EI 期末專題報告

1. EI期末專題報告 航太產業單據交換與BizTalk範例實作 指導老師：張瑞芬教授、何佩勳學長 組員：林向原 u860805 林敦睦 u870856 李宗翰 u860809

2. XML Transaction With BizTalk GEAE/ERP AIDC/ERP Boeing/ERP DSC/VPRO ERP AIDC iHub Suppliers ebChain/EcOs Exostar RFQ RFQ Quote Quote P.O. P.O.A. S.O.N. S.N. R.N. Invoice N. 引用老師的投影片

3. How to make a transaction with BizTalk? BizTalk Server 波音的XML 普揚的XML 波音的DTD 普揚的DTD Internet Intranet BizTalk Server ERP

5. RosettaNet與Oagis的文件解析 RosettaNet • 3A4PurchaseOrderAcceptanceMessageGuideline • 3A4PurchaseOrderCancellationMessageGuideline • 3A4PurchaseOrderChangeMessageGuideline • 3A4PurchaseOrderRequestMessageGuideline OAGIS • 003_process_po_007.xml • 004_acknowledge_po_007.xml • 005_load_receivable_006.xml • 150_get_rfq_003.xml • 151_show_rfq_003.xml • 159_qet_quote_003.xml • 160_show_quote_003.xml • 161_show_shipment_004.xml

6. Cluster 3: Order Management Segment 3A: Quote and Order Entry •PIP 3A1: Request Quote •PIP 3A2: Request Price and Availability •PIP 3A3: Transfer Shopping Cart •PIP 3A4: Manage Purchase Order •PIP 3A5: Query Order Status •PIP 3A6: Distribute Order Status •PIP 3A7: Notify of Purchase Order Acceptance Segment 3B: Transportation and Distribution •PIP 3B1: Distribute Transportation Projection •PIP 3B2: Notify of Advance Shipment •PIP 3B3: Distribute Shipment Status •PIP 3B4: Query Shipment Status •PIP 3B5: Change Shipment •PIP 3B6: Notify of Shipper's Manifest •PIP 3B7: Create Delivery Appointment •PIP 3B8: Notify of Transportation Claim •PIP 3B9: Notify of Delivery Exception •PIP 3B10: Notify of Cancel Delivery Appointment Segment 3C: Returns and Finance •PIP 3C1: Return Product •PIP 3C2: Obtain Financing Approval •PIP 3C3: Notify of Invoice •PIP 3C4: Notify of Invoice Reject •PIP 3C5: Notify of Billing Statement •PIP 3C6: Notify of Remittance Advice Segment 3D: Product Configuration •PIP 3D1: Distribute Risk Analysis •PIP 3D2: Notify of Solution Configuration •PIP 3D3: Notify of Manufacturing Specification •PIP 3D4: Request Build Authorization •PIP 3D5: Distribute Material Status •PIP 3D6: Distribute Build Readiness •PIP 3D7: Request Customer Waiver •PIP 3D8: Distribute Work in Process •PIP 3D9: Query Work in Process •PIP 3D10: Distribute Test Result •PIP 3D11: Request Product Acceptance •PIP 3D12: Request Engineering Change •PIP 3D13: Distribute Engineering Change Response •PIP 3D14: Request Engineering Change Approval •PIP 3D15: Notify of Engineering Change Order •PIP 3D16: Notify of Engineering Change Implementation Plan

7. PIP 3A4 Manage Purchase Order

9. 進度報告 • 4/30-5/6    study XML • 5/7-5/13    實做 XML mapping 範例 • 5/14-5/20   study RosettaNet ch3 並與普揚DTD 對照 • 5/21-5/28 learning BizTalk • 5/29-6/2 RosettaNet及OAGIS文件解析 • 6/3-6/10 Biztalk 實做

10. BizTalk Introduction • BizTalk Editor • 用來定義商業文件格式 • BizTalk Mapper • XSLT Transformation Component • 豐富的資料對應轉換工具 • BizTalk Messaging Desk • 提供分析人員一個商業後台管理機制 • 作商業交易的定義 • BizTalk Administration Tool • Manages queues • Configures transport integration

11. BizTalk Introduction – Editor • XML/Non-XML • EDI-X12 • EDI- UN/EDIFACT • Flat • Document templates • Import Modules • WF-XML • DTD • XDR Schema

12. BizTalk Introduction – Mapper • XSLT Generator Component • Create Maps • Published open format • Schema Driven • Functoids • Canned • User-Configurable • Script • Rich Mapping Zone

13. BizTalk Introduction – Administration Tool • WMI provider for admin settings • MMC snap in • Receive functions • Monitor queues • Service management

14. 結論 • BizTalK功能齊全但尚在發展中 • BizTalk的Orchestration較重於內部流程與的規劃因此在此專題中並未使用到 • BizTalk Messaging Service需要繁瑣的設定 • BizTalk Server 2000 可以提供電子商務B2B的解決方案 • 可使用資源不足，造成研究上的困擾

15. DEMO 利用 Biztalk 轉換 XML
