  1. Air Pollution ControlSource Testing

  2. Source Testing (Stack Sampling) • why? • methods of determining ER • source testing • sampling train • process of sampling (PM) • location of sampler, probe • calculating ER • is it isokinetic?

  3. Why Sample Stack? • need ER

  4. Methods of Determining ER • Mass Balance/ Engineering Calculations • if (mass in) > (mass out) then mass loss → • evaporation rate, chemical kinetics

  5. Methods of Determining ER • Emission Factors (in kg/Mg lime produced)

  6. Methods of Determining ER • Source Testing • quantify process η • C of A • test APCD • calibrate CEM • Ontario Source Testing Code • MOE Procedure A-1-1

  7. Source Testing (PM) • sampling train

  8. Source Testing (PM)

  9. Process of Sampling • define the problem • understand the process • visit the site • preliminary test • source sampling • analysis, result

  10. Process of Sampling • define the problem • what to sample? • why? • understand the process • visit the site • preliminary test • source sampling • analysis, result

  11. Process of Sampling • define the problem • understand the process • feed rate, production rate, APC • T. RH, estimate of PM conc., loading, gas composition • visit the site • preliminary test • source sampling • analysis, result

  12. Process of Sampling • define the problem • understand the process • visit the site • accessibility, port location • services (power, water, lab.) • preliminary test • source sampling • analysis, result

  13. Process of Sampling • define the problem • understand the process • visit the site • preliminary test • gas velocity, temperature • gas composition, moisture content • source sampling • analysis, result

  14. Process of Sampling • define the problem • understand the process • visit the site • preliminary test • source sampling • do sampling • lab analysis • check isokineticity • analysis, result

  15. Process of Sampling • define the problem • understand the process • visit the site • preliminary test • source sampling • analysis, result • calculate ER • report

  16. 3. Visit Site • port location • 8 dia. downstream, 2 dia. upstream of disturbance • probe location • 2 perpendicular traverses • divide cross section into equal areas • sample at “centre” of area • different charts for rectangular ducts

  17. Probe Location

  18. Probe Location

  19. determine port height • determine number and location of sampling points

  20. 5. Source Sampling

  21. Problem • calculate ERp , given: Us(avg) = 40 ft/s Vm(ref) = 1.40 m3 Mp = 17,200 mg Ts(avg) = 386 K Ww = 56.6 g Ps = 101.5 kPa stack dia. = 7.0 ft

  22. check if sampling was isokinetic

  23. Source Testing
