  1. JI Quick Reference Guide

  2. Lesson Objective Know the Joint Inspection Quick Reference Guide (QRG)

  3. Overview • Aircraft Characteristics • Departure Airfield • JI Deployment References • Load Plans

  4. Military Aircraft

  5. C-130 E/H/J C-130 E/H/J Hercules STATISTICS CONFIGURATIONS • C-1 slick floor • C-2 max pallets, no pax • CP-1 44 side seats, baggage pallet • Max cargo weight: 25,000 lbs • Max cargo height: 96” • Max passengers (over land): 90 • Max passengers (over water): 74 • Max cargo Pallets: 6

  6. C-130J Stretch C-130J-30 Stretch CONFIGURATIONS STATISTICS • Max cargo weight: 35,000 lbs • Max cargo height: 96” • Max passengers (over land): 138 • Max passengers (over water): 138 • Max cargo Pallets: 8 • C-1 slick floor • C-2 max pallets, no pax • CP-1 48 side seats, baggage pallet

  7. C-5 C-5 A/B Galaxy STATISTICS CONFIGURATIONS • CP-1 max pallets • CP-2 slick floor for rolling stock • CP-3 combination CP-1 & CP-2 • Max cargo weight: 150,000 lbs • Max cargo height aft loading: 112” • Max cargo height front loading: 156” • Max passengers (over land): 73 • Max passengers (over water): 73 • Max cargo Pallets: 36

  8. C-17 C-17A Globemaster III STATISTICS CONFIGURATIONS • C-1 11 pallets ADS & 54 pax • C-2 slick floor & 54 pax • C-3 18 pallets LRS no pax • CP-1 # seats based on # pallets • Max cargo weight: 90,000 lbs • Max cargo height: 142” or 156” • Max passengers (side): 54 • Max passengers (total): 102 • Max cargo pallets (ADS): 11 • Max cargo pallets (LRS): 18 • Max ramp weight: 40,000 lbs

  9. KC-10 KC-10A Extender STATISTICS CONFIGURATIONS • Code B: 10 Pax & 22 pallets • Code D: 69 Pax & 16 pallets • Max cargo weight: 80,000 lbs • Max cargo height 2-12: 96” • Max cargo pallets: 22 • Max cargo weight 2-6, 12: 6,500 • Max cargo weight 7-11: 10,000

  10. Commercial Contract Aircraft

  11. B-747 B-747 • Max cargo weight: 176,000 lbs • Capacity • Main Deck: 33 pallets • Forward Lower: 5 pallets • Aft Lower: 4 pallets • *Can be loaded through side or nose door*

  12. DC-10 DC-10 • Max cargo weight: 180,000 lbs • Capacity • Main Deck: 30pallets • Forward Lower: 5 pallets • Aft Lower: Reserved • *Cargo must be sub floored and contoured*

  13. MD-11 MD-11 • Max cargo weight: 170,000 lbs • Capacity • Main Deck: 35 pallets • Forward Lower: 6 pallets • Aft Lower: 4 pallets • *Cargo must be sub floored*

  14. DC-8 DC-8 • Max cargo weight: 82,000 lbs • Capacity • Main Deck: 18 pallets • *Cargo must be sub floored and contoured along with a 5,000 pound ballast prior to loading*

  15. Departure Airfield Operations Marshaling Yard Alert Holding Area Call Forward Area Ready Line

  16. Departure Airfield Operations • Broken down into four areas: • Unit Marshalling Area • Alert Holding Area • Call Forward Area • Ready Line / Ramp Loading Area

  17. Unit Marshalling Area • Purpose: Assembly area for vehicles equipment and supplies • Controlled by: Deploying Unit

  18. Alert Holding Area • Purpose: Final preparation of chalks and transfer of control • Controlled by: DACG

  19. Call Forward Area • Purpose: Joint inspection and holding areas • Controlled by: DACG, host installation, mobility forces

  20. Ready line/Loading Ramp Area • Purpose: Aircraft loading • Controlled by: Mobility forces

  21. Responsibilities • Call Forward Area • Deploying Unit • DACG • Mobility Force

  22. JI Deployment References

  23. Mobility TCN Construction FJRT104$G108150XX • Positions 16-17: • Split/Partial Shipment • One shipment: XX • Split Shipment: XA • Partial Shipment: AX • Position 15: • TCN Indicator • 0 indicates that the cargo is using a mobility TCN • Positions 9-10: • Reserved • For service use • Normally used for deployment echelon • Positions 2-8: • ULN/UIC code • Must be 7 digits • Use $ for shorter codes • Position 1: • Service Code • A - Army • F - Air Force • N - Navy • M - Marines • Positions 11-14: • Shipment Number • AF uses increment #

  24. Other QRG References • Center of Balance • Shoring Calculation • AMC IMT 1015 • DD Form 2133 • Zulu Time Conversion • Useful Websites • Telephone Listings • JI Kit Pubs and Forms

  25. ICODES • Integrated Computerized Deployment System • Header Information • Schematic of Aircraft • Load Information • Load Summary • Signatures

  26. DD Form 2130 Series • Manual Load Plan • Header Information • Schematic of Aircraft • Load Information • Signatures • Reverse

  27. Lesson Objective • Know the Joint Inspection Quick Reference Guide (QRG)

  28. Summary • Aircraft Characteristics • Departure Airfield • JI Deployment References • Load Plans
