  1. Secure & flexible monitoringof virtual machine University of Mazandran Science & Tecnology By : Esmaill Khanlarpour S.khanlarpour@ustmb.ac.ir January 07 2010

  2. Secure & Flexible Monitoring of Virtual Machines Outline : • Prolegomenon • VMM & Types • Xen Hypervisor • Xen Architecture • Memory Introspection • Introduction • Requirements 2 / 30

  3. Secure & Flexible Monitoring of Virtual Machines Outline (contd.) : • XenAccess Monitoring Library • XenAccess Virtual Memory Introspection • Conclusion 3 / 30

  4. Secure & Flexible Monitoring of Virtual Machines VMM (or Hypervisor) : • Is a piece of software/hardware platform-virtualization software that allows multiple operating systems to run on a host computer concurrently. • The VM management ,memory partitioning, cpu scheduling ... 4 / 30

  5. Secure & Flexible Monitoring of Virtual Machines VMM types : • Type 1 (bare-metal) hypervisors are software systems that • run directly on the host's hardware. • control the hardware control and to monitor guest operating-systems. • Examples include VMware ESX Server ,Xen, Oracle VM Server ,.. 5 / 30

  6. Secure & Flexible Monitoring of Virtual Machines VMM types (contd.): Application Application OS OS VMM HWW Type1 Architecture 6/ 30

  7. Secure & Flexible Monitoring of Virtual Machines VMM types (contd.): • Type 2 (or hosted) hypervisors are software applications running within a conventional operating-system environment. • Examples include VMware Server (formerly known as GSX), VMware Workstation,.... 7 / 30

  8. Secure & Flexible Monitoring of Virtual Machines VMM types (contd.): Application OS VMM Host os HWW Type2 Architecture 8/ 30

  9. Secure & Flexible Monitoring of Virtual Machines Xen Hypervisor : • Xen is a virtual-machine monitor for x86, x86-64, Itanium and PowerPC 970 architectures • The University of Cambridge Computer Laboratory developed the first versions of Xen for linux . • As of 2009 the Xen community develops and maintains Xen as free software. 9 / 30

  10. Secure & Flexible Monitoring of Virtual Machines Xen Hypervisor (contd.) : • licensed under the GNU General Public License (GPL2). • Type 1 of VMM types. • Xen has traditionally used a paravirtualized approach to implement virtualization. • Xen uses a split domain architecture , meaning that guest OSes are kept in unprivileged domains(domU). 10 / 30

  11. Secure & Flexible Monitoring of Virtual Machines Xen Hypervisor (contd.) : • Other Domain In Xen is Domain 0 (Dom0) DOM0 DOM U DOM U Xen Hypervisor HWW 11 / 30

  12. Secure & Flexible Monitoring of Virtual Machines Domain 0 (dom0) : • boots automatically when the hypervisor boots • receives special management privileges and direct access to all physical hardware by defaul • Modified versions of Linux, NetBSD and Solaris can run as theDom0 • interact with the other virtual machines 12/ 30

  13. Secure & Flexible Monitoring of Virtual Machines Domain 0 (contd.) : • All Xen virtualization environments require Domain 0 to be running before any other virtual machines can be started 13 / 30

  14. Secure & Flexible Monitoring of Virtual Machines Domain User (DomU) : • EXCEPT Dom0,All paravirtualized virtual machines running on a Xen hypervisor, are referred to as DomU PV Guests • Unmodified versions of Microsoft Windows and other proprietary operating systems can also run as guests if the CPU supports x86 virtualization • such CPUs include Intel VT and AMD-V. 14 / 30

  15. Secure & Flexible Monitoring of Virtual Machines Xen Architecture : 15 / 30

  16. Secure & Flexible Monitoring of Virtual Machines Memory Introspection : • Memory introspection is the process of viewing the memory of one virtual machine from a different virtual machine. • What makes memory introspection difficult is the semantic gap between the two virtual machines. • This Technique most used in intrusions detection . • Example : state of a system call 16 / 30

  17. Secure & Flexible Monitoring of Virtual Machines • Monitoring application Introduction : • Example: Task manager • Monitoring app in VM • Monitoring app is ≠ VMM • No architecture 17 / 30

  18. Secure & Flexible Monitoring of Virtual Machines Create a Architecture : • Bryan D.payne & his friends • Bryan D.payne is a Ph.D. Candidate in the College of Computing at the Georgia Institute of Technology • Start a Project in Georgia Tech Information Security Center (GTISC) that was called XenAccess architecture . 18 / 30

  19. Secure & Flexible Monitoring of Virtual Machines Requirements : • They designed the XenAccess architecture based on six high-level requirements. • 1. No superfluous modifications to the VMM. • In general sense ,these requirements can be seen as typical good programming guidelines,or good security guidelines. • 2. No modifications to the VM or the target OS. 19 / 30

  20. Secure & Flexible Monitoring of Virtual Machines Requirements (contd.): • 3. Small performance impact. • 4. Rapid development of new monitors. • 5. Ability to monitor any data on target OS. • 6. Target OS cannot tamper with monitors. 20 / 30

  21. Secure & Flexible Monitoring of Virtual Machines XenAccess Monitoring Library : • XenAccess is a library that simplifies the process of memory introspection for virtual machines running on the Xen hypervisor. • With XenAccess, your software can run in one virtual machine and access the memory space of other virtual machines. • The primary goal for the XenAccess architecture is to satisfy the six requirements stated in the Requirements. 21 / 30

  22. Secure & Flexible Monitoring of Virtual Machines XenAccess Monitoring Library (contd.): • Xen Access is implemented in C language as a shared library with 1935 source lines of code(SLOC). • The two primary monitoring functionalities in XenAccess Are virtual memory introspection and virtual disk Monitoring . 22/ 30

  23. Secure & Flexible Monitoring of Virtual Machines XenAccess Monitoring Library (contd.): • XenAccess & Requirements • Satisfy property 1 with : • Chose Xen as a virtualization solution because it is a Type I VMM (Introspection VMM) 23 / 30

  24. Secure & Flexible Monitoring of Virtual Machines XenAccess Monitoring Library (contd.): • Satisfy property 2 with : • with Xen Infrastructure they able to design the monitoring architecture to work without Changes to the target OS. • Satisfy property 3 with : • with examine the xenAccess. 24 / 30

  25. Secure & Flexible Monitoring of Virtual Machines XenAccess Monitoring Library (contd.): • Satisfy property 4 with : • with the XenAccess’s API (application program interface). • Satisfy property 5 with : • they desire an architecture that can monitor any data on the target OS. 25 / 30

  26. Secure & Flexible Monitoring of Virtual Machines XenAccess Monitoring Library (contd.): • Satisfy property 6 with : • They placed the monitors in a different VM than the target OS. Xen provides sufficient isolation between VMs for this to be a viable solution. 26 / 30

  27. Secure & Flexible Monitoring of Virtual Machines XenAccess Monitoring Functionalities : • Virtual Memory introspection • Virtual Disk Monitoring 27 / 30

  28. Secure & Flexible Monitoring of Virtual Machines Virtual Memory introspection : XenAccess Memory introspection 28 / 30

  29. Secure & Flexible Monitoring of Virtual Machines Virtual Memory Introspection (contd.) : • An application that monitors for changes in the system call table • Example include : • An application that monitors the integrity of an installed LKM (Linux Kernel Modules ) 29 / 30

  30. Secure & Flexible Monitoring of Virtual Machines conclusion: • VMM & Type • Xen Hypervisor • Memory introspection • XenAccess Monitoring Library 30 / 30

  31. Secure & Flexible Monitoring of Virtual Machines Reference : [1] BD Payne, M Carbone, and W Lee. “Secure and Flexible Monitoring of Virtual Machines”. In Proceedings of the 23rd Annual Computer Security Applications Conference (ACSAC 2007), December 2007. [2] Xen introduction.http://wiki.xensource.com/xenwiki/XenIntro,last accessed an 2009/12/22 [3] Xen Hypervisor .http://en.wikipedia.org/wiki/Hypervisor,last accessed an 2009/12/15 [4] Xen Domain .http://wiki.xensource.com/xenwiki/Dom0,last accessed an 2010/01/02

  32. Secure & Flexible Monitoring of Virtual Machines Reference : [5] Xen Domain .http://wiki.xensource.com/xenwiki/DomU,last accessed an 2010/01/02 [6] Xen Architecture.http://wiki.xensource.com/xenwiki/XenArchitecture,last accessed an 2009/12/15

  33. Secure & Flexible Monitoring of Virtual Machines Questions
