  1. Group Structure

  2. Tecate Strengths • Product Breadth. All Capacitors. • Design support and Inventory Pipeline. • Financially Strong. 40 years. • Product/Market Knowledge. • Customer Service. Flexibility!! • Competitive pricing across products.

  3. Ceramic Capacitor Types • SURFACE MOUNT MONOLYTHIC • 0201 – 3640 Sizes • Tight tolerance for Telecom Applications • High Voltage to 5KV. X1/Y2 & X2/Y3 Safety • Flexible Polymer terminations • MONOLYTHIC RADIAL LEADED- NPO, X7R,Z5U • MONOLYTHIC AXIAL LEADED- NPO, X7R, Z5U • RADIAL LEADED DISK – NPO, N75, N150, N330, N1500, Y5V, Y5P, Z5U, Z5V

  4. Film Capacitor Types • SMT STACKED METALLIZED PET/PEN • SMT STACKED METALLIZED PPS. • POLYESTER: FILM AND FOIL. • POLYESTER: METALLIZED BOX FILM. • POLYPROPYLENE: FILM AND FOIL. • POLYPROPYLENE: METALLIZED FILM.

  5. Aluminum Electrolytic Types • MINIATURE RADIALS: (5-7 mm)- Gen. Purpose, Non-Polar, Low Leakage, Extended Temperature. • STANDARD GRADE: Gen. Purpose, Low Profile, Low Leakage, Extended Temperature. • AXIAL: General Purpose, Extended Temperature, Low Leakage. • NON-POLAR: Audio, Industrial, Extended Range. • SMT: Gen. Purpose, Extended Temperature, Low Impedance, Very Low Impedance, Non-Polar, 5000 Hr.

  6. Tantalum Capacitor Types • EPOXY DIPPED • SMT: MOLDED A TO E CASE • STANDARD • LOW ESR

  7. Maxwell Ultracapacitors • Tecate Group is the distributor for the Americas. • 4 to 2600 Farad Electric Double Layer Capacitors. • Hermetically sealed and UL recognized. • Value added Custom configurations available.

  8. Cells • Cylindrical radial leaded devices. • 4 to 100 Farad with other values on request. • 2.5 and 2.7 V series. • Drop in replacement to Panasonic, Ness and others.

  9. Modules • Maxwell Inside. PC5 and PC 10 cells. • Active or Passive balancing • 5.0 to 25 V • U.S. design and prototyping, Asian production. • Custom circuits and packaging available.

  10. Manufacturing • Two manufacturing facilities with more than 500 employees allow us the flexibility to offer fast turnaround as well as cost effective large production runs. • Tecate Asia Co., LTD. • Located in Shenzhen, China. Established in 2000 • Tecate Electronics, Inc. • Located in Dongguan, China. Established in 2000

  11. Custom Molded and Metal Parts • Grills • Port Tubes • Speaker Enclosures • Trim Rings • Terminal Cups • Terminals • Low tooling and production cost

  12. Wire Harnesses • Manufacturing capability combining both automated and manual assembly for maximum production output. • Production featuring UL approved wire, special connectors, specialized wiring, and simple-to-complex configurations as needed. • Wide range of available wire colors, sizes, in-line components and terminations. • Efficient component supplier network for fast production of both sample and production units.

  13. Design • Custom Designs • Design Modifications • Joint Development • CAD - SolidWorks, ProE , AutoCAD

  14. Packaging / Labeling • Finished product with your artwork • Wide range of packaging options • Distribution services • Stocking programs • Delivery of your product to your customer, installer, or retailer

  15. Tecate Quality • ISO certified factories. 9001/9002 • Quality Lab in San Diego and resources of manufacturing partners. • 24 hour response to issues for initial disposition.

  16. Inventory Management Services • Warehousing and Material Management. • N. America & Asia • Schedule Share, Demand Pull, Consignment, EDI. • Third Party warehousing. • Customer specific programs tailored to individual needs.

  17. Why Tecate? • Product Breadth. Capacitors and Assemblies • Flexibility- Schedules, Inventory & Terms • Options!! • MyTecate = Centralized tracking of WW business. • Competitive pricing. High Quality. • Global support. OEM/CEM
