  1. Eiffel: Analysis, Design and Programming Bertrand Meyer Chair ofSoftware Engineering

  2. - 6 - Genericity

  3. What’s wrong with this code? • classLIST_OF_CARSfeature • extend (v: CAR) is … • remove (v: CAR) is … • item: CARis … • end classLIST_OF_CITIESfeature extend (v: CITY) is … remove (v: CITY) is … item: CITYis … end

  4. What’s wrong with this code? • classLIST_OF_CARSfeature • append (other: LIST_OF_CARS) • do • from other.start until other.after loop • Current.extend (other.item) • end • end • end • classLIST_OF_CITIESfeature • append (other : LIST_OF_CITIES) • do • from other.start until other.after loop • Current.extend (other.item) • end • end • end DRY Principle: Don’t Repeat Yourself

  5. Possible approaches for containers • 1. Duplicate code, manually or with help of macro processor. • 2. Wait until run time; if types don’t match, trigger a run-time failure. (Smalltalk) • 3. Convert (“cast”) all values to a universal type, such as “pointer to void” in C. • 4. Parameterize the class, giving an explicit name G to the type of container elements. This is the Eiffel approach, now also found in Java (1.5), .NET (2.0) and others.

  6. Genericity solution to LIST_OF_... • classLIST [G]feature • append (other: LIST [G]) do • do • from other.start until other.after loop • Current.extend (other.item) • end • end • end • city_list: LIST [CITY] • car_list: LIST [CAR]

  7. A generic class classLIST[G ]featureextend (x : G )... last : G ... end To use the class: obtain a generic derivation, e.g. cities: LIST[CITY ] Formal generic parameter Actual generic parameter

  8. Genericity: Ensuring type safety How can we define consistent “container” data structures, e.g. list of accounts, list of points? Dubious use of a container data structure: c : CITY ; p : PERSONcities : LIST ... people : LIST ... --------------------------------------------------------- people.extend () cities.extend ( ) c := cities.last c.some_city_operation What if wrong? p c

  9. Using generic derivations cities : LIST [CITY] people: LIST [PERSON] c : CITY p: PERSON... cities.extend (c) people.extend (p) c := cities.last c. some_city_operation • STATIC TYPING • The compiler will reject: • people.extend (c) • cities.extend (p)

  10. Static typing Type-safe call (during execution): A feature call x.fsuch that the object attached to x has a feature corresponding to f. [Generalizes to calls with arguments, x.f(a, b) ] Static type checker: A program-processing tool (such as a compiler) that guarantees, for any program it accepts, that any call in any execution will be type-safe. Statically typed language: A programming language for which it is possible to write a static type checker.

  11. Using genericity LIST [CITY ] LIST [LIST [CITY ]] … A type is no longer exactly the same thing as a class! (But every type remains based on a class.)

  12. Definition: Type • We use types to declare entities, as in x: SOME_TYPE • With the mechanisms defined so far, a type is one of: • A non-generic class e.g.METRO_STATION • A generic derivation, i.e. the name of a class followed by a list of types, the actual generic parameters, in brackets (also recursive) e.g. LIST[ARRAY [METRO_STATION]] • LIST [LIST [CITY ]] • TABLE[STRING, INTEGER]

  13. So, how many types can I possibly get? • Two answers, depending on what we are talking about: • Static types • Static types are the types that we use while writing Eiffel code to declare types for entities (arguments, locals, return values) and when creating new objects without explicitly specifying the type • Dynamic types • Dynamic types on the other hand are created at run-time. Whenever a new object is created, it gets assigned to be of some type.

  14. Static types • classEMPLOYEE • feature • name: STRING • birthday: DATE • end • classDEPARTMENT • feature • staff: LIST [EMPLOYEE] • end bound by the program text: EMPLOYEE STRING DATE DEPARTMENT LIST[G] becomes LIST[EMPLOYEE]

  15. Object creation, static and dynamic types • classTEST_DYNAMIC _CREATION • feature • ref_a: A ref_b: B • --Let’s suppose B, with creation feature make_b, --inherits from A, with creation feature make_a • do_something • do • createref_a.make_a • -- All that matters is the static type A • create{B} ref_a.make_b • -- This is ok, because of the dynamic type end • end

  16. Dynamic types: another example • classSET[G] feature • powerset:SET[SET[G]]is • do • createResult • -- More computation… • end • i_th_power(i: INTEGER):SET[ANY] • require i>=0 • local n:INTEGER • do • Result:=Current • fromn:=1untiln>iloop • Result:=Result.powerset • n:=n+1 • end • end • end • __ Dynamic types from i_th_power : SET[ANY] SET[SET[ANY]] SET[SET[SET[ANY]]] … From http://www.eiffelroom.com/article/fun_with_generics

  17. Genericity: summary 1 • Type extension mechanism • Reconciles flexibility with type safety • Enables us to have parameterized classes • Useful for container data structures: lists, arrays, trees, … • “Type” now a bit more general than “class”

  18. Extending the basic notion of class BAG_OF_CARS LIST_OF_CITIES LIST_OF_ PERSONS LINKED_LIST_OF_CARS Inheritance Abstraction Genericity Type parameterization Type parameterization LIST_OF_CARS Specialization

  19. The static and the dynamic • For a feature call x.f: • Static typing: There is at least one feature f applicable to x • Dynamic binding: If more than one possible feature,execution will select the right feature

  20. The static and the dynamic • deferredclassANIMAL feature • talkis • -- Talk, or as least make sound. • deferred • end • end • classCAT inherit ANIMAL feature • talkis do io.put_string(“Miao”) end • end • classHUMAN inherit ANIMAL feature • talkis do io.put_string(“Hello”) end • end ANIMAL HUMAN CAT

  21. The static and the dynamic • a: ANIMAL • c: CAT • h: HUMAN • a := c • a.talk • a := h • a.talk ANIMAL HUMAN CAT When compiling, type checker checks if there is at least one feature named talk in type ANIMAL, which is the declared type of a. At run-time, execution will select the right feature to invoke, which will be talk fromCAT here.

  22. More Genericity Unconstrained LIST[G] e.g.LIST [INTEGER], LIST [PERSON] Constrained HASH_TABLE[G, H―> HASHABLE] VECTOR [G―> NUMERIC]

  23. Genericity + inheritance 1: Constrained genericity • class VECTOR [G ] feature • plusalias "+" (other: VECTOR [G]): VECTOR [G] • -- Sum of current vector andother • require • lower = other.lower • upper = other.upper • local • a, b, c: G • do • ... See next ... • end • ... Other features ... • end

  24. = i c a b + Adding two vectors u v = w + 2 1

  25. Constrained genericity • Body of plusalias "+": • createResult.make (lower, upper) • from • i := lower • until • i > upper • loop • a := item (i) • b := other.item (i) • c := a + b-- Requires “+” operation on G! • Result.put (c, i) • i := i + 1 • end

  26. The solution • Declare class VECTOR as • classVECTOR [G –>NUMERIC] feature ... The rest as before ... • end • Class NUMERIC (from the Kernel Library) provides features plusalias "+", minusalias "-"and so on.

  27. Improving the solution • Make VECTOR itself a descendant of NUMERIC, • effecting the corresponding features: • classVECTOR [G –> NUMERIC] inherit • NUMERIC • feature • ... Rest as before, includinginfix"+"... • end • Then it is possible to define • v : VECTOR [INTEGER] • vv : VECTOR [VECTOR [INTEGER]] • vvv: VECTOR [VECTOR [VECTOR [INTEGER]]]

  28. Enforcing a type: the problem • fl : LINKED_LIST [FIGURE] • fl.store("FILE_NAME") • ... • -- Two years later: • fl:=retrieved ("FILE_NAME") – See nextx := fl.last-- [1] • print (x.diagonal) -- [2] • What’s wrong with this? • If x is declared of type RECTANGLE, [1] is invalid. • If x is declared of type FIGURE, [2] is invalid.

  29. Enforcing a type: the Object Test Expression to be tested Object-Test Local • if {r: RECTANGLE} fl.lastthenprint (r.diagonal) • … Do anything else with r, guaranteed • … to be non void and of dynamic type RECTANGLE • elseprint ("Too bad.") • end SCOPEof the Object-Test Local

  30. Assignment attempt: an older mechanism • x ?= y • with • x: A • Semantics: • Ifyis attached to an object whose type conforms to A, perform normal reference assignment. • Otherwise, make xvoid.

  31. Assignment attempt example • f: FIGURE • r: RECTANGLE • ... • fl.retrieve ("FILE_NAME") • f := fl.last • r ?= f • ifr /= Void thenprint (r.diagonal)elseprint ("Too bad.")end

  32. More examples on constrained generics • deferredclassFIGUREfeature • drawis • -- Draw Current figure • deferred • end • end • classCIRCLEinheritFIGURE • feature • drawdo -- Draw circle. • end • end • LINE, RECTANGLE, …

  33. What about a composite figure? [G -> FIGURE] • classCOMPOSITE_FIGURE • inherit • feature • end FIGURE LINKED_LIST[G] • draw • do • -- To be finished. • end

  34. Composite figure • classCOMPOSITE_FIGURE[G->FIGURE] inherit • FIGURE • LINKED_LIST[G] • feature • drawis • do • from • start • until • after • loop • item.draw • forth • end • end • end

  35. Using FIGURE classes • f : FIGURE • c1, c2 : CIRCLE • l : LINE • cc: COMPOSITE_FIGURE[ CIRCLE ] • cf: COMPOSITE_FIGURE[ FIGURE ] • cc.extend (c1) • cc.extend (c2) • cc.draw • cf.extend (c2) • cf.extend (l) • cf.draw

  36. Are we really type safe? • animal_list: LINKED_LIST [ANIMAL] • sheep_list: LINKED_LIST [SHEEP] • sheep: SHEEP • sheep_list.extend (sheep) • animal_list := sheep_list ANIMAL SHEEP WOLF wolf: WOLF animal_list.extend (wolf)

  37. CAT calls • CAT stands for Changing Availability or Type • A routine is a CAT if some redefinition changes its export status or the type of any of its arguments • A call is a catcall if some redefinition of the routine would make it invalid because of a change of export status or argument type.

  38. Catcall cases • Covariant redefinition • Non-generic case • Generic case • Descendant hiding

  39. Covariant redefinition – Nongeneric case • class ANIMAL • feature • eat (a_food: FOOD) is deferred … end • end • class WOLF • inherit ANIMAL redefine eat end • feature • eat (a_meat: MEAT) is do … end • end ANIMAL WOLF FOOD GRASS MEAT

  40. Covariant redefinition – Nongeneric case • animal: ANIMAL • wolf: WOLF • food: FOOD • grass: GRASS • create wolf • create grass • animal := wolf • food := grass • animal.eat (grass) ANIMAL WOLF FOOD GRASS MEAT

  41. Descendant hiding • classRECTANGLE • inherit • POLYGON • export{NONE} add_vertexend • end • feature • … • invariant • vertex_count = 4 • end POLYGON RECTANGLE What will happen? r: RECTANGLE p: POLYGON create r p := r p.add_vertex (…)

  42. Covariant redefinition – Generic case • animal_list: LINKED_LIST [ANIMAL] • sheep_list: LINKED_LIST [SHEEP] • sheep: SHEEP • sheep_list.extend (sheep) • animal_list := sheep_list ANIMAL SHEEP WOLF wolf: WOLF animal_list.extend (wolf)

  43. Covariant redefinition – Generic case • classLINKED_LIST [ANY] • feature • extend (v: ANY) do … end • end • classLINKED_LIST [SHEEP] • feature • extend (v: SHEEP) do … end • end • classLINKED_LIST [WOLF] • feature • extend (v: WOLF) do … end • end
