Tensile Testing Machine | Shanta Engineering

Tensile Testing Machine, which is manufactured using best grade raw materials. Our range can be customized as per the requirement of our esteemed clients. Quality and service of the products is our first priority, we provide variety of grips to hold the material and perform testing. This machine is used for different application based on the requirement.<br>

ShantaEngg
Télécharger la présentation

Tensile Testing Machine | Shanta Engineering

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Shanta Engineering Presentation On…… Testing InstrumentsURL- http://www.tensiletestermanufacturer.com/

  2. Hand Operated Tensile Testing System • Hand Operated Tensile Testing System, the two column frame with a  hand wheel operated lead screw is a perfect tool for tension, compression and flexural testing of springs, rubber, paper, film etc., with apt attachments. These are appreciated for their durability, accuracy of results and high tensile strength. It is a better Tensile Tester Machine having variety of applications. • Features: • Table Top Model • Digital Display of load and Elongation. • Feather touche Key board operation. • Tare Facility for force and displacement. • Load display in Kg. Or Newton.

  3. Twin Column Universal Tensile Testing Machine • Shanta Engineering Universal Testing Machines are electro mechanical machines with digital display of load & displacement & pulley belt system for changing speeds. The machines are designed for testing various materials like rubber, plastics, cables, leather, paper, plywood and metals. Tension, compression, bend and flexural tests can be performed on these machines with suitable grips and fixtures. The machines are powder coated for elegant look. The critical components are plated for rust prevention and durability. Electronic Control Panel:Front panel membrane type keyboard for test set up • 7 segment digital display of load and displacement. • Storage of important parameters such as peak load, • braking • load and max. displacement • Facility to return of crosshead to home position for next test • Special Options:Load cells of different capacities are available as optional items • Displacement resolution of 0.1 mm is optional • Compression, Bending & flexural attachment to suit specific • tests is available as optional. • A.C. Variable speed is available as optional • P.C. interface is optional

  4. SPECIFICATIONS UTM TWIN COLUMN FIXED SPEED - BELT / PULLEY SYSTEM

  5. Single Column Universal Tensile Testing Machine • Shanta Engineering Single Column Universal Tensile Testing Machine are electro mechanical machines with digital display of load & displacement & pulley belt system for changing speeds. The machines are powder coated for elegant look. The critical components are plated for rust prevention and durability.  • Main Feature:Selection of different speeds by pulley belt system • Facility to mount different load cells. • Designed for testing various materials like rubber, plastics, cables, leather, paper, plywood and metals. • Special Options:Load cells of different capacities are available as optional items • Displacement resolution of 0.1 mm is optional • P.C. interface is optional.

  6. Electronic Tensile Testing Machine • We offer an extensive range of Electronic Tensile Testing Machine. These are manufactured with quality raw materials in accordance to the specifications given by the client. Our range is well known for easy installation and performance. These machines are used to perform tests on various materials like rubber, plastics, leather etc. We export these machines at competitive prices. • Special Options: • Variable Speed with the help of A.C. Drive Speed : 5 mm / min . to 100 mm / min. OR 30 mm / min. to 500 mm / min. • Variable Speed with the help of A.C. Servo Drive Speed : 1 mm / min. to 500 mm / min. Following changes can be offered on specific inquires: • Load cell of different capacities are available as optional items. • Displacement resolution of 0.1 mm is optional. • Compression, Bending & flexural attachment to suit specific tests are available as optional.

  7. Specification:
