  1. IPSec/IKE Protocol HackingToorCon 2K2 – San Diego, CA Anton Rager Sr. Security Consultant Avaya Security Consulting

  2. Agenda • IKE Overview and Protocol Weaknesses • Vendor Implementation Problems • IKE Tools discussion and demo

  3. Aggressive Mode IKE Cookie_R Cookie_I Responder Initiator SA_I+KE_I+Nonce_I+ID_I SA_R+KE_R+Nonce_R+ID_R+Hash_R [Hash_I] • Note: Aggressive uses ID that is independent of initiator IP

  4. Main Mode IKE Cookie_R Cookie_I Responder Initiator SA_I SA_R KE_I+Nonce_I KE_R+Nonce_R [ID_I] [ID_R] [Hash_I] [Hash_R] • Note: ID is normally IP address of each endpoint

  5. Aggressive Mode ID • ID sent in clear- Well known problem • IETF specifies that aggressive mode will send ID [UserID or GroupID] in clear • Eavesdropper can collect remote access user IDs • Some vendors have proprietary ways of hashing ID when using their client to hide ID • Interoperability [SafeNet/PGPNet] requires IETF adherence – ID leakage

  6. Aggressive Mode PSK Attacks • PSK [password or shared-secret] authentication uses a hash sent in the clear • HASH is derived from public exchanged info + PSK • Bruteforce/Dictionary attacks possible against HASH as a passive listener • Some vendors use DH private value for hash derivation to prevent passive attacks – attack must be active MITM with knowledge of hashing method

  7. Attack ProcessAggressive PSK Cracking Cookie_R Cookie_I Responder Initiator SA_I+KE_I+Nonce_I+ID_I SA_R+KE_R+Nonce_R+ID_R+Hash_R [Hash_I] Assume MD5-HMAC for Hash function – based on hash in SA Responder Hash: HASH_R=MD5-HMAC(MD5-HMAC(Guessed PSK, Nonce_I + Nonce_R), resp DH pub, init DH pub + cookie_R + cookie_I + init SA header + resp ID header)

  8. Aggressive Mode ID Enumeration • IKE protocol specification does not discuss how invalid ID should be handled. Many implementations respond with an invalid ID during the initial IKE negotiation – others just don’t respond • This can allow an active dictionary/bruteforce enumeration • Submit IKE initiator frame to concentrator with guessed ID. Concentrator will tell you if guess is wrong • Vendor Workarounds: Obfuscation responses

  9. Main Mode PSK Attacks • Similar problem to aggressive mode, except HASH is passed encrypted. • Main Mode requires an active or MITM attack to attack PSK to derive DH secret • IDs are normally the IPs of endpoints • We will guess the PSK and try to determine the encryption key for the 1st encrypted packet

  10. Attack ProcessMain Mode PSK Cracking Cookie_R Cookie_I Responder (Attacker) Initiator SA_I SA_R KE_I+Nonce_I KE_R+Nonce_R [ID_I] [ID_R] [Hash_I] [Hash_R]

  11. Attack ProcessMain Mode PSK Cracking • Collect public IKE values [Nonces, DH Public values, Cookies, headers, etc] and assume IDs are IP endpoint IPs • Collect 1ST encrypted packet • Calculate DH Secret • Choose PSK value and calculate SYKEYID, SKEYID_d, KEYID_a, KEYID_e • Generate IV from hash of DH Public values • Decrypt packet with IV and SKEYID_e – check for known plaintext to validate

  12. Main Mode Policy Enumeration • Similar to aggressive mode ID enumeration • Peer will only respond to valid IP address that has a defined policy • Attacker can send spoofed init frames to “peer” to search IP address space • Correct IP will cause an SA proposal reply from “peer” • Some vendors will send a “no proposal choosen” if SA is from invalid host

  13. Implementation Vulnerabilities • Cisco VPN Client 3.5 • Cisco VPN Client 1.1 • SafeNet/IRE SoftPK and SoftRemote • PGPFreeware 7.03 - PGPNet

  14. Tools • IKECrack – aggressive mode PSK cracker • IKEProbe – IKE packet mangler

  15. IKECrackhttp://ikecrack.sourceforge.net • IKE PSK Cracker – dictionary, hybrid, brute • Simplistic implementation – Aggressive mode only • Must use IETF HASH_R calculations (RFC 2409) • MD5 HMAC only – 93K kps on 1.8ghz P4 • PERL script that requires HMAC PerlMod and uses tcpdump –x output for capture – It’s a hack, but it works.

  16. IKEProberhttp://ikecrack.sourceforge.net • Command-line utility for building arbitrary IKE packets • Supports common IKE options and allows user specified data or repeated chars • Useful for finding BoF problems with option parsing – Used to find Cisco/PGPNet/Safenet probs • Perl based and requires NetCat in Unix -- Also a hack. • Can also be used for user enumeration

  17. Contact Info • IKE Tools and preso Download http://ikecrack.sourceforge.net • Anton Rager arager@avaya.com • Code criticism: This is proof-of-concept stuff -- fix it yourself
