Biochemical Engineering CEN 551

1. Biochemical EngineeringCEN 551 Instructor: Dr. Christine Kelly Chapter 15: Medical Applications of Bioprocess Engineering

2. Schedule • Thursday, April 1: Dr. Hasenwinkel (hand out homework). • Tuesday, April 6: Finish chapter 15. • Thursday April 8: Review for exam 3 (Chap. 12, 14 and 15 homework due). • Tuesday, April 13: Exam 3 - chapters 12, 14, and 15 and posters due. • Poster Presentations: Saturday afternoon, April 17. • Oral presentations: April 15, 20, 22, 27.

3. April 15: Mittal, Sameer, Xu, Anitescu April 20: Meka, Chapeaux, Chang, Sayut April 22: Pasenello, Prantil, Lu, Menon April 27 Price, Reis

4. Presentations • Each student will have to answer written questions about each presentation. • Be sure to include the answers to these questions in your presentation. • WWT, Chromatography and Validation: provide me a list of questions that you will answer in your presentation.

5. Questions • What is the biological product? •  What is the application for the product? •  Is the product currently being produced commercially? •  What is the host cell that produces the product? •  What type of bioreactor is utilized? •  What types of downstream processes are utilized? •  What analysis did the author perform on the process?

6. Outline • Tissue Engineering • Gene Therapy • Bioreactors

7. What is Tissue Engineering? “The application of principles and methods of engineering and life sciences toward fundamental understanding of structure-function relationships in normal and pathological mammalian tissues and the development of biological substitutes to restore, maintain or improve tissue function” (Whitaker Foundation “Tissue engineering”).

8. Developing in vitro tissues based on cells derived from donor tissue. • Used in transplants. • Commercial examples: skin and cartilage. • Artificial liver outside the body is in trials. Uses hollow fiber reactor and pig liver cells. • Under development: liver, pancreas, kidney, fat, blood vessel, bone marrow, bone, neurotransmitter secreting constructs.

9. Skin Engineering

10. Introduction The term “artificial skin” was first introduced by JF Burke in 1987, and used to designate a bilayered dermal- epidermal replacementdevised by Burke and Yannas. Now it can be applied to several on bilayeredproducts that have been engineered for permanent replacementof lost human dermis and that provide either a temporary orpotentially permanent epidermis.

11. The Structure and Function of Skin

12. Skin Structure • Skin has two distinct layers • epidermis • keratinocytes • dermis • fibroblasts and collagen

14. Basic functions of skin • Thermoregulation. • Microbial defense (both mechanical barrier and immune defense). • Desiccation barrier. • Mechanical defense and wound repair. • Cosmetic appearance, pigmentation, and control of contraction.

15. Skin Response to Injury • Epidermal injury (first degree). • Superficial dermal injury (second degree). • Epidermal plus near-full to full dermal injury (third degree).

16. Surgical Management of Skin Loss Autograft (Split-thickness skin grafts) The best material for wound closure, when practical, is the patient’s own skin (autograft). Split-thickness skin grafts (epidermis plus a thin layer of dermis) harvested from the patient’s uninjured skin is essential for closure.

17. Several disadvantages of autograft • The donor site is a new wound. • The donor site is subject to scarring and pigmentation changes. • The dermis taken from the donor site is not replaced. • The donor site is a potential site for microbial entry. • The donor site cannot provide an unlimited supply of dermis. • The limited supply of donor sites on a patient.

19. Permanent Dermal Replacement

20. A few observations in designing a dermal replacement • The thicker the dermal layer of a split-thickness skin graft, the less the graft contracts. • Full-thickness skin grafts contract minimally. • Full-thickness dermal injuries heal by contraction and hypertrophic scarring, producing subepithelial scar tissue that is nothing like the original dermis. • Partial-thickness wounds with superficial dermal loss heal with less hypertrophic scarring.

21. The two artificial skins that currently exist have sought to meet these constraints in two different ways: • Integra, devised by Burke & Yannas, was designed by applying materials science and engineering principles to the problem of dermal replacement. • Bell’s product, which is being commercially named Apligraf was designed by applying the principles of tissue culture.

22. Artificial Skin as Tissue Regeneration Matrix

23. In order to promptly close the wound, the skin substitute had to… • Adhere to the substrate. • Be durable and sufficiently elastic to tolerate some deformation. • Allow evaporative water loss at the rate typical of the stratum corneum. • Provide a microbial barrier. • Promote hemostasis. • Be easy to use. • Be readily available immediately after injury. • Elicit a "regeneration-like" response from the wound bed without evoking an inflammatory, foreign-body, or non-self immunologic reaction.

24. Figure 1.Integra, the bilaminate artificial skin of Burke & Yannas, applied to a full-thickness skin defect.

25. Figure 2.Integra 1 week after application to a full-thickness skin defect.

26. Figure 3. Second-stage Integra grafting. At 2 weeks after Integra application, the process of neodermis formation is complete, the temporary silicone epidermal analog has been removed.

27. Figure 4. Second-stage Integra grafting. A meshed ultrathin autograft has been applied. The epidermal cells of the autograft proliferate and attach to the underlying neodermis, forming a durable and confluent epithelium.

28. Three limitations of Intagra • First, it has no intrinsic immunologic defenses and must be kept freeof bacteria. • Second, the silicone epidermal analog ispurely prosthetic and must be removed and replaced with epidermalautograft. • A third drawback is that Integra, although it is fairly strongand elastic, does not do particularly well on those areas such as the back, the axilla, and the groin because of shear stress.

29. Artificial Skin as a Pre-engineered Tissue Substitute

30. In contrast to the materials science and engineering approachof Burke & Yannas, Bell and colleagues took theapproach of reconstituting dermal injury by applying a preformedtissue. The resulting product is described as a dermal equivalent, which, unlike Integra, relies on living cells in tissue culture to organize the collagen network.

32. The drawback of Apligraf Inorder to provide definitive wound closure, an Apligraf-likeproduct would have to be constructed from a patient’sown fibroblasts and keratinocytes. The production of a patient-specificproduct (i.e. with fibroblasts and keratinocytes taken fromthe patient) would take several weeks, during which the woundwould have to be covered with a temporary skin substitute.

33. Dermagraft-TC Deramagraft-TC is a two-layer synthetic material designed as a temporary skin substitute. The outer layer is a silicone polymer, and the inner layer is a nylon mesh. Scanning electron micrograph of human dermal fibroblasts grown on a three-dimensional nylon scaffold (Dermagraft-TC).

34. Temporary Dermal Replacement Several new products available • Human cadaveric allograft • Biobrane • Dermagraf-TC or Transcyte

35. The Future of Artificial Skin • Materials science and engineering principles produced the dermalregeneration template Integra. • Application of tissue culture techniques producedApligraf.

36. In the future, a combination of materials science and tissueculture techniques is likely to produce a skin substitute thatcan function as an autograft for both dermis and epidermis. Althoughexpensive, the new approach has demonstrated the feasibility ofcombining Integratechnology with that of tissue engineeringand may be the forerunner of 21st-century skinreplacement.

37. Cartilage Engineering

38. Introduction Most peoples “Achilles heel” is not their achilles heel but their knees. The knee is not that simple, it is actually an interwoven system of ligaments, cartilage, and muscle.

39. Functions of the Components • Anterior Cruciate Ligament (ACL) : responsible for stabilizing and preventing excessive extension and lateral movements in the joint. • Posterior Cruciate Ligament (PCL) : responsible for stabilizing and preventing excessive flexion and lateral movements of the joint. • Medial Collateral Ligament (MCL) : provides stability against pressure applied to the leg that tries to bend the lower leg sideways at the knee, away from the other leg. • Lateral Collateral Ligament (LCL) : provides stability against pressure applied to the leg that tries to bend the lower leg sideways at the knee, toward the other leg. • Patellar Tendon : connects the knee cap to the tibia. • Meniscus (Lateral and Medial) : rest on the top of the tibia and provide a shock absorbing effect. • Articular Cartilage : Creates a low friction surface for the joint to glide on. Figure 1: The knee in flexion (bent)

40. Why does Articular Cartilage need to be Engineered? • Replacement of the articular cartilage is a necessity because “defects in mature articular cartilage do not heal without residues” (Reiss, Rudert, Schulze, and Wirth 141). • Meaning that the smooth surface that the joint normally glides across becomes rough in that area. This roughness leads to swelling, pain, and arthritis in the joint.

41. History of the Tissue Engineering of Cartilage Cells • In the early 1980’s the Hospital for Joint Diseases in New York started to develop a procedure to use the patients own articular cartilage cells to use as a transplant into the degeneration or defect in the articular cartilage. This was do to the poor results yielded by methods to repair the articular cartilage at that time. • Starting in 1987 the University of Goteborg and Sahlgrenska University Hospital in Goteborg, Sweden worked to continue the development of the new procedure. • October of 1994 the Swedish researchers published a study in the New England Journal of Medicine. “The Swedish researchers reported "good-to-excellent results" in 14 of 16 patients with a cartilage defect on the thigh-bone part of the knee treated at least two years earlier. The researchers said the vast majority of patients treated on the thigh-bone part of the knee had developed hyaline-like cartilage, similar to normal cartilage, where the defects had been” (Genzyme “The Carticel Treatment Alternative”). • The Harvard Health Letter rated this new technique as one of the "Top Ten Medical Advances of1994".

42. The Swedish Method The Swedish Method of Articular Cartilage Replacement

43. The Swedish Method The procedure is used on patients who suffer from defects in the articular cartilage on the bottom of the femur. Articular cartilage (chondral) defect before removing damaged articular cartilage.

44. If the defect the same type of defect as shown in Figure 2, the an Orthopedic Surgeon will perform an arthroscopic surgery, shown in figure 3, to collect the sample cartilage cells. • Arthroscopic surgery is a procedure where the surgeon makes three small incisions in the knee and works with specialized equipment in a relatively noninvasive procedure. Photograph of an Arthroscopic Surgery

45. In the first incision the arthroscopic scope, a device that utilizes fiber optics, is inserted to allow the surgeons to see what they are doing. • In another incision the actual surgical cutting tool is inserted. • In the final incision an irrigating instrument is placed to keep the visibility of the area high. • Figure 4 shows the basic position of each of these tools during an arthroscopic surgery. Arthroscopic Surgery Instrumentation

46. After the cells have been collected they are sent to the company Genzyme Tissue Repair in Cambridge, Massachusetts. • At the plant the new cells are grown, by a proprietary procedure, for a period of 2-4 weeks. • The cells grown are specific for the patient they were grown for. • After enough cells are grown they are shipped back to the Orthopedic Surgeon. • When the cells get back to the Orthopedic Surgeon a much more invasive open knee operation is performed.

47. In this new surgery first the damaged area of the articular cartilage is cut out leaving. Articular cartilage (surface) defect (circled in red) after removing damaged articular cartilage.

48. When the defected articular cartilage is gone the surgeon will lance off a small amount of Periosteum, a tissue that covers the bone, taken from the medial tibia. • The Periosteum is stitched over the hole where the defect was. • The surgeon will then inject the new cells under the flap. • Under the flap the cells do some additional growing and eventually connect to the surrounding tissues to form the new cartilage. • After the surgery each patient receives a post-operation schedule that is based on progressive program of weight-bearing, range of motion, and muscle strengthening exercises. Articular cartilage (surface) defect after periosteum patch is sewn in place.

49. Currently • Most of the information collect has not been updated since 1999 so it is hard to estimate the current number of surgeons that have been trained in this procedure and just how many patients have underwent the operation. • However, as of March 31, 1998, 2,238 surgeons had been trained in the procedure and a total of 1,271 patients had been treated since Genzyme Tissue Repair began marketing the product in 1995. • In 1999, the cost of the procedure ranged from $17,000 to $38,000, with an average cost of approximately $26,000 per procedure. • Genzyme Tissue Repair charged $10,000 per procedure for the cells. • The Orthopedic Surgeons in Sweden who have been using this procedure since its conception in 1987 have recorded anywhere from a 88% to almost a 100%, depending on the type of defect started with, improvement in the patients who they preformed this procedure on.

50. Future • The research into articular cartilage replacement has just about run its course with no major breakthroughs in the last five to ten years. • However, with the number of Orthopedic Surgeons being trained in this procedure increasing yearly the cost of the procedure should decrease while the relative safety will increase. • As for tissue engineering in general, there are still some problems that need to be worked through before the engineering of complex organs can begin. • The first issue is the complexity of the organ to be engineered. Skin and articular cartilage are both geometrically simple organs and thus getting the cells to line up in those formations are easy. To get the cells to line up properly and form a liver for example takes a degree of cell control not yet mastered. • Another issue being faced is the low blood flow through the organs. When these organs are being grown in the laboratory the blood supply to the organs is not yet sufficient enough for the inner cells of the thicker organs to survive.
