Modeling with Haskell

1. Modeling with Haskell Scientific Seminar 03/04 Gerhard Navratil

2. Contents • Functional Programming • Haskell • Modeling • Example

3. Functional Programming • “Everything is a function” • Parameters to result • Different from imperative programming – no side effects! Result Parameters Function

4. Key Elements • Recursion replaces loops • No side effects • No change of value (x = x+1) •  ‘Easy’ to read ‘Easy’ to test Mathematically clean

5. Constants and Test Data … are functions, too • Constants are constant functionse.g. pi = 3.1415927… • Test data are modeled as constants

6. Testing the Model • Imperative programming: Debugger • No Debugger necessary for functional programming! • Each function tested separately • No side effects  the function will always react like that • Never forget: Special cases (Div by Zero)

7. Haskell

8. The Syntax • Predefined typesBool, Int, Integer, Float, Double, Rational, Char, String, Pairs, Lists Maybe • Type of a functionname :: T1 -> T2 -> … Tn -> Tr • Implementation of a functionname v1 v2 … vn = res

9. Indentation matters! Examples • increment :: Int -> Intincrement x = x + 1 • Quadratic polynom:root :: (Float,Float,Float) -> (Float,Float) • root (a,b,c) = (x1,x2) where x1 = e + sqrt d / ( 2 * a ) x2 = e – sqrt d / ( 2 * a ) d = b * b – 4 * a * c e = - b / ( 2 * a )

10. Lists • List = Structure that holds any number of elements of the same type • List of Integers, Stings, Booleans, … • Strings are lists of characters • e.g. [1,2,3], [‘a’, ‘b’], [] • Building: 1 : [2,3]  [1,2,3]

11. Working with Lists: Recursion • sumList :: [Int] -> IntsumList [] = 0sumList (x:xs) = x + sumList xs • Usually hidden inside other functions: • head, tail, take • sumList x = head x + sumList (tail s) • length, reverse, ++ • 2nd order: map, filter, fold, zip

12. Example map Coding of texts: coding :: String -> [Int] coding s = map ord s coding “Navratil” [78,97,118,114,97,116,105,108]

13. Example filter Filtering numbers: filter_even :: [Int] -> [Int] filter_even ns = filter even ns filter_even [1,2,3,4,5] [2,4]

14. Example fold Summing up all numbers in a list: addAll :: [Int] -> Int addAll ns = foldl (+) 0 ns addAll [1,3,5] 9

15. Example zip Combining neighboring elements of a list: neighbors :: [Int] -> [(Int,Int)] neighbors x = zip (take (length x - 1) x) (tail x) neighbors [1,2,3] [(1,2),(2,3)]

16. Representation of Data • Type-synonymstype Name = Stringtype Year = Inttype Month = Inttype Dat = Int • User-defined data typesdata DayOfWeek = Mon | Tue | …data Birthday = B Year Month Daydata Employee = E Name Birthday

17. Using Data Types • n :: Namen = “Gerhard Navratil” • e :: Employeee = E n (B 1969 8 25) • hire :: Employee -> [Employee] -> [employee]hire e []

18. Parametrized Data Types • data List a = L a (List a) | Empty • li1, li2, li3 :: List Integerli1 = Emptyli2 = L 1 li1li3 = L 5 li2 • li3L 5 (L 1 Empty)

19. Polymorphism • Roots of the quadratic equationroots :: (Floating a) => (a,a,a) -> (a,a) • Length of a listlength :: [a] -> Intlength [] = 0length (_:xs) = 1 + length xs

20. Function Composition • Math: f (g (x)) = (g  f) (x) • Haskell: (g . f) xResult type of f = Parameter type of g • take (length x - 1) x(reverse . tail . reverse) x

21. Guards • Sign function: • sign x | x < 0 = -1 | x == 0 = 0 | x > 0 = 1

22. List Comprehension • [x | x <- [0 .. 100], odd x] • f xs ys = [x*y | x<-xs, y<-ys] • map f xs = [f x | x <- xs] • filter p xs = [x | x <- xs, p x]

23. Modeling

24. Algebraic Modeling • Set of sorts S • Set of Operators O • Set of Axioms for the operators

25. Example 2D Vector • sorts: Vec, Float • operations make: Float Float -> Vec getX: Vec -> Float getY: Vec -> Float add: Vec Vec -> Vec sub: Vec Vec -> Vec • axioms add a,b = make (getX a + getX b) (getY a + getY b)sub a,b = make (getX a – getX b) (getY a – getY b)

26. Example 2D Vector in Haskell class Vector vec where make ::Float -> Float -> vec getX, getY :: vec -> Float add, sub :: vec -> vec -> vec add a b = make (getX a + getX b) (getY a + getY b) sub a b = make (getX a – getX b) (getY a – getY b)

27. Instances • Connection between classes and data types • type V2 = (Float, Float)instance Vector V2 where make x y = (x,y) getX (x,y) = x getY (x,y) = y • Same procedure fordata V2_2 = V Float Float

28. Modeling is … • Defining elements • Combining elements • Until the model is as complete as we want it

29. Example Database

30. Database Elements • Have an identifier • Have attributes type Attrib = (String, String) class Objects o where object :: ID -> [Attrib] -> o getID :: o -> ID getAtts :: o -> [Attrib] getAttN :: String -> o -> String getAttN n o = (snd.head.filter((n==).fst).getAtts) o

31. Database • Put objects in the DB • Read objects from the DB • Change objects in the DB class (Objects o) => Databases d owhere empty :: d o getLastID :: d o -> ID insert :: [Attrib] -> [d o] -> [d o] select :: ID -> d o -> o …

32. Cadaster class (Databases c d, ListFuncs d) => Cadasters c d where inscribe :: c d -> d -> c d data2Doc :: c d -> d -> d formalTest :: c d -> d -> Bool register :: c d -> d -> c d test :: c d -> d -> Bool dbChanges :: c d -> d -> c d inscribe c d = if (formalTest c d) && (test rc nd) then dbChanges rc nd else c where rc = register c a nd = data2Doc rc a

33. Cadastral Requests class Cadasters c d => Requests c d where owner :: c d -> ID -> d documents :: c d -> ID -> [d]

34. Further Reading • Books: • Simon Peyton Jones: “Haskell 98 Language and Libraries”, Cambridge University Press, 2003, 272 pages. • Simon Thompson: “Haskell: The Craft of Functional Programming”, 2nd Edition, Addison-Wesley, 1999, 507 pages. • Richard Bird: “Introduction to Functional Programming using Haskell”, 2nd edition, Prentice Hall Press, 1998, 460 pages. • Tutorial texts are available on: www.haskell.org
