1. Aspect Oriented Programming Carlos Oviedo Secure Systems Research Group

2. Introduction • Late 90’s PARC (Palo Alto Research Center) • Object Oriented Programming & Meta-object modeling protocols • Capture cross-cutting concerns • AspectJ  Java • Under constant development

3. Cross-cutting concerns • Not encapsulated by imperative object oriented programming languages (C, C#, Java, Pascal. Etc) [Cac04]

4. Cross-cutting concerns • Sometimes requirements relating to a particular concern are spread among multiple requirement sources. • Example: Logging • The consequence  Code spread across several modules

5. Cross-cutting concerns A specific concern spread along multiple classes

6. Cross-cutting concerns • Security is a concern that has impact on each design unit. • Modifying the affected design units accordingly can be fault prone and a tedious task. • Other examples: • identity management • transaction integrity • authentication • performance

7. Aspects Outline • Cross cutting concerns are not reusable (cannot be refined or inherited) • AOP  Modularizes cross cutting concerns • Pointcut (dynamic) • Advice (dynamic) • Inter-type declarations (static) • Aspects (encapsulates constructions)

8. Aspects Outline JOIN POINT: • A specific execution point in the program flow POINT CUT: • Selects certain join points and values at those points

9. Point Cuts • Call join point  actions of an object receiving a call pointcut move(): call(void FigureElement.setXY(int,int)) || call(void Point.setX(int)) || call(void Point.setY(int)) || call(void Line.setP1(Point))|| call(void Line.setP2(Point));

10. Advices • To implement the cross cutting behaviors we use advices before(): move() { System.out.println("about to move"); } after() returning: move() { System.out.println("just successfully moved"); }

11. Aspects • Aspects are wrappers • Very similar to “object oriented” classes aspect Logging { OutputStream logStream = System.err; before(): move() { logStream.println("about to move"); } }

12. Aspects in security • Example: Control access to a specific resource  Account access by a bank officer

13. Aspects in security public aspect AccountAuthorization { OutputStream logStream = System.err; boolean grantAccess(string id){ if(id != “guest”) return true else return false; } Pointcut change(): call(void Account.MakeWithDrawal()); before(): change(){ logStream.println("Change in progress..."); if(!grantAccess(context.id)) throw new UnauthorizedAccessException(); } }

14. Aspects in security Pointcut change(): call(* MakeWithdrawal(..));

15. Aspects in security abstract aspect SimpleAuthorization{ OutputStream logStream = System.err; public static boolean grantAccess(string id) { if(id != “guest”) return true else return false; } abstract pointcut change(): call( * Make*(..)); before(): change() { logStream.println("Change in progress..."); if(!grantAccess(context.id)) throw new UnauthorizedAccessException(); } }

16. Aspects in security • A specialization of the aspect: public aspect TransactionAuthorization extends SimpleAuthorization { pointcut change(): within(Transaction) || within(SecureTransaction); //... }

17. Conclusions • Aspects are capable abstract structures to capture cross cutting concerns such as security and can be applied to a system after it has been written. • Security concerns can be maintained in one place • Another example : track who did what on a system  Non-repudiation • Currently this field is under constant expansion and it is worth to exploring its potential due its ability to encapsulate concerns

18. AOP: Aspect Oriented Programming Theserverside.com
