  1. Chapter 21 Supporting Printers

  2. How Printers Work • Connect to a PC by parallel, serial, USB, IEEE 1394, or SCSI port, or by infrared, wireless, PC Card, or network connection • Can be combined with fax machines, copiers and scanners in the same machine • Most often use AC power A+ Guide to Managing and Maintaining Your PC, Fifth Edition

  3. Major Categories of Printers • Laser (highest quality) • Inkjet • Dot-matrix • …… A+ Guide to Managing and Maintaining Your PC, Fifth Edition

  4. Laser Printers • The highest quality • The most expensive • The fastest A+ Guide to Managing and Maintaining Your PC, Fifth Edition

  5. Inkjet Printers • Use ink-dispersion printing • Popular: small and print color inexpensively • Most give photo-quality results(eg, PhotoREt II color technology) • Paper quality affects quality of printed output • Slower than lasers A+ Guide to Managing and Maintaining Your PC, Fifth Edition

  6. Inkjet Printer Ink Cartridges A+ Guide to Managing and Maintaining Your PC, Fifth Edition

  7. Dot-Matrix Printers • Less expensive; lesser quality • Print multicopy documents (impact printer) • Print head moves across the paper, using pins to shoot against a cloth ribbon and print a matrix of dots • If print head fails, buy a new printer A+ Guide to Managing and Maintaining Your PC, Fifth Edition

  8. Dot-Matrix Printers A+ Guide to Managing and Maintaining Your PC, Fifth Edition

  9. Installing and Sharing a Printer • Local printers • Network printers • Default printer A+ Guide to Managing and Maintaining Your PC, Fifth Edition

  10. Hands-on Project: Installing a Local Printer • pp. 974 A+ Guide to Managing and Maintaining Your PC, Fifth Edition

  11. Hands-on Project: Sharing a Printer • pp. 975 A+ Guide to Managing and Maintaining Your PC, Fifth Edition

  12. Hands-on Project: Using a Shared Printer • pp. 977 - 980 A+ Guide to Managing and Maintaining Your PC, Fifth Edition

  13. Ways to Make a Printer Available on a Network • Attach regular printer to a PC using a port on the PC • PC can share printer with network • Connect network printer with embedded logic to manage network communication directly to network with its own NIC • Use a print server to control several printers A+ Guide to Managing and Maintaining Your PC, Fifth Edition

  14. How Windows Handles Print Jobs • Windows NT/2000/XP or Windows 9x using a PostScript printer • Converts print job data to PostScript language • Windows 2000/XP can also use Printer Control Language (PCL) • Windows 9x using a non-PostScript printer • Converts print job data to Enhanced Metafile Format (EMF) A+ Guide to Managing and Maintaining Your PC, Fifth Edition

  15. How Windows Handles Print Jobs (continued) • Text data lacking embedded control characters is sent as raw data (DOS) • Spooling • Printing jobs are placed in a queue, so the applications finish printing ASAP • The queued jobs are served by FCFS (First Come First Serve) A+ Guide to Managing and Maintaining Your PC, Fifth Edition
