  1. AS-i, The Simplest Automation Networking Solution Dated: 10/30/2008

  2. Actuator Sensor interface (AS-i) is a simple wire reduction system Easily replaces point to point wiring and complements existing higher level bus systems Reduces wiring and eliminates multiple termination points Connects inputs and outputs via a single two wire flat cable Easy to install and commission What is AS-i?

  3. AS-i vs. Point-to-Point Wiring

  4. Each bit of data needs its own wire. Power is run separately (more wires). Additional I/O points require additional PLC I/O cards. Additional PLC I/O cards may require the use of a larger PLC rack or multiple racks. Point-To-Point Wiring

  5. Smaller PLC rack. Smaller enclosures. Less wire. Standardized patch cables. Potential to eliminate J-boxes. Simpler documentation. Less commissioning time. Less Material & Labor

  6. One cable for many bits of data. One master replaces many PLC I/O cards = less wiring. Quick disconnect at modules vs. point-to-point terminations. I/O modules connect easily to the bus via insulation displacement connectors (IDC). Simple Installation & Expansion

  7. Modules connect easily to the bus via insulation displacement connections (IDC). Mechanically coded flat cable - AS-i and additional power supply Insulation displacement connectors - simple & safe - protection class up to IP67, - cables reseals up to IP65 Simple Installation & Expansion mechanical coded flat cable AS-Interfaceelectro-mechanics piercing connectors

  8. Less wire means less opportunity for error, less places to look for errors. Communication errors are captured by the master. Indicating lights on modules and masters communicate system and module status. Easier Troubleshooting

  9. Reducing overall machine cost AS-i can reduce up to 50% of the overall machine cost Time = Money

  10. AS-i Installation

  11. AS-i Installation

  12. Overview of AS-i system components

  13. AS-i Components

  14. 100 meters max. length per segment. With repeaters up to 300M AS-i transmits only 4 data bits per message. Single two wire unshielded cable carries input power and communication Up to 62 node addresses per network 248 inputs and 248 outputs Auto Address replacement Topology free network Max. of up to 10ms response time AS-i Specifications

  15. Two methods to connect AS-i to your existing platform Method 1: Direct PLC connection Fits into standard card slot in a PLC rack Replaces traditional I/O cards I/O are mapped directly to I/O tables Programmed and configured through standard PLC software No 3rd party software needed Available for most PLC platforms Control Integration

  16. Two methods to connect AS-i to your existing platform Method 2: Complements current fieldbus networks Gateway becomes a single node on the fieldbus network, up to 992 I/O points per gateway Reduces the price per point for connecting sensors and actuators Available for DeviceNet, Profibus, Ethernet /IP, Modbus TCP, and CanOpen Control Integration

  17. ifm Controller-e gateway Large Integrated Display Diagnostic LEDs Connection to Fieldbus (Ethernet IP connection shown) AS-i and 24 VDC connections

  18. After selecting the platform, pick an AS-i power supply An integral and required part of an AS-i system Specialty 30 VDC power supply use to couple the master data for transmission over the AS-i cable 2.8, 4 and 8 Amp versions available Provides power to all input devices and modules on the system AS-i power supply AS-i power supply

  19. Compact New ClassicLine ProcessLine SmartLine Cabinet Airbox PCB Family of I/O modules Choosing the correct I/O module to fit your application

  20. Control Cabinet Modules • Up to 4 inputs and 4 outputs • Analog inputs/outputs available in 4-20mA or 0-10V • Solid-state outputs protected against short circuits and reverse polarity • Integrated addressing port • Inputs to be supplied either by the AS-i network or 24 VDC externally • Relay outputs versions available; rated up to 230 V • LED indication for short circuit and power • DIN rail mount • Connection via removable screw terminals, Combicons

  21. New ClassicLine Field Modules • Mounting technology does not require tools for installation • Three directions of rotation for flat cable • DIN rail mount • Up to 4 inputs and 4 outputs • Up to 2 analog (4-20mA) inputs • 1 or 2 amp rated outputs available • Digital inputs and outputs with LEDs for status indication • Integrated addressing port allows setup while connected

  22. New ClassicLine Airbox Modules • Mounting technology does not require tools for installation • Three directions of rotation for flat cable • DIN rail mount • Up to 4 inputs per Pneumatic module • Different valve types include 3/2, 5/2, 5/3 way • Digital inputs and outputs with LEDs for status indication • Integrated addressing port allows setup while connected

  23. Compact Modules • Low profile design • Up to 4 inputs and 4 outputs per module • Fully potted units holds up to harsh environments • Increase resistance to shock and vibration • High amperage outputs rated for 2 amps • Digital inputs and outputs with LEDs for status indication • Module base included

  24. ProcessLine Modules • IP69K protection rating • Up to 4 inputs and 3 outputs • Up to 4 analog (4-20mA) inputs • Quick mounting with only one screw • Full 316 Stainless Steel housing • Ecolab tested to resistance to common cleaning agents found in the food industries

  25. Benefits to Equipment builders Reduces engineering time Reduces BOM cost Easy commissioning for new machines Easy trouble shooting No additional software

  26. Benefits to End Users Reduces maintenance cost Easy troubleshooting Easy expansion of existing systems in house Training seminars offered by ifm efector

  27. Complete sensor solution provider ifm can also provide your sensing component and cable needs Proximity sensors Photoelectric Flow Cables Pressure Temperature
