  1. XML

  2. What is XML? • "eXtensible Markup Language" • New development in web creation • Overcomes limitations of HTML • small number of tags • limited features • several versions of the language • XML allows you to create your own tags • Separates content from presentation

  3. SGML, HTML and XML • SGML • Standard Generalised Markup Language • ISO standard since 1986 • complex but widely used "meta-language" • HTML • created using SGML for web delivery • XML • a simplified version of SGML for users to create their own 'markup language' • not just a new version of HTML, a different concept

  4. Creating XML Processing instruction • <?xml version="1.0"?> • <library> • <book> • <author> • <firstname>Bill</firstname> • <lastname>Bryson</lastname> • </author> • <booktitle>Notes From a Small Island</booktitle> • <publisher>Transworld</publisher> • </book> • </library> Tags - "elements"

  5. More XML Markup • Empty elements <curtainup/> • Attributes <book section="short loan"> • Special characters &lt; &#8478; • Comments<!--some text--> • Data sections • <![CDATA[ • *a = &b; • c = (d<=3); • ]]>

  6. Using Style with XML • Cascading Style Sheets (CSS) for simple web presentation • booktitle { • margin-left: 10%; • font-weight: bold; • } • Present in multiple formats - print, audio... • XSL eXtensible Style Language • Transformations of XML • e.g. reorder elements

  7. XSL Transformations XSL commands • <H1> • <xsl:for-each select="library/book" • order-by="author/lastname"> • <xsl:value-of select="author/lastname"/> • </xsl:for-each> • </H1> XML elements HTML template for formatting

  8. Uses of XML • Creating web pages - better structure • Improved indexing and searching • www.goxml.com/ • www.w3.org/XML/ • Simple "database" functionality - organising and manipulating data "fields" within the page • Configuring/manipulating information at client - presenting information in different ways to different users • "E-business" - business to business transactions, passing of tailored information e.g. inventory, ordering etc

  9. Linking Developments • XLink • Multiple destinations for a link • Different presentations of a linked resource • replace existing page with new (as now) • embedded in existing page • display in new window • XPointer • Replaces internal anchor • Jump to any XML element within document

  10. XHTML: HTML in XML • Preparing HTML for use in XML browsers • HTML defined in XML • Must close all tags <p> </p> or <p/> • Tags in lower case • Quote attribute values src="logo.gif" • validate/correct documents www.w3.org/People/Raggett/tidy

  11. Browser Compatibility • Support for XML and CSS in common browsers: • Netscape 4 - no XML, moderate CSS • IE4 - partial XML, reasonable CSS • IE5 - good XML and CSS • XML viewers available (special browers or plug-ins) • Server can change XML to HTML before delivery

  12. XML Applications • XML is well established in some areas e.g. MathML (Mathematics Markup Language) • <expr> • <mci>x</mci> • <power/> • <mcn>2</mcn> • </expr> • <plus/> • <mcn>4</mcn> x2+4

  13. XML Applications • MathML (Mathematics Markup Language) www.w3.org/TR/REC-MathML • CML (Chemical Markup Language) www.venus.co.uk/omf/cml/ • RDF (Resource Description Framework) • www.w3.org/RDF/ • SMIL (Synchronised Multimedia Integration Language) www.w3.org/TR/1998/PR-smil-19980409/ • MusicML • www.tcf.nl/trends/trends6-en.html • CFML (Cold Fusion, for database integration) • www.allaire.com/documents/cf45docs/acrobatdocs/45refcard.pdf

  14. References • W3Cs XML HomePage • www.w3.org/XML/ • XML Homepage • www.xml.com • XML FAQ • www.ucc.ie/xml • Ariadne web articles • www.ariadne.ac.uk/issue16/what-is/
