  1. 学习情景7 发动机的冷却系统

  2. 7.2.2 冷却系的水路 水冷系的水路是：水泵由散热器出水软管将经过散热器冷却了的冷却液吸入并加压，使之经分水管流入气缸体水套和气缸盖水套，吸热升温后，经节温器及散热器进水软管进入散热器内散热冷却。随之，又被水泵吸入，如此，在水泵作用下不断强制循环流动。
