  1. AIRCRAFT MANUALS

  2. Aircraft Manuals. • What is Aircraft Manual? • Why they are used? • Types of Aircraft Manuals?

  3. Aircraft manual: • Aircraft manual, also commonly known as a user guide, is a technical communication document intended to give assistance to people using a particular system in aircraft.

  4. Uses: • Maintenance instructions. • Troubleshooting instructions. • Assembly instructions. • Installation instructions.

  5. VARIOUS AIRCRAFT MANUALS:

  6. OPERATIONAL MANUAL AIRCRAFT FLIGHT MANUAL-AFM AIRCRAFT PLANNING MANUAL-APM FLIGHT CREW OPERATING MANUAL-FCOM FLIGHT PLANNING AND CRUISE CONTROL MANUAL MASTER MINIMUM EUIPMENT LIST-MMEL WEIGHT & BALANCE MANUAL-WBM MATERIAL ILLUSTRATED PARTS CATALOGUE ILLUSTRATED TOOLS & EQUIPMENT MANUAL CLASSIFICATION-AIRCRAFT MANUAL: MAINTENANCE • AIRCRAFT MAINTENANCE MANUAL-AMM • COMPONENT MAINTENANCE MANUAL-CMM • AIRCRAFT SCHEMATIC MANUAL-ASM • WIRING DIAGRAM MANUAL-WDM • FAULT ISOLATION MANUAL-FIM • MAINTENANCE PLANNING DOCUMENT-MPD • MAINTENANCE TASK CARD MANUAL-MTCM • MAINTENANCE FACILITIES AND EQUIPMENT PLANNING MANUAL-MFEPM • POWER PLANT BUILD UP MANUAL-PPBUM • TROBLE SHOOTING MANUAL-TSM REPAIR • AIRCRAFT RECOVERY MANUAL-ARM • NON DESTRUCTIVE TESTING MANUAL-NDTM • STRUCTURAL REPAIR MANUAL-SRM

  7. AIRCRAFT MAINTENANCE MANUAL-AMM • The AMM contains data that includes the scheduled maintenance procedures identified by the Maintenance Requirements Manual (MRM). It gives instructions to service, replace, adjust, test, inspect, check, clean, paint, and repair the aircraft systems and equipment on the aircraft, usually done on the ramp or in the maintenance hangar. • Note: Instructions and data for repair of equipment off the aircraft OR OEM are contained in the Component Maintenance Manuals (CMM).

  8. AMM STRUCTURE

  9. ATA- AIR TRANSPORT ASSOCIATION • The ATA Chapter numbers provide a common referencing standard for all commercial aircraft documentation. This commonality permits greater ease of learning and understanding for pilots and engineers alike. The standard numbering system is controlled and published by the Air Transport Association.

  10. ATA CHAPTERS AIRCRAFT GENERAL ATA Number ATA Chapter name • ATA 05 TIME LIMITS/MAINTENANCE CHECKS • ATA 06 DIMENSIONS AND AREAS • ATA 07 LIFTING AND SHORING • ATA 08 LEVELING AND WEIGHING • ATA 09 TOWING AND TAXIING • ATA 10 PARKING, MOORING, STORAGE AND RETURN TO SERVICE • ATA 11 PLACARDS AND MARKINGS • ATA 12 SERVICING - ROUTINE MAINTENANCE

  11. AIRFRAME SYSTEMS ATA Number ATA Chapter name • ATA 20 STANDARD PRACTICES – AIRFRAME • ATA 21 AIR CONDITIONING AND PRESSURIZATION • ATA 22 AUTOFLIGHT • ATA 23 COMMUNICATIONS • ATA 24 ELECTRICAL POWER • ATA 25 EQUIPMENT/FURNISHINGS • ATA 26 FIRE PROTECTION • ATA 27 FLIGHT CONTROLS • ATA 28 FUEL • ATA 29 HYDRAULIC POWER • ATA 30 ICE AND RAIN PROTECTION • ATA 31 INDICATING / RECORDING SYSTEM • ATA 32 LANDING GEAR • ATA 33 LIGHTS • ATA 34 NAVIGATION • ATA 35 OXYGEN • ATA 36 PNEUMATIC • ATA 37 VACUUM • ATA 38 WATER/WASTE • ATA 45 DIAGNOSTIC AND MAINTENANCE SYSTEM • ATA 46 INFORMATION SYSTEMS • ATA 47 NITROGEN GENERATION SYSTEM • ATA 49 AIRBORNE AUXILIARY POWER • ATA 50 CARGO AND ACCESSORY COMPARTMENTS

  12. STRUCTURE ATA Number ATA Chapter name • ATA 51 STANDARD PRACTICES AND STRUCTURES – GENERAL • ATA 52 DOORS • ATA 53 FUSELAGE • ATA 54 NACELLES/PYLONS • ATA 55 STABILIZERS • ATA 56 WINDOWS • ATA 57 WINGS
