    1. eDEP Presentation 3rd April 2006

    2. Contents eDEP : An overview Introduction ATC simulator overview TWR simulator overview Other functionality eDEP : SPD overview eDEP & projects Roadmap Questions

    3. eDEP : What is it? EEC (ERIS) ATM prototyping platform broad, representative, but simplified ATM functionality (AIR, FDPS, CWP) Experimentation support (prep-IPAS, analysis-STORIA, replay) light-weight (200k lines of code versus 2+ million in ACE) small reactive team Flexible & modular Stable & mature (started in 2000) High quality (well documented, regression testing suite) Technically 100% Java PC based (or Linux & Unix if need be) Modern technology & modern development tools targeted at research, advanced concept projects small experiments (HF Lab) low cost demonstrators, training

    4. ERIS Simulator Solutions

    5. eDEP : Website

    6. eDEP in the HF Lab

    7. High Level Architecture View

    8. Contents eDEP : An overview Introduction ATC simulator overview TWR simulator overview Other functionality eDEP : SPD overview Usage in 2006 Questions

    9. Traffic Generator Piloting Positions, Cockpit AIR/GRD datalink DTL (CPDLC) ADS-B, TIS-B GROUND : FDPS : FM/TP, SYSCO, FPM (MONA/PAC) Tools : MTCD, STCA, AMAN, EMAN (Proto) RDPS : IAS CWP : EATMP & ECHOES Look & Feel Multiple positions Runs on 2k BARCO screens and/or simple PCs Hybrid positions “unmanned” (automated) positions

    10. eCockpit

    11. Contents eDEP : An overview Introduction ATC simulator overview TWR simulator overview Other functionality eDEP : SPD overview eDEP & projects Questions

    12. TWR Functionality Airport Model Derived from TAAM data LFPG (Paris CGG) used as example Map data (building, taxiway, runway outlines) Logical data Aprons, gates Taxiways & Taxiway segments (“LoA” : directions, restrictions, speed limits, junctions) Runways (hold points, protected areas) Airport “sectors” (i.e. frequencies) Runway controller Taxiway controller Apron controller

    13. LFPG Map (Controller Roles/Sectors)

    14. TWR Functionality Aircraft simulation Push-back Taxiing (& intelligent pilot behaviour) Calculate Shortest legal route to RWY Queuing behaviour (no overtaking) pilots maintain separation (not the controller) “Priority to the right” Take-off Hold at runway perimeter Line-up Accelerate & Take-off Landing Normal or fast runway exits Vehicle simulation

    15. TWR Functionality TWR FPDS FM/TP : GRD trajectory calculation – shortest legal route GRD Order processing (change RWY, GATE, SID, Taxiway) Co-ordination between TWR positions Flight Path Monitoring SNET : Runway Incursion Monitoring (RIMCAS) TWR RDPS TWR CWP DSI Look & Feel Arrival / Departure traffic lists Trajectory editor / elastic vector TWR Unmanned CWP Automated responses TWR standalone or TWR+ATC (APP/ACC)

    17. Contents eDEP : An overview Introduction ATC simulator overview TWR simulator overview Other functionality eDEP : SPD overview eDEP & projects Questions

    18. Others Data import IPAS, TAAM, CFMU ESCAPE Integration Transparently replace eDEP components with ESCAPE equivalent (FM/TP, TDM, RDPS) Data recording for analysis On-line data recording Fed into STORIA (EEC analysis / visualisation tool) Data recording for replay Replay CWP positions Synchronised with recorded AudioLAN R/T Traffic editor Tool Scripting Engine (inject R/T, controller orders, pilot orders)

    19. eDEP ATC Clients EVP AMAN Demonstrator DMAN DLR Integration EMAN Concept demonstration SPD (Sector Package 1 Demonstrator) CORA AVT ADS-B & TIS-B Demonstrations FARADS/RADES (TCAS RA Experiments) Innovation Business Area (long term R&D) INSTILUX – Radar Training (CBT Package)

    20. Contents eDEP : An overview Introduction ATC simulator overview TWR simulator overview Other functionality eDEP : SPD overview eDEP & projects Questions

    21. SSP Sector Package 1 Demonstrator SSP Demonstrator for “Sector Package 1” Could become C-ATM prototype demonstrator Integrating existing eDEP functionality, with ECHOES (G2G) compliance, into a coherent concept demonstrator MTCD, MONA (using ADS-B data), SYSCO, STCA DTL, ADS-B, TIS-B, ASAS 2D TED SPD relies 90-95% on eDEP core software, with only 5-10% ECHOES “specific” Therefore, this core software is re-used by EHQ for FASTI Demonstrator

    23. eDEP Modularity

    24. Contents eDEP : An overview Introduction ATC simulator overview TWR simulator overview Other functionality eDEP : SPD overview eDEP & projects Questions

    25. What Roles has eDEP Fulfilled? HMI prototypes & HF Studies Functional prototypes Concept demonstrators Airport/TMA/En-Route studies Training / CBT Packages Small scale simulation (1-2 sectors)

    26. HMI/HF Studies CORA2 (2003) Fixed traffic scenarios pre-engineered conflict situations Controller presented with conflict resolutions 3 different HMI / HF approaches: User centric Collaborative automated

    27. Functional Prototypes

    28. Concept Demonstrator

    29. En-Route/TMA/Airport Functionality APT A-SMGCS Level 1-2 Demonstrator Level 3-4 Demonstrator DMAN DLR DMAN integration

    30. Training/CBT Use EVP AMAN as example

    31. Small Scale Simulation TCAS RA Downlink simulations (RADE / FARADS) October – Nov 05 (8 week simulation) 3 sectors (1 measured, 2 feed) Connection to TCAS Box Data recording for replay (with R/T) Q1 2006 : Approach simulation CORA simulation (2003) 5 Controller Working positions

    32. Product Roadmap EEC ERIS eDEP Spin-offs Candidate (amongst others) for the ESCAPE HMI replacement Test Tool for ESCAPE eDEP ATC Prototyping platform : maintenance phase eDEP TWR prototyping platform : small developments EEC Clients DLR DMAN Integration (TWR) SPD Prototyping for C-ATM Episode 3 MSP (June onwards ) Complexity Management (June onwards) Advanced TWR HMI Demonstrator Other EHQ FASTI (MTCD, SYSCO, MONA) Demonstrator NATS spin-off work

    33. Questions?
