  1. Adding BPEL feature normal process (ForEach as an example)

  2. Pre-implementation • Design discussion Input: test matrix, design discussion slides design discussion slides: • Issues unclear in spec • Any critical implementation note

  3. Implementation • BPEL schema • Might need to add missing complex types in existing bpel schema : C:\Alaska\root\sharedlibrary\bpelmodel\src\com\sun\bpel\model\visitor\wsbpel_main.xsd

  4. Implementation -- cont • Add static BPEL model support root/sharedlibrary/bpelmodel/src/com/sun/bpel/model/visitor AbstractVisitor.java,1.5 CloneVisitor.java,1.4 DefaultXmlParserFactory.java,1.10 SAXParseVisitor.java,1.5 wsbpel_main.xsd,1.5 root/sharedlibrary/bpelmodel/src/com/sun/bpel/model BPELDocument.java,1.6 root/sharedlibrary/bpelmodel/src/com/sun/bpel/model/impl BPELDocumentImpl.java,1.6 ForEachImpl.java,1.2

  5. Implement -- cont • Add Runtime model support root/jbi/bpelse/core/src/com/sun/jbi/engine/bpel/core/bpel/model/runtime ActivityUnitFactory.java,1.23 root/jbi/bpelse/core/src/com/sun/jbi/engine/bpel/core/bpel/model/runtime/impl/messages Bundle.properties,1.3 root/jbi/bpelse/core/src/com/sun/jbi/engine/bpel/core/bpel/model/parser/impl RBPELDocumentImpl.java,1.16 RXmlParserFactoryImpl.java,1.16 root/jbi/bpelse/core/src/com/sun/jbi/engine/bpel/core/bpel/model/meta/impl RForEachImpl.java,1.9

  6. Implementation -- cont • Add ActivityUnit and any other necessary changes root/jbi/bpelse/core/src/com/sun/jbi/engine/bpel/core/bpel/model/runtime/impl ForEachUnitSerialImpl.java,1.2 ScopeUnitImpl.java,1.18

  7. Test Cases • Pick significant test cases from test matrix • Add bpel, wsdl into testnb5/bpel project or create a new project • Create test properties/input/output using project system or manually • EM simulator is better when you want to send soap messages not constrained by test cases.
