  1. KeyNote

  2. KeyNote: “?” • Aim:- A notation for specifying local security policies and security credentials that can be sent over an untrusted network. Vishwas Patil, TIFR.

  3. KeyNote: versus PolicyMaker • KeyNote predicate notations are based on C-like expressions and regular expressions. • KeyNote assertions always return a boolean. • It has built-in credential signature verification. • Human-readable assertion syntax (RFC 822). • Trusted actions are described by simple attribute/value pair. But it is similar in spirit to that of PolicyMaker! Vishwas Patil, TIFR.

  4. KeyNote: Approach • KeyNote accepts as input a set of local policy assertions, a collection of credential assertions, and a collection of attributes (action environment) that describes a proposed trusted action associated with a set of public-keys. • By applying assertion predicates to the environment it decides consistency of actions with local policy. Vishwas Patil, TIFR.

  5. KeyNote: Architecture • KeyNote is monotonic; adding an assertion to a query can never result in a query's having a lower compliance value that it would have had without the assertion. • Removing an assertion never results in increasing the compliance value returned by KeyNote for a given query. • The monotonicity property can simplify the design and analysis of complex network- based security protocols. Vishwas Patil, TIFR.

  6. KeyNote: Architecture Continued • KeyNote does not itself provide credential revocation services. • KeyNote compliance checker helps in verifying (signature) the credentials received from untrusted requestor. Vishwas Patil, TIFR.

  7. Vishwas Patil, TIFR.

  8. Keynote: Basic Syntax structure • A KeyNote assertion contains a sequence of sections, called fields,each of which specifies one aspect of the assertion's semantics. • Fields start with an identifier at the beginning of a line and continue until the next field is encountered. <Assertion>:: <VersionField>? <AuthField> <LicenseesField>? <LocalConstantsField>? <ConditionsField>? <CommentField>? <SignatureField>? ; [X]* means zero or more repetitions of character string X. [X]+ means one or more repetitions of X. <X>* means zero or more repetitions of non-terminal <X>. <X>+ means one or more repetitions ofX. <X>? means zero or one repetitions ofX. • Nonterminal grammar symbols are enclosed in angle brackets. • Quoted strings in grammar productions represent terminals. • All KeyNote assertions are encoded in ASCII. Vishwas Patil, TIFR.

  9. KeyNote: Semantics • Informally, the semantics of KeyNote evaluation can be thought of as involving the construction of a directed graph of KeyNote assertions rooted at aPOLICYassertion that connects with at least one of the principals that requested the action. • Semantics are almost similar to PolicyMaker. • RFC 2704 gives detailed description of the semantics. Vishwas Patil, TIFR.

  10. KeyNote: Discussion • Advantages / Disadvantages • Evaluation: simplicity, expressiveness, generality, extensibility • Open-Source implementations available. • OpenBSD uses it in IPSEC implementation. • $ man keynote Vishwas Patil, TIFR.
