**Decision Trees with Minimal Test Costs(ICML 2004, Banff,**Canada) Charles X. Ling, Univ of Western Ontario, Canada Qiang Yang, HK UST, Hong Kong Etc.**Goal**• When test examples contain missing values • Decide what to do? • Do a test to obtain a value • Skip the attribute and continue with the rest of the decision making • Ultimate decision: minimize total cost • Total cost=mis-classification cost + test cost**Assumptions**• Mis-classification cost, for one case • FP=false positive • FN=false negative • Test cost • = C(i) for attribute A_i, regardless of values • Examples in weather domain**Expected results**• Let there be a total of P+N training cases • If P*FN+N*FP < C*(P+N) • Then? • IF P*FN+N*FP >> C*(P+N) • Then?**Leaf Labeling**• How to label a node? • P=positive examples • N=negative examples • P*FN= • N*FP= • Label the node as + if …**Splitting Criteria on Attribute A**• Total Cost=? • Say two branches: 1 and 2 • (P1, N1) on branch 1, and (P2,N2) on 2 • Test cost= • Training data may contain missing values on this attribute • Ratio = P0/N0 • Total=? (page 3)**Properties**• The relative difference of misclassification cost and test cost tree! • Attributes with small test cost is always chosen first • When test cost is increased, the attribute goes down the tree**Test Strategies**• OST=optimal sequential test Always test when value is missing, following the order given by tree • Stops whenever meeting missing value Uses the ratio of P0/N0 to make decision at node**Experiments**• Comparison with C4.5**Costs in Machine Learning**• Most inductive learning algorithms: minimizing classification errors • Different types of misclassification have different costs, e.g. FP and FN • In this talk: • Test costs should also be considered • Cost sensitive learning considers a variety of costs; see survey by Peter Turney (2000)**Applications**• Medical Practice • Doctors may ask a patient to go through a number of tests (e.g., Blood tests, X-rays) • Which of these new tests will bring about higher value? • Biological Experimental Design • When testing a new drug, new tests are costly • which experiments to perform?**Previous Work**• Many previous works consider the two types of cost separately – an obvious oversight • (Turney 1995): ICET, uses genetic algorithm to build trees to minimize the total cost • (Zubek and Dieterrich 2002): a Markov Decision Process (MDP), searches in a state space for optimal policies • (Greiner et al. 2002): PAC learning**An Example of The Problem**Training: with ?, cannot obtain values Goal 1: build a tree that minimizes the total cost Test: with many ?, may obtain values at a cost Goal 2: obtain test values at a cost to minimize the total cost**blood test**pressure essay ? ? ? temperature cardiogram ? 39oc Example – Medical Diagnosis Is the patient healthy? Which test should be taken first? Which test to perform next? Concern: cost the patient as little as possible while maintaining low mis-diagnosis risk**What are Total Costs?**• Assumption: binary classes, costs: FP and FN • Goal: minimize total cost • Total cost = misclassification cost + test cost • Previous Work • Information Gain as a attribute selection criterion • In this work, need a new attribute selection criterion • Total cost = Sum_i { Probability(i)*Cost(i)}**Attribute Selection Criterion: C4.5**Select the attribute with minimal total cost • C4.5: minimal entropy • If growing a tree has a smaller total cost • then choose an attribute with minimal total cost • else stop and form a leaf • How to label a leaf node? • Label leaf according to minimal total cost • If (P×FN N×FP) then class = positiveelse class = negative • Example: {P, P, P, N, N, N, N} FN=$10, FP=$1 • Information Gain+Majority class: Predict N, 3 mistakes. • Total cost: if we predict P, 4*FP=4*1=$4; • If we predict N, 3*FN = $30. Conclusion: Predict P.**Minimal cost: summary**• Attribute selection criterion: minimal total cost(Ctotal = Cmc + Ctest) instead of minimal entropy in C4.5 • If growing a tree has a smaller total cost, then choose an attribute with minimal total cost. Otherwise, stop and form a leaf. • Label leaf also according to minimal total cost: • Suppose the leaf have P positive examples and N negative examples • FP denotes the cost of a false positive example and FN false negative • If (P×FN N×FP)THEN label = positive ELSE label = negative**A Tree Building Example**Cmc = min(P×FN, N×FP) Ctest = 0Ctotal = Cmc + Ctest P:N Attribute A with a test cost C Consider attribute A for a potential splitting attribute A = v1 A = v2 C’mc= min(P1×FN, N1×FP) + min(P2×FN, N2×FP) C’test = (P1 + N1 + P2 + N2) × C C’total = C’mc + C’test P2:N2 P1:N1 • If C’total < Ctotal, splitting on A would reduce the total cost Choose an attribute with the minimal total cost for splitting • If C’totalCtotal for all remaining attributes, no further sub-tree will be built, and the set will become a leaf.**Missing values: ? values**• First, how to handle ? values in training data • Previous work • built ? branch; • problematic • We will • deal with unknown values in the training set: • no branch for ? will be built, • examples are “gathered” inside the internal nodes**A1**A1 P All test costs are 300 A6 A6 P N P N P P P P P P All test costs are 20 P N N P N N All test costs are 0 Desirable Properties 1. Effect of difference between misclassification costs and the test costs**A1**A2 A3 A4 A5 A6 # 1 20 20 20 20 20 20 # 2 200 20 100 100 200 200 # 3 200 100 100 100 20 200 A1 A2 A5 A6 A6 A1 N P P P P P P A1 P P N N P N N P N P N P P P N P N P P 2. Prefer attribute with smaller test costs**A6**A6 A1 P P A1 N P P A2 N A6 A6 P P P P P N N P N N N N P P N P N Cost of A1=20 Cost of A1=50 Cost of A1=80 3. If test cost increases, attribute tends to be “pushed” down and “falls out” of the tree**Cost Reduction**P:N A P1:N1 P2:N2 • Equivalent to Information Gain • Min{P*FN, N*FP} – [cost(A) + Min{P1*FN,N1*FP} + Min{P2*FN, N2*FP}] • We choose the attribute with the largest such value as a splitting attribute**Missing values in test cases**A New patient arrives:**OST: Intuition**• Follow the test-cost sensitive decision tree • When reaching a node, make a decision • If the node is a leaf node… • If the node is an internal node, and we have missing value, then obtain the value • Evaluation: calculate the total cost when the ground truth is known**A1**A6 A6 P P P P P N N P N N A1 P N P N P P Four Testing Strategies • First: Optimal Sequential Test (OST)(Simple batch test: do all tests) • Second: No test will be performed, predict with internal node • Third: No test will be performed, predict with weighted sum of subtrees • Fourth: A new tree is built dynamically for each test case using only the known attributes**Experiment - settings**• Five dataset, binary-class • 60/40 for training/testing, repeat 5 times • Unknown values for training/test examples are selected randomly by a specific probability • Also compare to C4.5 tree, using OST for testing**No test, internal**No test, lazy tree C4.5 tree, OST Results with different % of unknown • OST is best; M4 and C4.5 next; M3 is worst • OST not increase with more ?; others do overall No test, distributed**No test, internal**No test, lazy tree C4.5 tree, OST Results with different test costs • With large test costs, OST = M2 = M3 = M4 • C4.5 is much worse (tree building is cost-insensitive) No test, distributed**No test, internal**No test, distributed No test, lazy tree C4.5 tree, OST Results with unbalanced class costs • With large test costs, OST = M2 = M4 • C4.5 is much worse (tree building is cost-insensitive) • M3 is worse than M2… (M3 is used in C4.5)**Comparing OST/C4.5 cross 6 datasets**• OST always outperforms C4.5**Conclusions**• New tree building algorithm for minimal costs • Desirable properties • Computationally efficient (similar to C4.5) • Test strategies (OST and batch) are very effective • Can solve many real-world diagnosis problems**Future Work**• More intelligent “Batch Test” methods • Consider cost of additional batch test • Optimal sequential batch testbatch 1 = (test1, test 2)batch 2 = (test 3, test 4, test 5), … • Other learning algorithms with minimal total cost • A wrapper that works for any “black box”
