  1. Chapter 27Light

  2. Early Concepts • Greek philosophers thought that light consisted of tiny particles • Soctrates and Plato thought that vision resulted from streamers or filaments emitted by the eye making contact with an object • Empedocles taught that light traveled in waves. • Christian Huygens, a contemporary of Newton argued that light was a wave. • He demonstrated that light seemed to travel in straight lines but in other circumstances it spreads out (diffraction). This supported the wave theory. • In 1905, Einstein published a theory explaining the photoelectric effect. According to this theory, light consists of particles called photons. Photon – elementary particle and basic unit of electromagnetic radiation

  3. The Dual Nature of Light The observation that light can behave as both a wave and a particle is called the dual nature of light

  4. Speed of Light • Danish astronomer Olaus Roemer (1675) made the first measurement • that showed that light travels at a finite speed by careful observations of Jupiter’s moons. • Albert Michelson (1880) performed the first experiment that measured the speed of light.

  5. Speed of light in vacuum: 300,000 km/s • 186,000 miles/s • Light Year: Distance that light travels in 1 year • A beam of light could make 7.5 trips around the earth in 1 second • Light takes about 8 minutes to travel from the sun to the earth • Light takes 4.2 years to travel from the nearest star, Alpha Centauri to Earth

  6. Microwaves are unable to pass through the screen in the window of a microwave because the wavelength of the microwaves is greater than the width of the holes in the screen:

  7. Light is emmitted by accelerating electric charges – often electrons in atoms • electromagnetic spectrum (see above) • Infrared waves – electromagnetic waves with a longer wavelength than the wavelength of red light • Ultraviolet waves – electromagnetic waves with a shorter wavelength than the wavelength of violet light

  8. Light is energy carried in an electromagnetic wave that is generated by vibrating electric charges. • When light is incident upon matter electrons in the matter are forced into vibration. • Exactly how a receiving material responds when light is incident upon it depends on the frequency of the light and the natural frequency of electrons in the material. • Glass and water are two materials that allow light to pass through in straight lines. They are transparent to light. • Materials that absorb light without reemission are opaque

  9. All materials that are springy (elastic) respond more to vibrations at some frequencies than others. Bells rings at a particular frequency, tuning forks vibrate at a particular frequency, and so do the eletrons in matter. The natural vibration frequencies of an electron depend on how strongly it is attached to a nearby nucleus. Different materials have different electric “spring strengths.”

  10. ray – a thin beam of light • shadow – formed where light rays cannot reach • umbra – total shadow • penumbra – partial shadow

  11. Crepuscular rays – columns of sunlit air separated by darker cloud-shadowed regions

  12. Polarization When wave motion is confined to one plane it is said to be polarized.
