  1. GNEP Alan J Hays Genoa Central High School Arkansas

  2. Before you can intellectually discuss nuclear energy, one must understand nuclear physics.

  3. Challenges to discussing Nuclear Physics • Homer Simpson • The “stigma” of “physics” too difficult, therefore is to be avoided at all costs • Society issues too difficult, therefore is to be avoided at all costs • Religious issues young earthers and other controversies, therefore is to be avoided at all costs • Mathematics is language of physics, therefore is too difficult, therefore is to be avoided at all costs

  4. Misconceptions • All radioactive elements are extremely dangerous to living things. • There is no way to protect oneself from radioactivity. • There are very few naturally occurring radioactive elements. • Radioactive elements only occur in nuclear power plants and nuclear weapons.

  5. It’s all Earth Science to me! Most all of the earth’s rock material contains uranium. Ratio of U-238 to U-235  0.7% U-238 →Pb T1/2 4.5 bil yrs. U-235 T1/2  700 million yrs. @t = 0 yrs [U-238] = [U-235] Ratio of T1/2U-238 to T1/2U-235  7  Age of earth  8 U-235 half-lifes  5.6 bil yrs

  6. Lab Sequence • What’s hot and what’s not • Background radiation • Radiation and Distance • Shielding and absorption • Half-Life

  7. What’s Hot and What’s Not • A discovery lab • Students are given a brief on GM tube use • Given a bag of miscellaneous materials. • Observations

  8. Background Radiation • Count the “ticks” for a specified time • From a class get 20 – 30 recordings • Sample data: counts per 30 seconds. Background radiation: 40 cps

  9. Radiation and Distance • Familiar “inverse square law” • Sample data: Background Radiation = 58cpm

  10. Radiation and Distance • Graphing y = 144651x-2.0132 The exponent of x -2; data function very closely follows the inverse square law

  11. Shielding • Beta source • Data:

  12. Absorption • Beta source and aluminum shielding • Sample data y = 16545e-47.1x

  13. Absorption • Gamma source and lead shielding • Sample Data y = -4967x + 3744

  14. Half-Life • Ba-137m Isogenerator Cs-137 Parent nuclide; half-life(t1/2)  30yrs This decays to a metastable form(excited state) of barium(Ba-137m). Ba-137m decays to Ba-137(ground state) by gamma emission. t1/2 2.5min. • Freshness of samples is critical to good data

  15. Half-Life • Sample data: Time vs Counts y = -6.39ln(x) + 15.2

  16. Half-life • Mathematical modeling: N = # of nuclei present at time t. N0 = # of nuclei present at t = 0.  = decay constant (it’s constant!) Linear!

  17. Half-life • Linear graph • Slope =  • = - 0.2852 Ln(N) vs time y = -0.2852x + 2.9821

  18. Physics Mantras • Don’t memorize; understand • To know physics is to do physics • A single good observation is worth a century of bad philosophy • Process is more important than results • You only arrive at the right answer after making all possible mistakes. • A theory is accepted only when the last of its opponents dies off. • Pollyannas who believe anything is possible should be subjected to a course in thermodynamics.
