Chapter 6: Designing Interface Components

1. Chapter 6: Designing Interface Components

2. Interface Components • Interface components is a term for all the supporting elements of a page’s content. • Lists • Menus • Forms • Tables • This chapter focuses on using proper, valid XHTML to create these components and how to properly design them to integrate well into a webpage.

3. Tables • Tables had a designated purpose when they were first developed– laying out grids of data in rows and columns à la Microsoft Excel. <table border=“1”> <tr> <td>&nbsp;</td> <td>Stylin’</td> <td>Codin’</td> </tr> <tr> <td>Languages</td> <td>XHTML &amp; CSS</td> <td>PHP &amp; SQL</td> </tr> <tr> <td>Focus</td> <td>Interface Design</td> <td>Back-end Code</td> </tr> </table>

4. Tables • Make it more accessible for the visually impaired by adding scope definitions to each table header (whether the header relates to a row or a column). <table class=“basic_lines” summary=“My Books”> <caption> <strong>My Books</strong> </caption> <tr> <th scope=“col”>&nbsp;</th> <th scope=“col”>Stylin’</th> <th scope=“col”>Codin’</th> </tr> <tr> <th scope=“row”>Languages</th> <td>XHTML &amp; CSS</td> <td>PHP &amp; SQL</td> </tr> <tr> <th scope=“row”>Focus</th> <td>Interface Design</td> <td>Back-end Code</td> </tr> </table> table.basic_lines { width:300px; border-top:3px solid #069; } Link to example

5. Tables • Further define the style of the table by adding lines around the rows. body { font: .8em verdana, sans-serif; } table.basic_lines { width:300px; border-collapse:collapse; /* Removes space between the cells */ border-top:3px solid #069; } table.basic_linesth { border-bottom:2px solid #069; } table.basic_lines td { border-bottom:1px solid #069; } table.basic_lines caption { margin-bottom:6px; } table.basic_lines td, table.basic_linesth { padding:5px 3px; } Link to example

6. Tables • Add some background color, and we have a nicely styled way to display rows of data. body {font: .8em verdana, sans-serif;} table.basic_lines { width:300px; border-collapse:collapse; border-top:3px solid #069; } table.basic_linesth { border-bottom:2px solid #069; background-color:#CCFFCC; } table.basic_lines td { border-bottom:1px solid #069; background-color:#FFFFCC; } table.basic_linesth[scope=“col”] { background-color:#99CCCC; } table.basic_lines td, table.basic_linesth { padding:5px 3px; border-bottom:1px solid #069; } Remember pseudo-classes? Link to example

7. Forms • A vital part of nearly every website is some type of form– login page, e-commerce checkouts, etc. • In XHTML, it’s useful to use “label” to define what each input type does. • Input Box  Simple text box. • <label for=“user_name”>User Name</label> • <input type=“text” name=“user_name” id=“user_name”/> • Password Box  Text box, but will encrypt your type on the screen. • <label for=“password”>Password</label> • <input type=“password” name=“password” id=“password” /> • Text Area  Large text box. • <label for=“desc”>Description</label> • <textarea id=“desc” name=“desc” rows=“3” cols=“14”>Enter description</textarea>

8. Forms • Radio Buttons  Allow one choice to be made. • <input type=“radio” id=“radio1” name=“radioset” value=“choice1” checked=“checked” /> • <input type=“radio” id=“radio2” name=“radioset” value=“choice2” /> • Check Boxes  Allow multiple choices to be made. • <input type=“checkbox” id=“check1” name=“checkset” value=“1” /> • <input type=“checkbox” id=“check2” name=“checkset” value=“2” /> • <input type=“checkbox” id=“check3” name=“checkset” value=“3” /> • Select Box  Drop-down box with multiple selections. • <select id=“choices” name=“choice”> • <option value=“0”>Choose something</option> • <option value=“1”>Option One</option> • <option value=“2”>Option Two</option> • </select> • Submit / Reset Button  Submits / Resets the form. • <input type=“submit” value=“Submit This Form” /> • <input type=“reset” value=“Reset This Form” /> Link to example * In the example I added div’s and labels. Consider doing this for styling purposes. You can see a stylized version of my example here.

9. Forms • A handy tool for any modern site is the tiny login. • Lets put it in our two-column page on the left side navigation bar. Link to style sheet. Link to example

10. Lists and Menus • A list is a group of related text items. • Ordered / unordered / definition. • A menu is a list that offers navigation choices. • Lists • Unordered  Bulleted by default. Can change to hollow circle, etc. • Ordered  Numbered by default. Can change to Roman Numerals, etc. • Definition  Nested list that contains sub items.

11. Lists and Menus Unordered <ul> <li>Choice 1</li> <li>Choice 2</li> </ul> Ordered <ol> <li>Choice 1</li> <li>Choice 2</li> </ol> Definition <dl> <dt>XHTML</dt> <dd>A mechanism…</dd> <dt>CSS</dt> <dd>A mechanism…</dd> </dl>

12. Lists and Menus • A menu, ultimately, is a list of choices. All menus are lists and should be styled as such for greatest compatibility within different browsers. • Let’s start with a simple list and turn it into a menu. <div class=“listcontainer”> <ul> <li>Gibson</li> <li>Fedner</li> <li>Rickenbacker</li> <li>Ibanez</li> </ul> </div> body { font:1.0em verdana, arial, sans-serif; } div#listcontainer { border:1px solid #000; width:160px; font-size:.75em; margin:20px; } Link to example

13. Lists and Menus • We’ll turn the borders on and the bullets off to make it more like a menu. body { font:1.0em verdana, arial, sans-serif; } ul {border:0; margin:10px 30px 10px 1.25em; padding:0; list-style-type:none;} li {border-bottom:2px solid #069; margin:0; padding:.3em 0; text-indent:.5em} div#listcontainer { border:1px solid #000; width:160px; font-size:.75em; margin:20px; } Link to example

14. Lists and Menus • Enclose the list, convert it into a menu (add links). body { font:1.0em verdana, arial, sans-serif; } ul {border:0; margin:10px 30px 10px 1.25em; padding:0; list-style-type:none;} li {border-bottom:2px solid #069; margin:0; padding:.3em 0; text-indent:.5em;} li:first-child {border-top:2px solid #069;} div#listcontainer a {text-decoration:none; color:#069;} div#listcontainer a:hover {color:#00;} div#listcontainer { border:1px solid #000; width:160px; font-size:.75em; margin:20px; } Link to example

15. CSS Menus • CSS menus are one of the highly sought-after code snippets in CSS. <div id=“multi_drop_menus”> <ul> <li><a href=“#”>Item 1</a></li> <li><a href=“#”>Item 2</a></li> <li><a href=“#”>Item 3</a></li> </ul> </div> • The CSS is rather long and complex and won’t fit on the PowerPoint, but we can outline a bit about how we want this to work. • First set the list elements side-by-side. • Style the list elements so they have a nice background color and a border. • Upon hovering the mouse over the list elements, have more elements be displayed under the one you’re hovering over. • When the mouse is not hovering over the original list elements or the displayed list elements, hide the displayed elements. Link to example

16. More Information • http://www.w3schools.com/css/ Tutorials, reference guides, advanced scripting. • http://safari.oreilly.com  Many good online books on CSS and other web design techniques. • Wyke-Smith, Charles. Stylin' with CSS : A Designer's Guide. Grand Rapids: New Riders, 2007.
