  1. TWS/Audit The Audit System for TWS z/OS Change History HORIZONT Software for Datacenters Garmischer Str. 8 D- 80339 München Tel ++49(0)89 / 540 162 - 0www.horizont-it.com

  2. TWS/Audit Change History TWS /Audit 7.3 TWS /Audit 7.2 TWS /Audit 7.1 TWS /Audit 7.0 TWS /Audit 6.4 TWS /Audit 6.3 TWS /Audit 6.2 TWS /Audit 6.1 / 6.0 TWS /Audit 5.1 TWS /Audit 5.0 TWS /Audit 4.1 TWS /Audit 4.0

  3. TWS/Audit 7.3 • Support of TWS for z/OS 9.1, including Runcycle Groups (Load module names end with F) • Support of TWS for z/OS 9.2 (Load module names end with G) • Shows date and time format behind the input fields • New summary statistics in the batch report TWS/Audit 7.3 has following new functions:

  4. TWS/Audit 7.3, summary statistics Job ’hlq.TWSAUDIT.V7R3M0.CNTL(OPAJGDB)’ has a new parameter: SUMMARY=NO/YES/ONLY YES/ONLY gives you in the PROTOKOL file statistics like: ======================================================== | SUMMARY REPORT | |======================================================| |Type |Insert |Delete |Update |Browse | |----------------------+-------+-------+-------+-------| |Workstations | 157| 137| 123| 0| |Calendars | 30| 27| 24| 0| |Periods | 102| 91| 48| 0| |Applications | 300| 254| 345| 0| |Operator Instructions | 30| 27| 6| 0| |Special Resources | 54| 47| 139| 0| |ETT Criteria | 24| 21| 12| 0| |JCL Variable Tables | 66| 59| 109| 0| |JS Changes | 1| 0| 0| 0| |LTP Changes | 0| 0| 1| 1| |Run cycle Groups | 19| 16| 7| 0| |----------------------+-------+-------+-------+-------| |Total | 783| 679| 814| 1| |======================================================| It is based on your selection criteria e.g. one day/week/month etc.

  5. TWS/Audit 7.2 • Support of TWS for z/OS 9.1, without Runcycle Groups (Load module names end with F) TWS/Audit 7.2 has following new functions:

  6. TWS/Audit 7.1 • TWS/Audit database options: • There is a new “ALL” Command to run the Restore line command for multiple TWS records (Restore by TWS/BatchAD) • CP Audit report: • Workstation name can be used as selection criteria to find workstation updates like changing the number of parallel server etc. • Date and time format check in the selection panel • MCP Audit: • Display the TWS update record of the manual CP modifications • Batch report for MCP (See extra presentation “TWSAudit - MCP.ppt”) TWS/Audit 7.1 has following new functions:

  7. TWS/Audit 7.1, ALL Command Command All R generates a Job to restore all of the list That works for all database objects (AD, WS, ETT etc.) Maybe you deleted e.g. some Special Resource definitions and you want to restore it. Line command R generates a Job to restore one of it

  8. TWS/Audit 7.1, WS change in CP Maybe you need to know, if the open intervals of a WS in the CP has been changed

  9. TWS/Audit 7.1, WS change in CP Yes, see the update timestamp and the WS intervals following

  10. TWS/Audit 7.1, MCP Change Data Line command T shows you the update record sent to TWS…

  11. TWS/Audit 7.1, MCP Change Data … and you can see the TWS CP data and in case of JCL modifications also the new JCL data which was written to TWS

  12. TWS/Audit 7.0 • Auditing of manual CP modifications (MCP dialog) with the option to add own comments, reason code and other order data. See extra presentation “TWSAudit - MCP.ppt” • Unification of some TWS/Audit field names in audit reports with names of TWS for z/OS TWS/Audit 7.0 has following new functions:

  13. TWS/Audit 6.4 • Support of TWS for z/OS 8.6 (Load module names end with E) • Support of operation User Fields also in CP (new in TWS for z/OS 8.5.1 with APAR PM14386) • ISPF dialog supports max. screen resolution 120x160 TWS/Audit 6.4 has following new functions:

  14. TWS/Audit 6.3 • New selection criteria: Owner Text (database, application) • Support of operation User Fields. (new in TWS for z/OS 8.5.1 with APAR PM14386) TWS/Audit 6.3 has following new functions:

  15. TWS/Audit 6.2 • The new selection criteria fields of the application common data like “Owner, Owner Description, Authority Group” are added for modules OPAIGDD and for batch module OPAIGDB, as well. The LRECL for DD GDBPRTO was changed from 80 to 160. • The ISPF dialog supports now screen resolution 62x160. Horizontal scrolling is implemented in result lists that require more than 80 bytes. • Previously missing substring fields for JCL Variable Tables were added. • The memory management in the CP-Audit program was improved to handle larger Current Plans. • Performance was improved by using better VSAM BUFFERSPACE values. TWS/Audit 6.2 has following new functions:

  16. TWS/Audit 6.1 / 6.0 • TWS/Audit Version 6.1 supports TWS for z/OS 8.5.1 (Load module names end with D) • TWS/Audit Version 6.0 supports TWS for z/OS 8.5.0 (Load module names end with C) and supports Virtual WS (APAR PK46296) • Migrating to a new TWS release no longer requires a conversion of the data base VSAM cluster. Data is converted “on the fly”. (The only needed change is to adapt jobs and dialog parameter member OPAXA) • The generated sample jobs work on JES3 systems • Parameter BR=Y/N was added to program OPAICPJ to support changes introduced with APAR PK27049 TWS/Audit 6.1 has following new functions:

  17. TWS/Audit 5.1 • TWS/Audit Version 5.1 is compatible to TWS for z/OS V8R3 (Load module names end with B) • “R”-Line command for TWS/BatchAD Generator allows selecting the “previous version” if the record was updated. • The Options Panel allows specifying a row limit for the dialog. TWS/Audit 5.1 has following new functions:

  18. TWS/Audit 5.0 • Tracks the JS file (JCL) • Tracks the LTP (Long Term Plan) • Generates TWS/BatchAD statements. • If a user has TWS/BatchAD, he can restore now all definitions, e.g. applications, resource definitions, ett, calendars etc. (Batchloader supports only application description) TWS/Audit 5.0 has following new functions:

  19. TWS/Audit 5.0 • Sample job OPAJSPLT is much faster • CP-Audit program OPAICP needs fewer resources (CPU, REGION, and EXCP) • Compatible to TWS for z/OS V8R2 with “WLM • SE Integration PTF • Dialog shows date for last processed tracklog record • Dialog allocates VSAM file JTWK only when it is really needed • Job OPAJUPD is needed to use existing VSAM from older releases

  20. TWS/Audit 5.0 JS Changes LTP Changes

  21. TWS/Audit 5.0 - JS Changes Selection Criteria

  22. TWS/Audit 5.0 - JS Changes Applications with changed JCL

  23. TWS/Audit 5.0 - JS Changes The JCL

  24. TWS/Audit 5.0 - LTP Changes Let's assume that a loop was caused by a modification made to the LTP. Let‘s see what was inserted into the LTP yesterday

  25. TWS/Audit 5.0 - LTP Changes Inserted applications

  26. TWS/Audit 5.0 - LTP Changes Application was added manually (ISPF dialogue)

  27. TWS/Audit 4.2 + 4.1 TWS/Audit 4.1 + 4.2 got following additional functions: • Support for TWS 8.2 • Supports multiple planning periods within one tracklog file (e.g. one extend, one replan, another replan etc.) • Improved CP dialog

  28. TWS/Audit 4.0 TWS/Audit 4.0 tracks all changes made to the CP for following objects • Occurrences • Operations • Dependencies • Special Resources

  29. Why not using EQQAUDIT? Why not using EQQAUDIT?

  30. EQQAUDIT EQQAUDIT is a TWS sample program, which is part of every TWS installation, but: • Output is difficult to read • Output is incomplete EQQAUDIT:This is an inserted operation

  31. TWS/Audit for the CP - Output This operation was added to the current plan TWS/Audit for the CP: • Output is easy to read • Output is complete

  32. TWS/Audit for the CP - Advantages TWS writes modifications into the JT file and EQQTROUT. Some facts: • JT file is unreadable • EQQTROUT is unreadable • EQQAUDIT is not complete, it shows only key values • TWS/Audit shows all modifications • Readable • Complete

  33. TWS/Audit The Audit System for TWS z/OS Many thanks for your attention HORIZONT Software for Datacenters Garmischer Str. 8 D- 80339 München Tel ++49(0)89 / 540 162 - 0www.horizont-it.com
