0 0 0 0 0 0 Define max run of zeros as 8, and we are coding runs of 1, 2, 4 and 8 zeros Here we have 4 non-zero “events” 1 x Run-of-4-Zeros event 2 x Run-of-2 zeros event 1x Run-of-8-zeros event 1 x Run-of-1-zero event

  35. Practical Results

  36. Synchronisation Say we have a source with symbols A, B and C. Say we wish to encode the message ABBCCBCABAA using the following code table The Coded message is therefore 010101111101101000 Q. What is the decoded message if the 6th bit in the stream is corrupted? Ie. We receive 010100111101101000

  37. Synchronisation • 010100111101101000 • The decoded stream is ABBACCACABA • The problem is that 1 bit error causes subsequent symbols to be decoded incorrectly as well. • The stream is said to have lost synchronisation. • A solution is to periodically insert synchronisation symbols into the stream (eg. One at the start of each row). This limits how far errors can propagate.

  38. Summary
