  1. The Tightbinding (LCAO) Method Overview of a Realistic Treatment of Semiconductor Materials.

  2. Tightbinding MethodRealistic Treatment for Semiconductor Materials! • For most of the materials of interest, in the isolated atom, the valence electrons are in s & p orbitals. • Before looking at the bands in the solid, lets first briefly & QUALITATIVELY look at the molecular orbitals for the bonding & antibonding states. • A Quantitative treatment would require us to solve the Molecular SchrödingerEquation That is, it would require us to do some CHEMISTRY!! • Now, a mostly qualitative review of elementary molecular physics.

  3. s orbitalsarespherically symmetric! Shapes of charge (& probability) densities |ψ|2 for atomic s & p orbitals: p orbitalshavedirectional lobes! The pylobeis along they-axis The pxlobeis along thex-axis The pzlobeis along thez-axis

  4. Wavefunctions Ψ and energy levels εfor molecular orbitals in Diatomic Molecule AB Ψ for aσ antibonding orbital ψsA ψs An s-electron on atom A bonding with an s-electron on atom B. Ψ for aσbonding orbital For ahomopolar molecule (A = B) ε for aσ antibonding orbital ε for atomic  s electrons ε for aσbonding orbital Result: A  bonding orbital (occupied; symmetric on exchange of A & B) Ψ= (ψsA+ ψsB)/(2)½ A  antibonding orbital(unoccupied; antisymmetric on exchange of A & B) Ψ= (ψsA - ψsB)/(2)½

  5. Wavefunctions Ψ & energy levels εfor molecular orbitals in aDiatomic Molecule AB Ψ forσ antibonding orbital An s-electron on atom A bonding with an s-electron on atom B. Ψ forσbonding orbital For aheteropolar molecule (A  B) ε forσ antibonding orbital ε for atomic s electrons on atoms A & B ε for σbonding orbital Result: A  bonding orbital (occupied; symmetric on exchange of A & B) Ψ= (ψsA+ ψsB)/(2)½ A  antibonding orbital(unoccupied; antisymmetric on exchange of A & B) Ψ= (ψsA - ψsB)/(2)½

  6. Charge (probability) densities |Ψ|2 for molecular orbitals in a Diatomic Molecule AB An s-electron on atom A bonding with an s-electron on atom B to get  bonding(+) &  antibonding(-) molecular orbitals.  bonding orbital: Ψ= (ψsA+ ψsB)/(2)½ (occupied; symmetric on exchange of A & B)  antibonding orbital Ψ= (ψsA - ψsB)/(2)½ (unoccupied; antisymmetric on exchange of A & B)
