  1. FACS Week 15Recursive Descent Parsers, Table Driven Recursive Descent Parsers • TUTORIAL: • Creating LL parsers using Tables

  2. CREATING PARSERS • Assume you have a GRAMMAR G and a string S of Tokens of G. How can you tell if G can generate S? How can you extract the structure of S if it can be generated by G? • Example G, Tokens a,b,c,d 1. Z ::= d 2. Z ::=XYZ 3. Y ::= b 4. Y ::= c 5. X ::= Y 6 X ::= aZ • Example string ‘bbd’

  3. CREATING “RECURSIVE DESCENT” PARSERS • Method Outline: (1) Each non-terminal N becomes a Method/Procedure N (2) Each set of productions for a non-terminal N are used to define N’s body: -the RHS forms a statement sequence where non-terminals are method calls -alternative productions for the same non-terminal form if/case statements (3) Each Method/Procedure ‘consumes’ tokens – it inputs a list and outputs a smaller list

  4. RECURSIVE DESCENT PARSER FOR G (NB - This is rough - e.g. it does not handle failure!) • Method Z(in: S: list, out: S3: list) • if head S == ‘d’ then record(1); S3 = tail S; • else record(2); call X(S,S1); call Y(S1,S2); call Z(S2,S3) END • Method Y(in: S:list, out S1:list) • if head S == ‘b’ then record(3); S1 = tail S; • else if head S == ‘c’ then record(4) S1 = tail S; END • Method X(in:S: list, out S1:list) • if head S == ‘a’ then record(6); call Z(tail S,S1); • else record(5); call Y(S,S1) END • PARSER_for_G(S) = call Z(S, OUT); if OUT == ““ then SUCCESS.

  5. RECURSIVE DESCENT PARSER FOR G in PROLOG(NB - it does not handle failure!) • z([HS|TS], TS) :- HS = ‘d’, write('rule 1 used'),nl. • z([HS|TS], TS0) :- write('rule 2 used '),nl, x(S,S1), y(S1,S2), z(S2,TS0). • y([HS|TS], TS) :- HS = ‘b’, write('rule 3 used'),nl. • y([HS|TS], TS) :- HS = ‘c’, write('rule 4 used'),nl. • x([HS|TS], TS0) :- HS = ‘a’, write('rule 6 used'),nl,z(TS,TS0). • x([HS|TS], TS0) :- write('rule 2 used '),nl,y(TS,TS0). • Eg • | ?- z("adbd",C). • rule 2 used • rule 6 used • rule 1 used • rule 3 used • rule 1 used • true ?

  6. Definition of ‘LL’ Parser: • A Recursive Descent Parser is termed LL(1) because • -- It parsers from Left to right; • -- It calls methods corresponding to non-terminals in a Left to right fashion • -- It looks for the next 1 Token in the string to decide what branch to take in the parser

  7. PROBLEMS with the RD PARSER • BUT THE RD won’t work unless G is LL(1), i.e. • (i) G is NOT ambiguous • (ii) G is NOT left recursive • (iii) for EVERY two of G’s productions of the form X ::= W1, X ::= W2, it is the case that First(W1) and First(W2) have no common element • [ e.g. Add extra rule 7: Z ::= b ]

  8. TABLE DRIVEN PARSERS • Rather than translating a grammar straight into a program, its much better to translate in into a “machine” or “table”, forming a “table-driven parser”. • Translating a grammar into a table is a good form of analysis as well as one step towards a parser: GRAMMAR => TABLE => PARSER

  9. TO AUTOMATICALLY CONSTRUCT AN LL(1) PARSING TABLE • The Table is of size i x j – it has i columns corresponding to G’s i Tokens, j rows corresponding to G’s j non-terminals • Entries in the table are one or more production rules METHOD: 1. Enter the rule N ::= w in Row N Column m for each m in the First(w) 2. For each rule N ::= w, find if w is nullable. If w is nullable, enter N ::= w in Row N Column m for each m in the set Follow(N)

  10. TO RUN AN LL(1) PARSING TABLE ….on a string in its language (Exercise: adjust it to make it execute on any string) • Program Run-parsing-table: • % assume input string is consumed a token at a time • M = special symbol; a = get_token; call Loop(M,a); end • Loop(in: M, in/out: a) • 1. Apply the production P in Row M Column a; • 2. For each of the symbols w in the RHS of P • if w is a Non-Terminal: call Loop(w,a); • else if w is a Token: a = get_token • end

  11. SUMMARY • LL parsers are top-down - they start at the special symbol and try to parse a string from left to right. • We have seen how to construct two kinds of LL(1) parser - the recursive descent method and the table driven method • NEXT WEEK - LR table driven parsing - how JavaCup constructs its parsers
