  1. MARPLOT Beta Joseph Mastandrea Emergency Response and Crisis Plan Manager Orange County Public Schools

  2. Additional Affiliations Present Adjunct Instructor, Louisiana State University National Center for Biomedical Research and Training (4+ years) Past CAMEO / MARPLOT / ALOHA Course Manager and Instructor, Nebraska Emergency Management Agency (7+ years)

  3. The Suite Computer-Aided Management of Emergency Operations (CAMEO) Mapping Application for Response, Planning and Local Operational Tasks (MARPLOT) Areal Locations of Hazardous Materials (ALOHA) LandView

  4. The Balance Sheet Benefits Developed by Federal Agencies Runs quickly on most MS and Mac platforms When you download CAMEO the chemical library is included Popular with planners and responders Focus response efforts Free training available Limitations Developed by Federal Agencies – on “Census time” Statistical predictions of vulnerable zones resemble weather forecasts Statistical models do not consider topography

  5. MARPLOT Today Today you can obtain MARPLOT packaged in two different ways As a free standalone - download from EPA at http://response.restoration.noaa.gov/marplot Packaged US Census data and Landview via http://www.census.gov/geo/landview/ (entire US on 2 DVDs at $129) or http://atlas.lsu.edu/landview5/ (one state at a time for free) Download additional county maps for free at http://web-services.gov/mmaps/index.htm

  6. MARPLOT Today List -> Map List, Find New Map, navigate to the .map

  7. MARPLOT Today

  8. MARPLOT Beta Downloads with the continental US and state maps As you zoom in, MARPLOT automatically downloads any needed local maps and displays them Looks more like a highway map, online mapping program or atlas Uses the same navigation buttons as the current MARPLOT

  9. MARPLOT TODAY Deriving a population estimate from an area: Draw polygon or plot plume Select polygon or plume List menu -> Search… Objects inside or touched by Set layer to Census Block Points Search, Show All on Map Sharing menu -> LandView -> Get Info Summarize

  10. Simplified Population Estimates

  11. Download (if needed)

  12. MARPLOT Beta

  13. Aerial Photos Today Select for or search for an USGS-GNIS object in LandView Click the “Web Link” button On the web page, click “View USGS Digital Orthophoto Quadrangle (DOQ)” Save the file to your computer Create a new layer or open an existing layer, bring in the photo and geo-reference (a long process taking several steps)

  14. Aerial Photos in the Beta

  15. Topo Maps Today Select for or search for an USGS-GNIS object in LandView Click the “Web Link” button On the web page, click “View USGS Digital Raster Graphic or Topozone.com” Like aerial photos, topo maps must be saved, placed in a layer and geo-referenced

  16. Topop maps in the Beta

  17. Hands-on Demonstration Standard “beta software” disclaimers apply You are about to see the latest beta which is the fourth in the series General release and availability are scheduled for early 2009 Some of the menus, dialog boxes and features are not complete

  18. Training Resources Dwayne Mundy, North Central Florida Local Emergency Planning Committee Free DHS FEMA National Preparedness Directorate (NPD) National Integration Center (NIC), Training and Exercise Integration Secretariat (TEI), Training Operations (TO) via FDEM (our SAA) PER 229 Intro to CAMEO (-1 TTT) MGT 320 Utilizing CAMEO in WMD (-1 TTT)

  19. Questions?
