  1. PowerLogic™ PowerView™ 2.0 Power monitoring software

  2. PowerLogic systems help you make the most of your energy • For decades, PowerLogic systems have helped customers improve productivity and profitability by helping them to …

  3. Save 2-4% on utility bills by knowing where and how energy is being used … Measure and control energy costs • Verify utility bills; participate in utility rate reduction programs • Reveal energy waste • Verify savings resulting from equipment upgrades, energy efficiency programs, or performance contracts • Identify opportunities to reduce demand changes and improve power factor • Allocate or sub-bill energy costs

  4. Save 2-5% on operating costs, by optimizing utilization and eliminating unnecessary equipment purchases … Optimize equipment use • Prolong asset life by balancing loading, and measuring and reducing harmonics and other factors that cause heating and shorten equipment life. • Maximize existing capacity, avoid unnecessary capital purchases by understanding loading and identifying spare capacity on existing equipment.

  5. PowerView™ 2.0 summary • Ideal for small system applications • Cost-effective, easy-to-use, entry-range power monitoring solution • Essential upgrade for existing users • Out-of-the-box usability – preconfigured screens and reports • Collect, process, analyse, store, and share data from compatible devices across your network • Key step towards a comprehensive energy intelligence strategy

  6. Power consumption monitoring Trend historical data; use electrical system to full capacity; avoid over-design Equipment monitoring Monitor electrical equipment, installations across network; watch for issues, schedule maintenance . Strategic planning Use logged values to develop strategies to avoid interruptions Preventative maintenance Transformers, circuit breakers, busways, panels, contactors for motors, etc. Applications Cost allocation and sub-billing Track and verify power-related costs,bills and tariffs; multi-year time of use profiles

  7. PowerView 2.0 features • Automatic device detection for easy setup • new higher speed detection possible • Supports up to 32 compatible PowerLogic devices • PC-based data logging for devices without onboard logging memory • Pre-configured real-time and historical data displays • Modbus TCP/IP and RS-485 supported serial communications • Reports in Microsoft Excel • MS Vista compliant • … part of a complete solution Software- PowerView 2.0 Data Communications- EGX-100- EGX-400 Intelligent Devices- Power meters - Enercept • Trip units

  8. Easy to use – 3 tab functionality • Real Time Display • Report Builder • Setup

  9. PowerLogic PowerView 2.0 components • Real Time Display: real-time access to your network’s power system information – view demand, energy, load, power and I/O status summaries • Report Builder: automatically interprets logged values and presents your data – easily generate and share measurement, energy by day or hour, THD and time of use reports • Setup: configure your system – find, add, rename or remove devices, configure logging intervals, set database backup or restore parameters

  10. Setup • PowerView scans and detects compatible networked devices • Uses Modbus TCP/IP and RS-485 serial communications • Allows up to 32 device connections • Real time data displays and historical logging begin automatically • Collects historical data on 15 minute intervals by default • Add/remove devices • Find compatible networked devices • Manually connect to, add and delete devices if desired • Change logging interval • Easily change the interval at which your devices are logged • Auto-detected devices can be renamed easily by the user

  11. Setup: database management • MicrosoftSQL2005 Express-Advanced database management includes: • Database backups • Database restores • Historical database management • Maintained below 2.9 GB in size

  12. Devicesupport • PowerView supports the following PowerLogic devices: • Power meters • PM9C • PM210 • PM500 • ION6200 • PM710, PM750 • PM810, PM820, PM850, PM870 • Circuit breaker trip units • Micrologic A, P and H • Compact NSX A and E • I/O status units • TORO MC • Enercept • Ability to offer other Modbus device support

  13. Devicesupport • PowerView logs the following parameters:

  14. Real-time display • Display real-time data and analyse summary information • Remotely view operations monitored by compatible devices • Monitor current, voltage, power, power factor, energy, demand power, demand current, and total harmonic distortion (THD) • View summary reports • Lowers infrastructure costs • Enables faster, more effective response to system events

  15. Real-time displays • Summaries include: • Demand current • Energy • Load current • Overview • Power • Input status • Output status

  16. Real-timedisplays • View individual circuits

  17. Real-timedisplays • View summaries for your entire system

  18. ReportBuilder • Easily create MS Excel reports with a few simple clicks • Print, store, distribute, or save • Define and create comprehensive database reports

  19. Report Builder • Pre-configured queries in MS Excel for complete ease of report creation • Provides historical information on electrical energy usage and power demand • Can view both graphical and tabular data • Energy usage reports by day or by week • Energy TOU (Time of Use) reports include: • Defining up to 3 schedules • Each schedule can contain: • up to 10 periods (bands) for energy accumulation • supports weekends, special days, holidays • Leverages Microsoft Excel • Exports complete data set to Excel • Crisp graphs, charts • View data as spreadsheet • Allows for additional manipulation, calculations and reporting

  20. Report Builder • Provides a six-step interface for easy report creation and generation

  21. Report: measurement trend

  22. Report: energies by day

  23. Report: THD quantitytrend

  24. Report: TOU energy cost summary

  25. In conclusion… • PowerLogic™ PowerView™ 2.0 software is an easy to use tool • Converts raw data from your power meters into valuable information • A key step towards a comprehensive energy management strategy
