  1. NCAB NETS redundancy topics - 15-Dec-2004 Jeff Custard business continuity design redundancy overview (current and future)

  2. Redundancy Starts in the closet – redundant: power supplies switch supervisor modules switch uplinks and on to Layer 3: redundant routers (MSFCs in the switches)

  3. Redundancy And extends out to BPOP and FRGP connectivity – redundant: physical connection paths commodity carriers

  4. IPT redundancy At the server level -- redundant: power supplies hard drives server functionality

  5. IPT Current redundancy for (call processing): CCM call routing SRST Future redundancy for: long distance authorization Cisco Emergency Responder

  6. Layer3 restructuring project • http://www.scd.ucar.edu/nets/projects/layer3/index.html

  7. VoIP at UCAR • http://www.scd.ucar.edu/nets/projects/voip/

  8. BPOP • http://www.scd.ucar.edu/nets/projects/bpop/

  9. FRGP • http://www.frgp.net/
