    1. Tic-Tac-Toe By K. Krishna Chaitanya Ankit C. Master Department of Electrical and Computer Engineering University of Tennessee, Knoxville

    2. This Project deals with the implementation of Tic-Tac-Toe game on the Spartan – III kit. The logic of the game is encoded using VHDL in order to implement it on the board. The game is played between a player and the computer. This project utilizes a data path to accept input from the user. This unit then synthesizes the next move (based on the current input and previous states) and generates the desired output output.
