  1. Colors

  2. Color Systems • In computer graphics, we use RGB colors. But… • Can it represent all colors? • Is it linear? For example, • (1.0, 1.0, 1.0) is white • (1.0, 0.0, 0.0) is red • Is (1.0, 0.5, 0.5) half white and half red? • Does the color (r, g, b)*0.5 look like the color (r, g, b) in half intensity?

  3. What is a Color, After All? • We may define a color by its wavelength. • However, most colors have energy spread in every wavelength. Figure 5.1 in Pharr’s book: • Fluorescent light • Lemon skin

  4. What is a Color (II) • What is more interesting is that different energy distributions may be perceived as the same color!

  5. Additive vs. Subtractive Color

  6. The CIE Color Matching

  7. CIE XYZ Space • To get rid of the negative values, CIE defined 3 new hypothetical light sources .

  8. Color and Spectrum in PBRT • XYZ color: • Spectrum class in PBRT: Class COREDLL spectrum { public: private: float c[COLOR_SAMPLES]; }

  9. Linearity • Unfortunately equal steps in the XYZ space does not produce perceptually equal steps in the color.

  10. CIE L*u*v Space • Designed to be perceptually uniform.

  11. Other Color Space • HSV: hue, saturation, value. • HSL: hue, saturation, lightness. From: http://en.wikipedia.org/wiki/File:Hsl-hsv_models.svg

  12. Gamma Correction • For a monitor, the light intensity follows an exponential curve such as:

  13. How to Determine the Gamma? • How to detect the gamma of your monitor? Compare it with dithering: (Hint: how do you produce a square with 50% gray on the screen?)

  14. Basic Radiometry

  15. What Do You Mean By Light Intensity? • What does I in rendering equation mean? • The power of light source • E.g., wattage of a light bulb. • Flux (Φ) measured in watts (W) or joules/second • Does it change with distance? • Another radiometric quantity needed here.

  16. Radiance and Irradiance • See Pharr’s 5.4.1 (2nd Ed.) • Irradiance E • Area density of flux. • Measured in W/m2 • E = Φ / 4πr2 From Watt’s p.278

  17. Radiance and Irradiance • Intensity and solid angle • Radiance L • Light energy density • Measured in W/(sr-m2) • Remains constant along a ray From Watt’s p.278

  18. Analogy to River Flow • How do you compare the water flow of two rivers? • How do you measure the intake of a irrigation canal attached to the river?

  19. Exercise (Sanity Check) • Q1: What do you mean when you say object A is “brighter” than object B? Does it refer to intensity, radiance, or irradiance?

  20. High Dynamic Range (HDR) Images

  21. What is Dynamic Range? • What does the brightness (or darkness) mean in a photograph?

  22. An Example

  23. Recovering High Dynamic Range Radiance Maps from Photographs • By Paul Debevec (SIGGRAPH 1997) • Step 1: Recovering the film response curve. • Step 2: Recovering the radiance map given the response curve.

  24. Recovering the Response Curve

  25. File Format • RGBE (.hdr) format that is used in Greg Ward’s RADIANCE. • OpenEXR: also used in Pharr’s PBRT • For more information, see: • http://ict.debevec.org/~debevec/Research/HDR/ • http://en.wikipedia.org/wiki/High-dynamic-range_imaging

  26. Tone Mapping • Converting HDR intensity to displayable range • In general: [0, infinity) to [0, 1) • Global – spatially uniform • Local – spatially varying in each pixel according to the local features of the image.

  27. Creative CommonsAttribution-Share Alike 3.0 Unported license. Source: http://en.wikipedia.org/wiki/File:Dundus_Square.jpg

  28. Creative CommonsAttribution-Share Alike 3.0 Unported license. Source: http://upload.wikimedia.org/wikipedia/commons/b/b3/HDRI-Example.jpg

  29. Tone Mapping In Digital Photography Creative CommonsAttribution 2.0 Generic license. Source: http://en.wikipedia.org/wiki/File:Dundus_Square.jpg
