  1. Facilities Based Networking Corporation for Education Networking Initiatives in California (CENIC)

  2. Charter Associates • California Institute of Technlogy • California State University • Stanford University • University of California • University of Southern California

  3. Mission Statement Facilitate and Coordinate the: Development, Deployment, Operations of a set of seamless and robust advanced network services. CENIC’s networks support advanced applications designed to enhance California’s leadership in research and education.

  4. CalREN-DCDigital California • IP based network: OC-48 • Serves 140 Higher Ed institutions, 8,000+ Elementary, Secondary and High Schools • 8.0 million+ student, faculty & staff users • Internet2 connectivity and commodity ISP services

  5. CalREN-HPRHigh Performance Research • IP based network, 10Gb Ethernet • 50+ Research institutions, National Laboratories and San Diego Super Computing Center • California component of Internet2 with 10G and OC-12 connections • Serves hundreds of researchers

  6. CalREN-XDExperimental/Development Network • 10Gb wavelengths (OC-192c or 10G LANPHY) and dark fiber • Point-Point, Point-MultiPoint 1G Ethernet possible • Serves network researchers in California Research institutions • Four UC Institutes, USC/ISI, Stanford and CalTech

  7. CalREN Optical Footprint

  8. Northern California

  9. Southern California

  10. National Light Rail • Dark Fiber National footprint • Serves very high-end Experimental and Research Applications • 4- 10.0 GB Wavelengths initially • Partnership

  11. NLR “Service Offerings” • Point-to-Point wave (OC-192c or 10GE) • No wave can interfere with others • Shared IP service • Must be able to tolerate outages • Supports experimental code • Switched Ethernet service • Delivered as gigabit Ethernet • Point-to-point or point-to-multipoint

  12. 15808 Terminal, Regen or OADM site (OpAmp sites not shown) Fiber route NLR Footprint and Layer 1 (15808s) Topology SEA POR SAC BOS NYC CHI OGD DEN SVL CLE WDC PIT FRE KAN RAL NAS STR LAX PHO WAL ATL SDG OLG DAL

  13. National Light Rail Lambda & Route Map TERMINAL REGEN OADM Metro 10 Gig E 4 Seattle Chicago Boise Ogden Denver Kansas Cleveland 4 2 4 4 6 (OC192) 2 6 4 Salt Lake City Portland StarLight 2 5 Boston Pittsburgh 2 Sacramento Sunnyvale 15808 LH System 2 15808 ELH System 4 4 Fresno 15540 Metro System 4 4 10 Gig E New York City Washington DC OC192 4 Los Angeles 2 4 4 2 Stratford 4 San Diego 4 4 Walnut Nashville Pheonix Olga Dallas Atlanta Raleigh 4

  14. NLR POP Architecture Long Haul OC48/OC192/10GigE DWDM NLR DWDM 10 Gig E or OC192 Gig E

  15. Campus or Metro Interconnect One of above options used for Each campus Calren/DC/HPR/NLR PoP Architecture CalRen DC HPR NLR Long Haul OC48/OC192/10GigE DWDM DWDM 10 Gig E or OC192 Gig E CalREN/DC HPR NLR 15500
