Enhancing Graphical Data Representation: Maximizing Data-Ink and Erasing Chartjunk

In this first part of the theory on data graphics, we explore the importance of maximizing the data-ink ratio, as highlighted by Tufte. Key principles include showcasing data above all, minimizing non-data ink, and revising to achieve a data-ink ratio of 1. Tufte tests these principles with diverse examples, demonstrating effective designs that enhance legibility. Furthermore, we discuss the concept of chartjunk and the value of multifunctioning graphical elements, emphasizing the need for clarity in visual data representation.

aldan
Télécharger la présentation

Enhancing Graphical Data Representation: Maximizing Data-Ink and Erasing Chartjunk

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Theory of Data Graphics • Part 1 Most of a graphic’s ink should vary in response to data variation (see chapters 4-6)

  2. Chapter 4 - Data-Ink Ratio • Data Ink is the ink on a graph that represents data.  Tufte claims that good graphical representations maximize data-ink and erase as much non-data-ink as possible.  • Data-Ink Principles: 1. Above all else show data. 2. Maximize the data-ink ratio. 3. Erase non-data-ink. 4. Erase redundant data-ink. 5. Revise and edit

  3. Data-Ink ratio of 1 Tufte tests these principles on a whole range of examples to come up with a wide range of fresh designs that dramatically improve the legibility of the graphs.  Here is an example with a very high data-ink ratio.  It’s an electroencephalogram – a graph that records the electrical activity from the brain.  This graph would have a data-ink ratio of 1.

  4. CH. 5 - Chartjunk • Moiré vibration 123 • Grids 1vs2 • Ducks (self-promoting graphs that are used to demonstrate the graphic ability of the designer rather than display the data.)

  5. Worst chart ever?   “A series of weird three-dimensional displays appearing in the magazine of American Education in the 1970’s delighted the connoisseurs of the graphically preposterous.  Here five colors report, almost by happenstance, only 5 pieces of data (since the division within each adds to 100%).  This may well be the worst graphic ever to find its way into print.” See page 118.

  6. Chapter 6 – Data-Ink Maximization • See chart redesign pages 127-128

  7. http://mindprod.com/image/math/livinghistogram.jpg

  8. Multifunctioning Graphical Elements • “The same ink should often serve more than one graphical purpose” (139) • Graphical element may carry data information and also perform a design function • Element that locates or plots the data is the data measure • , also pg. 144 “road stripes”

  9. Multifunctioning Graphical Elements Data-Based Grids • Grid reports directly on the data • Sometimes it’s better to make the coordinate labels into the actual data points themselves. (this strategy eliminates the need to perform eye-work) • example • Generally works better for smaller data sets

  10. Multifunctioning Graphical Elements Puzzles and Hierarchy in Graphics • Complexity of the elements can sometimes turn the graphic into a visual puzzle • How to recognize: Graphic must be interpreted through verbal rather than visual process • See page 153
