Preparation of innerlayer circuit board Preparation of role film Temp: Cold -> R.T. Predrying of boards (Remove water absorption) o 130 C x30min. Opening role Lamination (temporal) (place films onto patterns) Using auto-cut laminator for DFR Using vacuum applicator Vacuum Lamination (Nichigo-Morton 、 MEIKI) o Mechanical d rilling or laser Via formation 100-110 C , 30s Vacuum, 30s Press, +(0.5-0.7) MPa Hot press o to flatten surface 100-110 C , 60s Press, 2-6kgf/cm2 Desmear Treatment with permanganate Removing of PET film Remove when cooled down to room temperature after lamination Electroless copper plating Copper plating Electo copper plating Hot air oven SH , G ; 170degCx30min GX:(90-120degCx30min)+(150-170degCx30min) SH-9K:170degCx30min C ure Subtractive method Pattern formation Semi-additive method RCC;120degCx30min+170degCx30min Repeat for multilayered types Annealing Hot air oven (Post-cure) For RCC, Two step cure is necessary for resin curing without voids or wrinkles. o 170 C x 30-60min. Coating solder mask ABF介紹_製程
ABF介紹_數據 Curing condition; 170degCx90min : SH-9K, GX, GX-10, GX-11, 180degCx90min : GX-35, GX-13, GX-TH3
