  1. Kinect Introduce 2012 Seung Heon Kang

  2. Kinect Introduce • Motion sensing device • Natural user interface using gestures and spoken commands

  3. History • Technical invented by Zeev Zalevsky, Alexander Shpunt, Aviad Maizels and Javier Garcia (2005) • Project Natal (June 1, 2009) • Kinect (November 4, 2010) • First release of Kinect SDK (June 16, 2011) • Release of Kinect SDK v1.0 Beta2 (November 1, 2011) • Release of Kinect for Windows SDK (February 1, 2012)

  4. Structure

  5. Features • Field of View • Horizontal field of view : 57 degrees • Vertical field of view : 43 degrees • Physical tilt range : ±27 degrees • Data Stream • 320X240 16-bit depth @ 30 frames/sec • 640X480 32-bit color @ 30 frames/sec • 16-bit audio @ 16kHz

  6. Features • Skeleton tracking system • Tracks up to 6 people, including 2 active players • Tracks 20 joints per active player • Audio System • Echo cancellation system enhances voice input • Speech recognition in multiple

  7. NUI Library • Natural User Interface

  8. NUI Library

  9. Color Image Data • Resolution 640x480, fps 30 • Resolution 1280x960, fps maximum 12 • 4Byte per Pixel • RGB color • YUV color

  10. Depth Image Data • Resolution 320x240 fps 30 • Resolution 640x480 fps 30 (upsampling)? • 2Byte per Pixel • Real depth 13bit 0~8192 • Player 3bit

  11. Depth Image Data • Measure distance • Default Mode 800 ~ 4000 mm • Near Mode 400 ~ 3000 mm

  12. Skeleton Data • Using depth image • Make joint points • 3D points • Float x • Float y • Float z • Float w

  13. How to Skeleton Tracking Divide by Background DepthMap Distinguish Create Recognize

  14. Skeleton Data • Skeleton data of the players detects 6 players • Get skeleton data 2 players
