  1. SETTING DWELL AUTO 2

  2. DWELL • TIME IN DEGREES THAT POINTS ARE ____________. • MAXIMUM DWELL FOR A 4 CYLINDER? • MAXIMUM DWELL FOR AN 8 CYLINDER? • MAXIMUM DWELL FOR A 6 CYLINDER?

  3. DWELL & TIMING • WHEN YOU CHANGE DWELL, YOUR TIMING WILL CHANGE. • WHEN YOU CHANGE TIMING, DWELL IS NOT AFFECTED. • ALWAYS SET DWELL BEFORE TIMING.

  4. DWELL & TIMING QUESTION • WE HAVE A CAR WITH THE TIMING SET AT 10 DEGREES BTDC. • THE DWELL ON THIS CAR IS SET AT 30 DEGREES. • A TECHNICIAN CHANGES THE DWELL TO 35 DEGREES. • NOW THE TIMING IS SET AT? • A. 10 DEGREES BTDC • B. 15 DEGREES BTDC • C. 5 DEGREES BTDC • D. 0 DEGREES BTDC • E. 5 DEGREES ATDC • F. 7.5 DEGREES BTDC THINGS TO REMEMBER TIMING IS MEASURED AT THE CRANK DWELL AT DISTRIBUTOR DIST. IS HALF SPEED OF CRANK
