The Mathematics of Networks

Thomas avatar
Thomas
12 diapositives · 548 Views · Jan 20, 2012

The Mathematics of Networks. Chapter 7. Trees. A tree is a graph that Is connected Has no circuits. Tree. Tree. Tree. Not a Tree. Not a Tree: Has a circuit. Not a Tree: Has several circuits. Not a Tree. Not a Tree: Has no circuit, but is not connected. Not a Tree.

#trigonometry #geometry #reciprocal #statistics #analysis #differential #square #topology
The Mathematics of Networks - slide 1
01 / 12The Mathematics of Networks
1 / 17

Télécharger la présentation

The Mathematics of Networks
Une image / un lien ci-dessous est fourni (tel quel) pour télécharger la présentation

Politique de téléchargement : le contenu du site vous est fourni TEL QUEL pour votre information et votre usage personnel ; il ne peut être vendu, concédé sous licence ni partagé sur d’autres sites sans l’accord de son auteur.Le contenu vous est fourni TEL QUEL, pour votre information et votre usage personnel uniquement. Téléchargez la présentation en cliquant sur ce lien. Lors du téléchargement, si vous ne parvenez pas à télécharger une présentation, l’éditeur a peut-être supprimé le fichier de son serveur.Pendant le téléchargement, si vous ne parvenez pas à obtenir une présentation, le fichier a peut-être été supprimé par l’éditeur.

F I N

Plus de contenu associé

Transcription de la présentation

  1. The Mathematics of Networks Chapter 7

  2. Trees • A tree is a graph that • Is connected • Has no circuits Tree Tree Tree

  3. Not a Tree Not a Tree: Has a circuit Not a Tree: Has several circuits

  4. Not a Tree Not a Tree: Has no circuit, but is not connected

  5. Not a Tree Not a Tree: Has circuit, is not connected

  6. Properties of Trees Property 1: • If a graph is a tree, there is one and only one path joining any two vertices. • Conversely, if there is one and only one path joining any two vertices of a graph, the graph must be a tree X Two different paths joining X and Y make a circuit => Not a Tree Y

  7. Properties of Trees Property 2: • In a tree, every edge is a bridge. • Conversely, if every edge of a connected graph is a bridge, then the graph must be a tree. Tree: every edge is a bridge. If we erase any edge, the graph will be disconnected

  8. Properties of Trees Property 3: • A tree with N vertices must have (N-1) edges. • However, if a graph has N vertices and (N-1) edges, it will not be a tree always. The graph has 10 vertices and 9 edges, but not a tree because the graph is not connected

  9. Properties of Trees Property 4: • A connected graph with N vertices and (N-1) edges must be a tree Tree: Connected graph has 6 vertices and 5 edges

  10. Disconnected Graph • Graph with five vertices and less than four edges are disconnected

  11. Connected Graph • Graph with five vertices and four edges are – just enough to connect

  12. Not a Tree any more • Graph with five vertices and more than four edges are – circuits begin to form
