  1. Week 8: Audio Processing CS 177

  2. Sound • Light and sound are both transmitted in waves

  3. Frequency • The human ear can hear between about 12 Hz and 20,000 Hz • The higher the frequency of the wave, the higher the frequency of the note • Note that the A an octave above concert A (A440) has twice the frequency • Each half-step is an increase in the frequency by a factor of about 1.06

  4. Example of frequency change • We can take a sound: • And reproduce that sound at double the frequency (speeding it up): • Notice that we have to add twice as much information to have the sound fill the same amount of time

  5. Amplitude • The amplitude of a wave is the distance to its peak (measured by its y-value) • In sound, amplitude is a measure of volume • The larger the amplitude, the louder the sound Amplitude

  6. Example of amplitude change • We can take a sound: • And make the sound with half the amplitude: • The frequency is exactly the same, but the sound is half as loud

  7. Real sounds • Something that looks like a smooth sine wave is called a pure tone • No real instruments play anything like that • Even the purest real sound has overtones and harmonics • Real sound is the result of many messy waves added together:

  8. Digital Sampling • On a computer, we cannot record a wave form directly • As usual, we have to figure out a way to store a wave as a series of numbers • We are going to use these numbers to approximate the heights of the wave at various points

  9. Sample rate • Hertz (Hz) is a unit that means a number of times per second • We are going to break down the wave into lots of slices • We are going to have 44,100 slices in a second • Thus, we are slicing at 44,100 Hz

  10. Sample values • We slice up a wave and record the height of the wave • Each height value is called a sample • By getting 44,100 samples per second, we get a pretty accurate picture of the wave

  11. Sample format • There are many different formats for sampling audio • In our system, each sample will be recorded as a double • The minimum value of a sample will be -1.0 and the maximum value of a sample is 1.0 • A series of samples with value 0.0 represents silence • Our samples will be stored in an array

  12. Purpose of the StdAudio class • Audio data on computers is sometimes stored in a WAV file • A WAV file is much simpler than an MP3 because it has no compression • Even so, it contains two channels (for stereo) and can have many different sample rates and formats for recording sound • The StdAudio class lets you read and write a WAV file easily and always deal with a single array of sound, sampled at 44,100 Hz

  13. StdAudio methods • Everything you’d want to do with sound: • To do interesting things, you have to manipulate the array of samples • Make sure you have StdAudio.java in your directory before trying to use it

  14. StdAudio example • Let’s load a file into an array: • If the song has these samples: • Perhaps samplewill contain: String file = “song.wav”; double[] sample = StdAudio.read(file);

  15. StdAudio example • With the audio samples loaded into the array named sample, we can play them as follows: StdAudio.play(sample);

  16. Generating sound with StdAudio • Or, we could generate sound from scratch with StdAudio • This example from the book creates 1 second of the pitch A440: • StdAudio.SAMPLE_RATE is 44100 • double[] sound = new double[StdAudio.SAMPLE_RATE + 1]; • for( inti = 0; i < sound.length; i++ ) • sound[i] = Math.sin(2 * Math.PI * i * 440 / StdAudio.SAMPLE_RATE); • StdAudio.play(sound);

  17. PlayThatTune.java • The book provides a short program called Play That Tune (pp. 150 and 205) that will generate a sequence of notes according to an input file • It’s a sort of software synthesizer • If you know the notes for a song you’d like to play and their durations, you can create a file to play it with PlayThatTune.java • java PlayThatTune < song.txt

  18. Play That Tune file format • As you can see, the file is just a list of numbers giving pitch and duration • Although ugly, this form of bookkeeping takes up virtually no space compared to WAV files • Drawbacks: • You can only play one note at a time • All notes have a pure tone with a little bit of harmonics • It takes forever to type out an input file • No dynamics (volume control)

  19. Sound waves • Remember, sound is a wave • We are going to start playing with the waveform now to get different effects • Phase is a property of a wave that can be determined by its starting position • You can think of phase as the alignment of the wave

  20. Inverting phase • What happens if we invert a sound wave? • For example, we turn this wave: • Into this wave:

  21. Inverting phase in code • How would we invert the phase of a wave in code? • And what does that crazy, upside-down sound sound like? • Exactly the same • The human ear is not sensitive to phase • double[] sound = StdAudio.read( file ); • for( inti = 0; i < sound.length; i++ ) • sound[i] = -sound[i]; • StdAudio.play(sound);

  22. Concerns with phase • Phase is still worth knowing about • If you hear two copies of the same sound, but one is 180° out of phase, the sounds will cancel each other out • This can happen if you hook up one of your stereo speakers backwards

  23. Reversing a sound • To reverse a sound, we simply send the wave form backwards • For example, we take this sound: • And turn it into this sound:

  24. Reversing a sound in code • How would we reverse a sound in code? • What does it sound like? • Sort of like a bizarre foreign language • double[] sound = StdAudio.read( file ); • intstart = 0; int end = sound.length - 1; • while( start < end ) { • double temp = sound[start]; • sound[start] = sound[end]; • sound[end] = temp; • start++; • end--; • } • StdAudio.play(sound);

  25. Amplitude • Recall that the amplitude of a wave is the distance to its peak (measured by its y-value) • In sound, amplitude is a measure of volume • The larger the amplitude, the louder the sound Amplitude

  26. Example of amplitude change • We can take a sound: • And make the same sound with half the amplitude: • The frequency is exactly the same, but the sound is half as loud

  27. Reducing volume in code • How would we half the volume of a sound in code? • This is half the amplitude. Is this exactly half the volume? • No… this stuff gets complicated • Different frequencies with the same amplitude are actually perceived as different loudnesses • But, it’s close enough • double[] sound = StdAudio.read( file ); • for(inti = 0; i < sound.length; i++ ) • sound[i] = 0.5*sound[i]; • StdAudio.play(sound);

  28. Increasing volume in code • How would we double the volume of a sound in code? • Be careful! • Remember that the max is 1.0 and the min is -1.0 • If you go outside of that range, you should limit the values • double[] sound = StdAudio.read( file ); • for(inti = 0; i < sound.length; i++ ) { • sound[i] = 2*sound[i]; • if( sound[i] > 1.0 ) • sound[i] = 1.0; • else if( sound[i] < -1.0 ) • sound[i] = -1.0; • } • StdAudio.play(sound);

  29. Speeding up sound • We can take a sound: • And shrink that sound in half the time (while also doubling its frequency):

  30. Speeding up a sound in code • How would we double the speed of a sound in code? • We are just taking every other sample • We are throwing out half the information • double[] sound = StdAudio.read( file ); • double[] speed = new double[sound.length/2]; • for(inti = 0; i < speed.length; i++ ) • speed[i] = sound[2*i]; • StdAudio.play(speed);

  31. Slowing down sound • We can take a sound: • And stretch that sound to double the time (while also cutting its frequency in half):

  32. Slowing down a sound in code • How would we stretch that sound to double in code? • Often times, this can sound terrible • We are doubling the length of the sound, but we have no extra information • We are just filling in holes in the samples with copies • double[] sound = StdAudio.read( file ); • double[] slow = new double[sound.length*2]; • for(inti = 0; i < slow.length; i++ ) • slow[i] = sound[i/2]; • StdAudio.play(slow);

  33. Speeding up or slowing down non-integer amounts • Integers are easy • You can apply the same ideas to non-integer speed-ups and slow-downs • Smarter algorithms, like the ones used by professionals, may do some averaging or other tricks to retain sound quality

  34. Adding noise • To add noise to a waveform, add small random numbers to the wave • Make sure that the random numbers are both positive and negative (with a mean of 0) • You can turn this wave: • Into this wave:

  35. Removing noise • How can we turn this wave… • Into this wave? • That is much harder!
