  1. Chapter 11Gases 11.1 Gases & Pressure

  2. Defining Gas Pressure • How are number of particles and pressure related? • Pressure –force per unit area that particles exert on walls of their container • Gas particles collide with walls = greater pressure • Pressure is directly proportional to number of particles. Number of Particles Increases Pressure Increases

  3. Temperature & Pressure • Higher temperature results in more kinetic energy! • IF the volume of container remains constant and IF the amount of gas remains constant: the pressure of a gas increases in direct proportion to the Kelvin temperature. (Kelvin Temp = Celsius Temp + 273) • Volume of a gas at constant pressure is directly proportional to Kelvin temp. Pressure of Gas Increases Kelvin Temperature Increases

  4. Temperature Conversions • Kelvin & Celsius Tk = (Tc + 273) Tc = (Tk - 273) • Fahrenheit & Celsius Tf = (9/5 Tc) + 32 Tc = (Tf - 32) 5/9

  5. Devices to Measure Pressure • Barometer: an instrument that measures pressure exerted by the atmosphere. Invented in 1600’s by an Italian scientist, Evangelista Torricelli • Height of column of mercury shows the atmospheric pressure. (atm)

  6. Atmospheric Pressure • We live at the bottom of an ocean of air; highest pressure occurs at the lowest altitudes! • Standard Atmosphere is pressure that supports a 760 mm column of mercury. • 1.00 atm = 760 mm Hg

  7. Devices to Measure Pressure • Pressure Gauge: instrument used to measure pressure inside a tire or oxygen tank. Tire Pressure Blood Pressure

  8. Absolute Pressure • When measuring tire pressure; you measure pressure ABOVE atmosphere pressure. Recommended pressures for tires are gauge pressures. • Absolute pressure – the TOTAL pressure of all gases including the atmosphere. Q: How would you figure it for an inflated tire? A: Add barometric pressure to the gauge pressure.

  9. Pressure Units • SI unit for measuring pressure is the pascal (pa) after the French physicist Blaise Pascal (1600s) • A kilopascal (kPa) is 1000 pascals and is more commonly used.

  10. Sample Calculations • Express 1.56 atm in kPa. • Convert 801 mm Hg to Pa. • How many psi are equivalent to 95.6 kPa?

  11. Answers 101.3 kPa X • 1.56 atm • 801 mm Hg • 95.6 kPa = 158 kPa 1.00 atm 101300 Pa X = 107000 Pa 760 mm Hg 14.7 psi X = 13.9 psi 101.3 kPa

  12. Dalton’s Law of Partial Pressures • Partial Pressure The pressure exerted by each gas in a mixture The total pressure of a mixture of gases is equal to the sum of the partial pressures of the component gases Dalton’s Law: PT = P1 + P2 + P3 + …

  13. Practice • Calculate the partial pressure in mm Hg exerted by the four main gases in air at 760 mm Hg: nitrogen, oxygen, argon and carbon dioxide. Their abundance by volume is 78.08%, 20.95%, 0.934% and 0.035%, respectively. N2= 593.4 mm Hg O2= 159.2 mm Hg Ar = 7.10 mm Hg CO2= 0.27 mm Hg

  14. Gases Collected by Water Displacement • Gases produced in the lab are often collected by the displacement of water in a collection bottle • Water vapor will be present in the collected gas, and it exerts a pressure • Water vapor pressure = PH20 • Water vapor pressure increases with temperature (Appendix A, Table-8) • Pressure of the dry gas P atm = P gas + P H20 so… P gas = P atm – P H2O

  15. Practice • A student has stored 100.0 mL of neon gas over water on a day when the temperature if 27.0 °C. If the barometer in the room reads 743.3 mm Hg, what is the pressure of the neon gas in its container? P atm = P Ne+ P H2O P Ne= P atm – P H2O P Ne= 743.3 mm Hg – 26.7 mm Hg =716.6 mm Hg

  16. Chapter 11Gases 11.2 The Gas Laws

  17. Pressure & Volume • In the 1600s, Robert Boyle did many experiments involving gases. • He did these experiments at constant temperature. if pressure increases, volume decreases if pressure decreases, volume increases Pressure & Volume are Inversely Proportional!

  18. Boyle’s Law Graph

  19. Boyle’s Law V1P1=V2P2 Where: V1 = initial volume P1 = initial pressure V2 = final volume P2 = final pressure

  20. Kinetic Explanation of Boyle’s Law • As volume is reduced, number of particles and temperature remains constant but number of collisions with the walls of the container increases. • There is a smaller area of space for the same number of particles to move around, so pressure increases.

  21. Practice • If you have 5.5 L of gas at a pressure of 1.6 atm, and the pressure changes to 1.2 atm, what is your new volume? V1P1 = V2P2 (5.5 L) x (1.6 atm) = (x L) x (1.2 atm) x = 7.3 L

  22. Temperature & Volume • Jacques Charles did experiments concerning gases held at constant pressure, while varying temperature. As Kelvin temperature increases, volume increases. As Kelvin temperature decreases, volume decreases. Temperature & Volume are Directly Proportional!

  23. Charles’s Law Graph

  24. Charles’s Law V1 V2 T1 T2 Where: V1 = initial volume T1 = initial temperature V2 = final volume T2 = final temperature =

  25. Kinetic Explanation of Charles’s Law • When a gas is heated, its temperature increases, which means the kinetic energy of the particles has increased. • Then the particles begin to move faster, which causes its volume to increase. • The reverse occurs as the temperature begins to fall.

  26. Practice • 3.0 L of Helium gas is in a balloon at 22 C and a pressure of 760 mm Hg. If the temperature rises to 31 C and the pressure remains constant, what will the new volume be? (remember to convert any temperatures to KELVIN!!!) V1 V2 T1 T2 3.0 L V2 (273 + 22C) (273 + 31C ) V2 = (3.0 L x 304 K) / 295 K V2 = 3.1 L = =

  27. Pressure & Temperature • From the prior relationships of volume & pressure, and temperature & volume, it could be concluded that a relationship exists between pressure & temperature. For a given mass of a dry gas, if the volume is constant, the pressure is directly proportional to the Kelvin temperature Pressure & Temperature are Directly Proportional!

  28. Gay-Lussac’s Law Graph

  29. Gay-Lussac’s Law P1 P2 T1 T2 Where: P1 = initial pressure T1 = initial temperature P2 = final pressure T2 = final temperature =

  30. Practice • At 27 C, Helium gas is in a balloon at pressure of 760 mm Hg. If the temperature rises to 31 C, what will the new pressure be? (remember to convert any temperatures to KELVIN!!!) P1 P2 T1 T2 760 mm Hg P2 (273 + 27C) (273 + 31C ) P2 = (760 mm Hg x 304 K) / 300 K P2 = 770 mm Hg = =

  31. Combined Gas Law • All 3 Gas Laws require one variable to be held constant. • How can we solve a problem when all 3 variables; volume, pressure & temperature change? • Since 2 out of the 3 laws always have a variable in common, there should be a way to relate these laws into one formula. • This new formula is called the Combined Gas Law.

  32. Combined Gas Law Gay-Lussac’s Law P1 V1 = P2 V2 T1 T2 Where: P1, V1 & T1 are initial values P2, V2 & T2 are final values *0C & 1 atm = Standard Temperature & Pressure, or STP Boyle’s Law Charles’s Law

  33. Practice • 154 mL of Carbon Dioxide gas is at a pressure of 121 kPa and a temperature of 117C. What volume would this gas occupy at STP? (Remember to convert your temps to Kelvin!!!) 1 atm = 101.3 kPa P1V1/ T1 = P2V2/ T2 (154 mL)(121 kPa) = (101.3 kPa)(V2) (117C + 273) (0C + 273) V2 = (154 mL)(121 kPa)(273 K) (390 K)(101.3 kPa) V2 = 129 mL

  34. Chapter 11Gases 11.3 Gas Volumes & the Ideal Gas Law

  35. The Law of Combining Gas Volumes • If one volume of water, H2O, is decomposed, one volume of oxygen will be formed and 2 volumes of hydrogen will be formed. • How can 3 volumes be formed from only 1 initial volume? 1 L H2O 1 L O2 1 L H2 1 L H2 + +

  36. The Law of Combining Gas Volumes The law of combining volumes states that in chemical reactions involving gases, the ratio of the gas volumes is a small whole number. • All of the gases are at the same temperature & pressure, each of the identical flasks contains the same number of molecules. Notice how the combining ratio: • 2 volumes H2 : 1 volume O2 : 2 volumes H2O leads to a result in which all the atoms present initially are accounted for in the product.

  37. The Law of Combining Gas Volumes • Avogadro was the first to study this and concluded a water molecule is composed of particles. • We now know that a water molecule is composed of 2 hydrogen atoms & 1 oxygen atom. When a molecule of water breaks down, it breaks down according to the ratio of particles that compose it; 2 volumes of H2 & 1 volume of O2 from 1 volume of H2O.

  38. The Law of Combining Gas Volumes My principle states that equal volumes of gases at the same temp & pressure contain equal numbers of particles. • He reasoned that the volume of a gas depends on the number of gas particles, provided the temperature & pressure are constant.

  39. The Law of Combining Gas Volumes • Under the same conditions of temperature and pressure, the volumes of reacting gases and their gaseous products are expressed in ratios of small whole numbers 2 L H2 + 1 L O2 → 2 L H2O (g) 2 volumes H2 + 1volume O2 → 2 volumes H2O (g) 1 volume H2 + 1 volume Cl2 → 2 volumes HCl 1 volume HCl + 1 volume NH3 → NH4Cl (s)

  40. Avogadro’s Law • For a gas at constant temperature and pressure, the volume is directly proportional to the number of moles of gas (at low pressures). V = an a = proportionality constant V = volume of the gas n = number of moles of gas

  41. Standard Molar Volume Equal volumes of all gases at the same temperature and pressure contain the same number of molecules. - Amedeo Avogadro

  42. Standard Molar Volume

  43. Practice • You are planning an experiment that requires 0.0580 mol of nitrogen monoxide gas at STP. What volume would you need? 0.0580 mol x 22.4 L = 1.30 L 1 mol

  44. Gas StoichiometryVolume-Volume Calculations • Assume: All products and reactants are at the same temp and pressure • Unless otherwise stated, assume STP • Solve by normal stoichiometric processes • Volume ratios are the same as mole ratios

  45. Volume-Mass and Mass-Volume Calculations • Order of Calculations • You are given a gas volume and asked to find a mass: gas volume A →moles A →moles B → mass B • You are given a mass and asked to find a gas volume: mass A → moles A →moles B →gas volume B

  46. Ideal Gas Law PV = nRT P = pressure in atm V = volume in liters n = moles R = proportionality constant = 0.08206 L∙ atm/ mol·K For units of kPa, L & K: R = 8.31 kPa ∙ L Mol ∙ K T = temperature in Kelvin

  47. Calculate the Value of R • Use all standard values! P = 1 atm V = 22.4 L n = 1 mole T = 273 K • Try substituting different standard pressures to obtain different values of R

  48. Practice • A 2.07 L cylinder contains 2.88 mol of helium gas at 22.0 °C. What is the pressure in atmospheres of the gas in the cylinder? PV = nRT P = nRT V = 2.88 mol x 0.0821 (atm∙L/mol∙K) x 295 K 2.07 L = 33.7 atm

  49. Gas Density so at STP…
