  1. Power Solution Technologies co.,ltd. Switching Mode Rectifier PRODUCT PRESENTATION Pranai K. PST….

  2. Telecom power system configuration SMR main feature SMR block diagram SMR product SMR specification review Appendix Contents

  3. Telecom power system configuration

  4. Modular design for scalable ,cost effective expansion Hot-swappable,No system shutdown for maintenance Light weight ,high efficiency, high power density saves valuable floor space Active power factor correction (PF>0.99) Temperature compensation-voltage correction for VRLA batteries Advanced load share technology Front access for simplified operation and maintenance Wide input range(90Vac~300Vac,300Vac~320Vac no damage) Meet international safety and EMC regulations,UL/C-UL/TUV/CE approval SMR Main Feature

  5. PFC Boost Converter Insulated Full Bridge (Resonant ) DC/DC Converter OutputFilter & Breaker Input Breaker , Fuse , EMI Filter & Bridge Diode L Vo+ N Vo- PFC Controller DC/DC Controller Auxiliary Power Protection Ckt & Others SMR Block diagram

  6. SMR Product

  7. ESR 48/10B(ESR 48/08A) Series Rectifier -48V/10A,-48V/08A Max Power 560W Efficiency: 90% Fan cooling Operation temp.:-20deg C~+65deg C Dimension:63.6mm(W)*132mm(H)*243.1mm(D) Weight:2Kg UL/CUL/TUV/CE

  8. MCS 3000 Series Rectifier • Model: ESR 24/100B and ESR 48/50B • Universal Input : 90V~276V • Max. output power: 2800W • Efficiency: >88% for 24V; >90% for 48V • Cooling System: Forced Air Cooling • Dimension(WxHxD): 87 x 266 x 376 /mm • Weight: 7.8 Kg • Input power factor: >0.99 • Intelligent micro-processor controller inside • CAN Bus-High speed communication • 0~50 Degree C operating temperature • UL/CUL ,TUV

  9. DPST 2800AB A (MP at March 2003) • +24V/100A;48V/50A(May 2003) • Max. Power 2800W • Constant power • Power density=11.6 w/in^3 • Efficiency: >89.5%(24V),>91.5%(48V) • Fan cooling • Dimension:125mm(W)*84mm(H)*375mm(D) • Weight:4.9Kg • UL/CUL/TUV/CE

  10. MCS 1800 Series Rectifier • -48V/30A, +24V/50A • Max Power 1650W(1400W for 24V) • Dimension:83.6mm(W)*132mm(H)*263mm(D) • Light weight:3.3Kg • High power density:10.4W/inch^3 • Efficiency:> 91% • Fan cooling • Operation temp.:0deg C~+50deg C • PFC circuit patent • PFC,DC/DC converter Soft-Switch operation • UL/CUL,TUV/CE

  11. The MCS 1800 Rectifier Easy replaceable fan design The customer can replace the fan by just release these two screws.

  12. DC/DC CONVERTER • Model: DCS-48/10 and DCS-24/20 • Efficiency: >85% (48V) • EMI/RFI: FCC Class B • Indicators: Load Bars x 4, Fan Fail, Converter Fail • 2U height • UL/CUL,TUV/CE

  13. NEW DC/DC CONVERTER • Model: DPST-1300AB A • Vin=20V~31V,Vo=55V,Max. power =1300W • Efficiency: >87%,I/P=24V full load • EMI/RFI: FCC Class B • Meet ETSI spec. • W*H*D=65mm*170mm(4U)*215mm,3Kgw • Operating temp.:-5C ~+50C • UL/CUL,TUV,CE

  14. ESI Series Inverter • Vin=48V,1KVA/800W;2KVA/1.6KW • Pure sine wave output • User friendly LCD Interface • Compact size:19” W x 2U H • Intelligent communication interface • UL/CUL(110Vac model)TUV/CE(220Vac model)

  15. SMR Specification

  16. INPUT SPEC. • I/P voltage:176Vac~300Vac,single phase ,full load • 176Vac~90Vac derating to 50% load • I/P frequency :45~65Hz • Iin=(Po/Eff.)/Vin • PF:>0.99,normal input,full load • THD:<5%, ,normal input,full load • Efficiency:>90%,for 48V O/P, ,normal input,full load • >88%,for 24V O/P,normal input,full load • Inrush current:1.5*Iin, ,normal input,full load • Start time delay(walk-in):3~10 seconds • Protection:fuse or breaker

  17. OUTPUT SPEC. • DC Output: 40~59Vdc for 48V output • 20~29Vdc for 24V output • Output power:Max. power =56Vdc*Io • Regulation : • load regulation:<+-0.5%(load 0%~100%) • line regulation:<+-0.1%(90Vac~300Vac) • Current limit:110% Max. of rated output current • Noise : • Audio Band:<2mV(for 48Vdc),<1mV(for 24Vdc) • Wide Band:<10mV(10KHz~100MHz) • Acoustic:55dBA@1M

  18. Current sharing:<+-5% of rated output current • Temperature coefficient:<200ppm/deg C • Dynamic Response: • 10%> 90% load change, • overshoot<+-5% rated O/P voltage • recovery time<1ms to <+-1% rated output voltage • Protection :fuse or breaker

  19. Protection • High voltage shutdown: If the rectifier o/p voltage exceeds a preset • value ,the module will shutdown and latch • Over current/Output short:Automatic shutdown and Recovery • Over temperature: :Automatic shutdown and Recovery • Brown out:No damage during brown out conditions • AC input voltage high: :Automatic shutdown and Recovery • AC input voltage low: :Automatic shutdown and Recovery

  20. Environmental • Operating temperature:0~+50 deg C • Storage temperature:-40~85 deg C • Humidity :0~95% Relative Humidity non-condensing • Altitude:-500~10000 feet • EMI/RFI Suppression:Conforms to EN 55022,BS 652,FCC part 15,CISPR 22 class A • Current Harmonic:Conforms to EN 61000-3-2/A12,EN60555-2,IEC555-2 Class A • Voltage fluctuation:Conforms to EN 61000-3-3,EN60555-3 • Electrostatic Discharge:Conforms to EN 61000-4-2,IEC 1000-4-2,IEC801-2 level 4 • Radiated Susceptibility :Conforms to EN 61000-4-3, IEC801-3 level 3 • Electrical Fast Transients: :Conforms to EN 61000-4-4,IEC 1000-4-4,IEC801-4 level 4 • Conducted Susceptibility: :Conforms t IEC 1000-4-6 level 3 • Lighting/Surge:Conforms to ANSI/IEEE C62.41-1,1991 B3,IEC1000-4-5 level special

  21. Adjustments • Test pin: for output voltage,current • Float voltage(FLO):Adjust by SMR or Setting from CSU • Equalize voltage(EQU):Adjust by SMR or Setting from CSU • Current limit(CL) :Adjust by SMR or Setting from CSU • Remote control:Emergency Shutdown,Float/Equalize Mode

  22. Other Data • Safety:meet IEC 950,EN 60950,UL/C-UL/TUV/CE Approval • Isolation(Hi-Pot): 4242Vdc(1mins) between input and output • 2828Vdc(1mins) between input and FG • 707Vdc(1mins) between output and FG • MTBF:>150K Hours • Cooling:Fan cooling or Natural Convection • Heat Dissipation: P loss*3.412BTU/HR (1W=3.412BTU/HR) • Pin=Po/Eff. • P loss=Pin-Po

  23. APPENDIX

  24. Why PF Correction ? • Power company unhappy • Large power loss ( input current increase) • Reduce current harmonic distortion • Neutral Wire Burns(potential fire hazard) • More limitation on wall socket output • For example:120V,line 12Arms (Household Regulation) • then Max.=1.4KW Output • if PF=0.6 then Max. power=0.84KW

  25. BROWN OUT TEST

  26. What is CE ? • CE=EMC+Safety(TUV or VDE) • EMC=EMI+EMS • EMI=Conduction +Radiation • EMS • ESD(Electrostatic Discharge):air 15KV,contact 8KV • EFT(Electrical Fast Transient):level 4,4KV • RS(Radiated Susceptibility):Level 3,10V/m • CS(Conducted Susceptibility):Level 3,3V/m • Surge/Lightning :Level special 6KV • Current Harmonic:<5%

  27. Why Soft-Switching(ZVS,ZCS) ? • Reduce switching loss • Increase switching frequency • Reduce EMI noise • Increase Switch Component SOA Ids Vds

  28. Because the CE Mark is mandated for all products shipped into the European Union, it has become the driving force for standards harmonization world-wide The CE Mark

  29. What is Electrostatic Discharge A person or charged object discharging into a sensitive electronic component or circuit can cause a device to fail or circuit to be upset.

  30. The threshold of feeling is 2kV to 4kV. Everyone can feel 5kV. 15kV is a memorable event! What is Electrostatic Discharge

  31. Arcing, which occurs as a switch opens, is both conducted and radiated into sensitive electronic circuits. What is an Electrical Fast Transient ?

  32. High energy transients resulting from lightning or switching operations in the power system. What is a Surge ?

  33. AC Magnetic fields are created whenever current is flowing in a loop or through inductors - most commonly, electric motors and transformers. AC Magnetic Fields

  34. THANKS
