    1. Introduction to RADIO BEACON WMS Overview

    2. Level 1 Overview RADIO BEACON University

    3. Level 1 Overview RADIO BEACON University What is RADIO BEACON WMS? RADIO BEACON WMS is a Warehouse Management System But whats that? Barcoding Inventory Management up-to-the-minute warehouse inventory records Automated in-warehouse processes Order Management reports in real-time status of orders, products, and processes Customer Service Retail Compliance And MUCH, MUCH More!

    4. Level 1 Overview RADIO BEACON University Warehouse Processing with RADIO BEACON

    5. Level 1 Overview RADIO BEACON University Accounting (Host System) Interfaces Interfaces developed in-house and by third-party vendors include: SAP Business One Best Software: MAS 90/200, MAS 500, Platinum for Windows Microsoft Business Solutions: Great Plains/Solomon/Navision/Axapta Exact Software: MacolaES Pointforce: Winsol, AccountMate OEM products include: ACCPAC: AWMS Aperum: eWMS

    6. Level 1 Overview RADIO BEACON University Shipping System Interfaces

    7. Level 1 Overview RADIO BEACON University Interface Downloads Transactions going to RADIO BEACON WMS are downloads Downloads include: PO Purchase Orders (Receiving) SO Sales Orders (Picking) WO Work Orders (Kits/Assemblies) RMA Return Material Authorizations New Products, Updates & Barcodes Inventory Adjustments

    8. Level 1 Overview RADIO BEACON University Interface Uploads Transactions sent from RADIO BEACON are uploads Uploads include: PO Purchase Order Confirmations SO Sales Order Confirmations WO Work Order Confirmations RMA Return Material Auth. Confirmations Inventory Adjustments & Current Inventory Transaction/Status Confirmations EDI Raw ASN 856

    9. Level 1 Overview RADIO BEACON University Interface Types Accounting (Host System) Interfaces: Flat text file RB DNLOAD / UPLOAD SQL tables Host DNLOAD / UPLOAD SQL tables SOAP (Simple Object Access Protocol) & XML (Extensible Markup Language)

    10. Level 1 Overview RADIO BEACON University Warehouse Cycle Shipping (optional) final step before the product leaves distribution centre Host updated with quantity picked Host invoices customer Purchase orders downloaded from host: Items received in warehouse (paperless) using RADIO BEACONs RECEIVING functions receipt confirmation recorded and acknowledged by host as received Received stock put away in warehouse can be temporary location, overstock or pickbin Sales orders downloaded from host: stock allocated from locations within warehouse to sales order order waved to warehouse floor picked and packed (paperless) using RADIO BEACONs PICKING functions

    11. Level 1 Overview RADIO BEACON University Warehouse Processing

    12. Level 1 Overview RADIO BEACON University RADIO BEACON User Interfaces Radio Frequency (RF) Terminals RF handheld devices PC running Telnet Web Workstation Web Dispatch RFBase Console Barcode Printers RFID Printers and Portals (RFID=Radio Frequency Identification)

    13. Level 1 Overview RADIO BEACON University RF Handheld Devices RF Handhelds: Radio frequency handheld devices Run Telnet RFBASE sessions Connect via TCP/IP protocol Used by warehouse staff for all operations including: Receiving Printing labels Picking RF/Telnet This is the terminal client user interface for RFBase which is run via telnet sessions on RF handheld devices or PCs. It is used by warehouse staff for all warehousing operations such as receiving, picking, printing labels and so on.RF/Telnet This is the terminal client user interface for RFBase which is run via telnet sessions on RF handheld devices or PCs. It is used by warehouse staff for all warehousing operations such as receiving, picking, printing labels and so on.

    14. Level 1 Overview RADIO BEACON University Telnet If you are using a Telnet client program on a PC, point the client to the server machine on which the handheld thread is running, by entering the IP address or machine name of the server, or enter localhost if you are running Telnet on the server machine.If you are using a Telnet client program on a PC, point the client to the server machine on which the handheld thread is running, by entering the IP address or machine name of the server, or enter localhost if you are running Telnet on the server machine.

    15. Level 1 Overview RADIO BEACON University Web Workstation

    16. Level 1 Overview RADIO BEACON University Web Dispatch Web-based user interface Accessed with Internet Explorer Web Dispatch This is the web-based user interface for RADIO BEACON, accessed with Internet Explorer from any client machine. It is typically used by a warehouse manager to control order processing in the warehouse, to monitor and report on daily warehouse operations in real time, and, in some cases, to create sales and purchase orders. It may also be used by sales or customer service agents who want to use the reporting functions to check the status of orders or inventory.Web Dispatch This is the web-based user interface for RADIO BEACON, accessed with Internet Explorer from any client machine. It is typically used by a warehouse manager to control order processing in the warehouse, to monitor and report on daily warehouse operations in real time, and, in some cases, to create sales and purchase orders. It may also be used by sales or customer service agents who want to use the reporting functions to check the status of orders or inventory.

    17. Level 1 Overview RADIO BEACON University Web Dispatch Controls order processing for: Purchase Orders Sales Orders Work Orders Warehouse Transfers Monitors & reports on: Daily warehouse operations Inventory Order status Used by IT manager and System administrator for: Maintenance Troubleshooting Access to Setup/Configuration Customization using RADIO BEACON SDK (Software Developers Kit) Web Dispatch This is the web-based user interface for RADIO BEACON, accessed with Internet Explorer from any client machine. It is typically used by a warehouse manager to control order processing in the warehouse, to monitor and report on daily warehouse operations in real time, and, in some cases, to create sales and purchase orders. It may also be used by sales or customer service agents who want to use the reporting functions to check the status of orders or inventory.Web Dispatch This is the web-based user interface for RADIO BEACON, accessed with Internet Explorer from any client machine. It is typically used by a warehouse manager to control order processing in the warehouse, to monitor and report on daily warehouse operations in real time, and, in some cases, to create sales and purchase orders. It may also be used by sales or customer service agents who want to use the reporting functions to check the status of orders or inventory.

    18. Level 1 Overview RADIO BEACON University Web Dispatch Web Dispatch This is the web-based user interface for RADIO BEACON, accessed with Internet Explorer from any client machine. It is typically used by a warehouse manager to control order processing in the warehouse, to monitor and report on daily warehouse operations in real time, and, in some cases, to create sales and purchase orders. It may also be used by sales or customer service agents who want to use the reporting functions to check the status of orders or inventory.Web Dispatch This is the web-based user interface for RADIO BEACON, accessed with Internet Explorer from any client machine. It is typically used by a warehouse manager to control order processing in the warehouse, to monitor and report on daily warehouse operations in real time, and, in some cases, to create sales and purchase orders. It may also be used by sales or customer service agents who want to use the reporting functions to check the status of orders or inventory.

    19. Level 1 Overview RADIO BEACON University RFBase Console Terminal User interface for RFBase program running on the RADIO BEACON server

    20. Level 1 Overview RADIO BEACON University User ID

    21. Level 1 Overview RADIO BEACON University Barcode Printers Prints bin labels, product labels, license plates, shipping lables,pickslips, etc

    22. Level 1 Overview RADIO BEACON University RFID Printers Like a Barcode Printer but prints a RFID Label

    23. Level 1 Overview RADIO BEACON University RFID Portals Also referred to RFID scan tunnels Products are sent through the RFID portal, which reads all the RFID labels on cartons and pallets.

    24. Level 1 Overview RADIO BEACON University Lets Review So what did you learn? same list as goals and objectives (with hyperlinks??? next point next
