SFDJA DJ Lighting Tips and Tricks Sam Session 6 Presented by: Alex “DeeJayGalaga” Lopez
Basics of Lighting • Trussing Systems • Washes • DMX • Micro Applications • Tips and Tricks Agenda
Basics of Lighting Agenda
Basics of Lighting Effects Lighting Intelligent Lights Strobes Washes
Trussing Systems Agenda
Basics of Trussing Tree Stand with IBar Tree Stand All in Ones Arch Stand Triangle Truss Crank Stands Clamps
Washes Agenda
Columns and Pillars Walls and Large Areas DJ Washes Application
DMX Agenda
DMX512 (Digital MultipleX) is a standard for digital communication networks. • It was originally intended as a standardized method for controlling light dimmers, which, prior to DMX512, had employed various incompatible proprietary protocols. What is DMX?
This is where most of the confusion starts. • Many intelligent scanning lights use 4 channels; 1 for the gobo wheel, 1 for the color wheel, 1 for left to right mirror movement and 1 for up and down mirror movement. • So why does the second fixture need to be addressed 13 instead of 5? I can't tell you why they do it, but almost all manufacturers make DMX intelligent lights that OCCUPY more channels than they USE. What is DMX Addressing?
Assumptions: 8 Channel Light (Gobo) , with 10 Channel Light (Led Bar), with 3 Channel Light (Small MoonFlower) Address 1 Gobo: Math: Channel: Address = 0 + 1 = 1 DMX Math
Assumptions: 8 Channel Light (Gobo) , with 10 Channel Light (Led Bar), with 3 Channel Light (Small MoonFlower) Address 1 Gobo: Math: Channel: Address = 0 + 1 = 1 Gobo Address = 1 DMX Math
Assumptions: 8 Channel Light (Gobo) , with 10 Channel Light (Led Bar), with 3 Channel Light (Small MoonFlower) Gobo Fixture Address is 1 Address 2 Led Bar: Math: Channel : Address = 1 (In Use Gobo) + 8 (Available Gobos Channel) First Available Channel: 9 LED Bar Fixture Address is 9 DMX Math
Assumptions: 8 Channel Light (Gobo) , with 10 Channel Light (Led Bar), with 3 Channel Light (Small MoonFlower) Gobo Address = 1 Led Bar Address = 9 Address 3: Moonflower: Math: Channel : Address 1 + 8 + 10 = First Available: 20 DMX Math
Difference Between DMX and XLR Cables? • Reliability • Difference in Impedance and Shielding DMX Cables and Tips and Tricks
Difference Between Hardware Controllers vs. PC Controllers: • HW Controller Much more difficult to program • HW can be more Reliable no 2nd PC Needed Standard DMX Controllers vs. PC Based Controllers
Micro Applications Agenda
Tips and Tricks Agenda
Tips and Tricks • Mobile Applications Trees Have been Great • Don’t Go Crazy with DMX, Micros are a Fantastic Alternative • If you DMX, Consider the PC Option the HW Option can be a Pita Agenda
Tips and Tricks • Do not Skimp on DMX vs. Standard XLR – DMX Cables will help eliminate unreliability. • All in One Sets for Washes are fantastic and pretty cost effective. • Train for free in the Chauvet DJ Academy Agenda
Questions? Agenda
