Virtualization Explained | What Is Virtualization Technology? | Virtualization T

In this presentation on virtualization explained, we will understand what is virtualization technology and how it is helpful to us during professional as well as personal work. In this virtualization tutorial, we will understand how virtualization takes place and what software makes virtualization possible and manage different virtual instances, along with the benefits of virtualization.<br><br>The topics covered in this what is virtualization presentation are:<br>1. What Is Virtualization?<br>2. What Is a Virtual Machine(VM)?<br>3. Role and Types of Hypervisor<br>4. Types of Virtualization<br>5. Benefits of Virtu

Simplilearn
Télécharger la présentation

Virtualization Explained | What Is Virtualization Technology? | Virtualization T

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Meet Jake, he works as a SDE in an IT firm.

  2. Windows Linux To complete his projects he has to use different OS for working. Mac

  3. Click here to watch the video

  4. Windows Linux But, this often leads to different management issues due to multiple operating systems. Mac

  5. To overcome such an issue he decided to opt for Virtualization. What can Jake do to solve his problem?

  6. To solve such an issue he decided to implement Virtualization.

  7. To solve such an issue he decided to implement Virtualization. Let’s take a look at what is virtualization and how it is helpful to us.

  8. What’s In It For You ? • What Is Virtualization? • What Is Virtual Machine(VM)? • Role and Types of Hypervisor • Types of Virtualization • Benefits of Virtualization

  9. What Is Virtualization?

  10. What Is Virtualization? Virtualization creates a virtual layer using the hypervisor software, which manages resources assigned to the virtual instances. The newly formed virtual representation is known as virtual machines (VMs).

  11. Windows Host

  12. Unix Macux Linux Virtual Systems

  13. Hypervisor

  14. What Is Virtual Machine(VM)?

  15. What Is Virtual Machine(VM)? • Virtual machine is an emulation or a virtual presentation of a physical system. • They are also referred to as guest, whereas the physical system they run on is referred to as the host. Guest Unix Mac Linux Host

  16. Role of Hypervisor

  17. Role of Hypervisor • Hypervisor is a software that manages VMs. • It acts as an interface between VM and physical hardwareto ensure proper access to the resources needed for working. Hypervisor Hardware

  18. Types of Hypervisors

  19. Types of Hypervisors Hypervisor Type-1/Bare Metal Type-2

  20. Type-1 Hypervisor Guest OS Hypervisor Hardware

  21. Type-2 Hypervisor Guest OS VMM Host OS Hardware

  22. Types of Virtualization

  23. Types of Virtualization • Desktop Virtualization • Network Virtualization • Storage Virtualization • Application Virtualization

  24. Desktop virtualization • Desktop virtualization allows us to run multiple desktop OS in each VM. • Types of desktop virtualization: • Virtual desktop infrastructure (VDI) • Local desktop virtualization Virtual Environment

  25. Network virtualization • NV can combine multiple physical networks into one virtual, software-based network, or it can divide one physical network into separate, independent virtual networks. • Types of network virtualization: • Software-defined networking (SDN) • Network function virtualization (NFV) Virtual Network Workload Virtual network Network Protocols and devices Workload Virtual Network Virtual Network Workload

  26. Storage virtualization • Storage virtualization uses all the storage devices on the system to be accessed and be managed as a single storage unit. • The management and provision of storage are made by the software. • All the storage is formed in a shared pool from which they can be allotted to any VM on the system. Virtual Storage Pool Software Storage Units

  27. Application virtualization • Application virtualization runs software applications without installing them directly into the host’s OS. • Types of application virtualization: • Local application virtualization • Application virtualization • Server-based application virtualization

  28. Benefits of Virtualization

  29. Benefits of Virtualization Time management,setting up whole server from scratch can be avoided by using sufficient hardware devices for virtualization. Resource efficiency, using virtualization the maximum computing capacity can be utilized. Minimum downtime,application and OS crash cases can be neglected by running multiple VMs with the same OS.

  30. Join us to learn more! simplilearn.com UNITED STATES Simplilearn Solutions Pvt. Limited 201 Spear Street, Suite 1100 San Francisco, CA 94105 Phone: (415) 741-3319 INDIA Simplilearn Solutions Pvt. Limited #53/1C, 24th Main, 2nd Sector HSR Layout, Bangalore 560102 Phone: +91 8069999471 UNITED STATES Simplilearn Solutions Pvt. Limited 801 Corporate Center Drive, Suite 138 Raleigh, NC 27607 Phone: (919) 205-5565
