  1. SubSystems Total Embedded Solutions

  2. Agenda • SSD Background • Embedded Products • MIPS based processor products • I/O cards • Memory Products

  3. SSD Background • Second Oldest Product Line in IDT • Formed over 15 years ago • Traditionally - Memory Based Business • Standard Products - SIMMs, ZIPs, DIPs, MLMs • Recently - L2 Cache Volume Supplier • Volumes of ~1KK units/qtr • Today - Focus on Two Areas • PCI Based Embedded Solutions • Strengthen Position in Memory Module Market

  4. SubSystems Product Families

  5. Processor Products • Common bus CPU Card (C3) • Common MIPS R4xxx/R5xxx 64-bit bus interface • Wide range of performance options in single socket • No redesign for higher performance/next generation processor • CompactPCI Products • Designed to provide high performance I/O processing • 6U Form Factor with 2 PMC Slots • VxWorks Board Support Package • PCI Mezzanine Card (PMC) • Complete processor subsystem • RV4640/RC64V474 supported • On board DRAM, FLASH, serial channels

  6. CPU - C3 Products • Features • Common R4xxx/R5xxx 64-bit bus interface • Low Profile connector • On-board L2 cache options • On-board Clock and Reset circuitry • Benefits • Wide range of performance options in single socket • No redesign for higher performance/next generation processor

  7. C3 Product Family 7M95xx 64600 based 7M9522 ‘5000 + 1M L2 7M9521 ‘5000 + 512K L2 7M9523 ‘575 based Performance 7M9520 ‘5000 based 7M9519 ‘475 based 7M9516 ‘4700 based 7M9518 ‘4650 based

  8. CPU - CompactPCI Products • 32-bit family • 7M9532/33/34 • 64-bit family • 7M9535/36/37/38 • Benefits • Off-loads I/O processing from CPCI Host processor - improving system performance • Complete board subsystem improving time to market

  9. CPU - CompactPCI Products • Current Features • C3 Processor Card • Two PMC Slots • Front Panel I/O • GT-64120 • 75 MHz Processor bus support • 75 MHz SDRAM support • 64 bit PCI support • Transparent PCI bridge (Intel 21154) • VxWorks BSP

  10. CPU - CompactPCI Products • Next Generation Features • C3 Processor Card • Two PMC Slots • Front / Rear Panel I/O support • On-board Ethernet support • GT-64120A • 100 MHz Processor bus support • 100 MHz SDRAM support • 64 bit PCI support • “Drawbridge” PCI bridge (Intel 21554) • VxWorks BSP

  11. CPU - PMC Products • Features • PMC based processor card • Single PMC Form Factor • RV4640/RC64V474 supported • On-board DRAM/Flash • Dual Serial Channels (16550A) • Host to PCI bridge • 66MHz PCI support • VxWorks BSP

  12. CPU - PMC Products • RV4640 based family • 7M9510 - GT64011/FPGA - User I/O • 7M9511 - GT64111/No User I/O • RC64V474 based family • 7M9514A - GT64111/FPGA - User I/O • Benefits • Complete MIPS based single board computer • Ideal for low profile system applications (“pizza box”) - e.g. Enet/ATM switches

  13. PMC CPU Product Family 7M9510 ’4640/64011 7M9511 ’4640/64111 7M9511A ’4640/64144 7M9514 ’474/64011 7M9514A ’474/64144 7M95XX ‘5000/64145 7M9512A 32364/32134 FPGA based 7M9512B 32364/32134 CPLD based

  14. I/O Products

  15. Memory Products • Asynchronous • JEDEC standard 64 pin & 72 pin modules • Densities from 64K x 32 to 2M x 32 • 3.3V and 5V versions supported • Synchronous / ZBT • Densities from 64K x 36 to 512K x 72 • Flow thru and Pipeline versions supported • Low profile, Board to Board mounting options • MCM • 128K x 24 and 2 x 64K x 16 • Speeds to 10ns • Ideal memory for DSP applications

  16. SRAM ModulesSynchronous and ZBT™ x36 Family Density Part Number Speed Package 128K x 36 7MPV4161 9ns FT 144 SO-DIMM 256K x 36 7MPV4162 9ns FT 144 SO-DIMM 512K x 36 7MPV4163 11ns FT 144 SO-DIMM x64/72 Families Density Part Number Speed Package 128K x 64 7MBV4150 100MHz 160 FH BTB 256K x 72 7MBV4151 100MHz 160 FH BTB 256K x 72 ZBT 7MBV4152 100MHz 160 FH BTB 128K x 72 7MPV4171 9ns FT 168 DIMM 256K x 72 7MPV4172 9ns FT 168 DIMM 512K x 72 7MPV4173 11ns FT 168 DIMM

  17. SRAM ModulesAsynchronous Multichip Modules Density Part Number Speed Package 128K x 24 7MMV4101 10ns 119 BGA 64K x 16 x 2 7MMV4103 10ns 121 BGA 3.3V x32 Family Density Part Number Speed Package 128K x 32 7MPV4060 12ns 72 SIMM 256K x 32 7MPV4145 15ns 72 SIMM 512K x 32 7MPV4135 15ns 72 SIMM 1M x 32 7MPV4120 15ns 72 SIMM 2M x 32 7MPV4130 15ns 72 SIMM 5V x32 Family Density Part Number Speed Packages 128K x 32 7MP4095/4060 15ns SIMM, ZIP 256K x 32 7MP4045/4145 15ns SIMM, ZIP 512K x 32 7MP4135 15ns SIMM, ZIP 1M x 32 7MP4120 15ns SIMM, ZIP 2M x 32 7MP4130 15ns SIMM

  18. Specialty Memory Modules Pentium Processor Standard Part Number Size and Speed COASt 3.1 7MPV6202/03SA66M 256KB/512KB – Pipelined Burst 7MPV6273/74SA66M 256KB/512KB – Pipelined Burst (with resistors) 7MPV6293SA66M 512KB – Pipelined Burst (single bank) 7MPV6294SA66M 512KB – Pipelined Burst (single bank with resistors) PowerPC Processor Platform Part Number Size and Speed CHRP 7MPV6255/56/66S83M 256KB/512KB – Pipelined Burst Dual-Port Family Density Part Number Speed Package 64K x 8 7M1001 35ns DIP 128K x 8 7M1003 35ns DIP 16K x 32 7M1002 30ns PGA 32K x 32 7MP1015 25ns DIMM 64K x 32 7MP1016 25ns DIMM
