  1. SE571Security in Computing Chap 2: Elementary Cryptography

  2. Chap 2 Examines… Concepts of encryption Cryptanalysis: how encryption systems are “broken” Symmetric (secret key) encryption and the DES and AES algorithms Asymmetric (public key) encryption and the RSA algorithm Key exchange protocols and certificates Digital signatures Cryptographic hash functions SE571 Security in Computing Dr. Ogara

  3. Common Terminologies Cryptography - practice and study of hiding information/using encryption to conceal text Cryptoanalysis - to find some weakness or insecurity in a cryptographic scheme Cryptology - research into and study of encryption and decryption; it includes both cryptography and cryptanalysis SE571 Security in Computing Dr. Ogara

  4. Common Terminologies Decryption – the method of turning cipher text back into plaintext Encryption algorithm – set of rules or procedures that dictates how to encrypt and decrypt data, also called an encryption cipher Encryption – method of transforming data (plaintext) into an unreadable format Plaintext – the format(usually readable) of data before encrypted SE571 Security in Computing Dr. Ogara

  5. Common Terminologies Ciphertext – the scrambled format of data after being encrypted Key – a value used in the encryption process to encrypt and decrypt/ also called cryptovariable SE571 Security in Computing Dr. Ogara

  6. Encryption SE571 Security in Computing Dr. Ogara

  7. Symmetric Encryption SE571 Security in Computing Dr. Ogara Uses one key for both encryption and decryption Receiver and sender share same key (private key) to lock and unlock Also called private key encryption Must securely distribute keys to other parties

  8. Symmetric Encryption SE571 Security in Computing Dr. Ogara • Anyone with key can either encrypt or decrypt (similar to password) • Very fast to encrypt or decrypt • Provides authentication as long as key remains secret • Problem • How do A and B obtain their shared secret key? • Key distribution is e.g. n users communicating in pairs need n*(n-1)/2 keys

  9. Asymmetric Encryption SE571 Security in Computing Dr. Ogara Receiver and sender have two keys – public and private Public key can be sent in an e-mail message or posted in a public directory Public key used to encrypt and private key to decrypt or vise-versa Requires a lot of resources

  10. Asymmetric and Symmetric Encryption SE571 Security in Computing Dr. Ogara

  11. Encryption SE571 Security in Computing Dr. Ogara

  12. Cryptanalysis attempts to do six things… break a single message recognize patterns in encrypted messages, to be able to break subsequent ones by applying a straightforward decryption algorithm infer some meaning without even breaking the encryption, such as noticing an unusual frequency of communication or determining something by whether the communication was short or long SE571 Security in Computing Dr. Ogara

  13. Cryptanalysis attempts to do six things… deduce the key, to break subsequent messages easily find weaknesses in the implementation or environment of use of encryption find general weaknesses in an encryption algorithm, without necessarily having intercepted any messages SE571 Security in Computing Dr. Ogara

  14. Forms of Ciphers • Confusion (substitution) • One letter is exchanged for another • Basis of many cryptographic algorithms used for diplomatic communication through the first half of the twentieth century • Basis for some widely used commercial-grade encryption algorithms • Examples: • Ceasar cipher • One-Time Pad • The Vernam cipher SE571 Security in Computing Dr. Ogara

  15. Forms of Ciphers • Diffusion (Transposition) • Order of the letters is rearranged • Basis for some widely used commercial-grade encryption algorithms • Goal - widely spread the information from the message or the key across the ciphertext (diffusion) • Also known as permutation (rearrangement of symbols of a message) SE571 Security in Computing Dr. Ogara

  16. Ceasar cipher • Romans used a shift cipher called Ceasar cipher • Shift ciphers simply shift characters in an alphabet • Advantages • Easy to memorize and implement • Disadvantage • Pattern is obvious SE571 Security in Computing Dr. Ogara

  17. One-Time Pads • Large, non-repeating set of keys is written on sheets of paper, glued together into a pad • Requires a prearranged chart called Vigenere table (contains 26 letters in each column in some scrambled order) • Receiver needs a pad similar to the sender SE571 Security in Computing Dr. Ogara

  18. One-Time Pads • Example: • Message has 300 characters in length • Keys are 20 characters long • Sender needs 15 pages of keys • Sender writes keys one at a time above the letters of plain text • Sender encipher plain text with Vigenere chart • Receiver uses appropriate number of keys to decipher message SE571 Security in Computing Dr. Ogara

  19. One-Time Pads • Problems • Requires absolute synchronization between sender and receiver • Difficult to store and account for the keys SE571 Security in Computing Dr. Ogara

  20. The Vernam Cipher Developed by Gilbert Vernam for AT&T Is immune to most cryptanalytic attacks Uses long non-repeating sequence of numbers that are combined with the plaintext Used long punched paper tape that fed into a teletype machine Tape contained random numbers that were combined with characters typed into the teletype sequence of random numbers had no repeats, and each tape was used only once SE571 Security in Computing Dr. Ogara

  21. The Vernam Cipher SE571 Security in Computing Dr. Ogara

  22. The Vernam Cipher - Example SE571 Security in Computing Dr. Ogara Plain text - VERNAM CIPHER Ciphertext - tahrspitxmab

  23. Columnar Transposition • Plaintext characters are rearranged into columns • Example: • Plain text - THIS IS A MESSAGE TO SHOW HOW A COLUMNAR TRANSPOSITION WORKS • Ciphertext - tssohoaniwhaasolrstoimghwutpirseeoamrookistwcnasns SE571 Security in Computing Dr. Ogara

  24. Columnar Transposition SE571 Security in Computing Dr. Ogara

  25. Characteristics of Good Ciphers The amount of secrecy needed should determine the amount of labor appropriate for the encryption and decryption The set of keys and the enciphering algorithm should be free from complexity SE571 Security in Computing Dr. Ogara

  26. Characteristics of Good Ciphers The implementation of the process should be as simple as possible Errors in ciphering should not propagate and cause corruption of further information in the message The size of the enciphered text should be no larger than the text of the original message SE571 Security in Computing Dr. Ogara

  27. Properties of Trustworthy Encryption Systems It is based on sound mathematics It has been analyzed by competent experts and found to be sound It has stood the test of time SE571 Security in Computing Dr. Ogara

  28. Stream and Block Ciphers Stream ciphers - encrypt one bit or character or symbol of plaintext into bit or symbol of Ciphertext at a time e.g. diffusion Block ciphers encrypt a group of plaintext symbols as one block e.g. columnar transposition Block ciphers can effectively act as a stream cipher SE571 Security in Computing Dr. Ogara

  29. Stream and Block Ciphers Stream ciphers Block ciphers SE571 Security in Computing Dr. Ogara

  30. Advantages of Stream Ciphers SE571 Security in Computing Dr. Ogara • Speed of transformation - the time to encrypt a symbol depends only on the encryption algorithm itself, not on the time it takes to receive more plaintext • Low error propagation - error in the encryption process affects only a character

  31. Disdvantages of Stream Ciphers SE571 Security in Computing Dr. Ogara • Low diffusion - Each symbol is separately enciphered. Therefore, all the information of that symbol is contained in one symbol of the ciphertext. • Susceptibility to malicious insertions and modifications - Because each symbol is separately enciphered, an active interceptor who has broken the code can splice together pieces of previous messages and transmit a spurious new message that may look authentic.

  32. Advantages of Block Ciphers SE571 Security in Computing Dr. Ogara • High diffusion - Information from the plaintext is diffused into several ciphertext symbols. One ciphertext block may depend on several plaintext letters • Immunity to insertion of symbols - Because blocks of symbols are enciphered, it is impossible to insert a single symbol into one block. The length of the block would then be incorrect, and the decipherment would quickly reveal the insertion

  33. Disdvantages of Block Ciphers SE571 Security in Computing Dr. Ogara • Slowness of encryption - The person or machine using a block cipher must wait until an entire block of plaintext symbols has been received before starting the encryption process • Error propagation - An error will affect the transformation of all other characters in the same block

  34. Three commonly used encryption schemes DES – Data Encryption Standards AES – Advanced Encryption Standards RSA – Rives-Shamir-Adelman Encryption SE571 Security in Computing Dr. Ogara

  35. DES Developed by U.S government for general public (adopted in 1976) Based on data encryption algorithm developed by IBM Combines two fundamental building blocks of encryption – substitution and transposition Uses only standard arithmetic and logical operations on numbers up to 64 bits long SE571 Security in Computing Dr. Ogara

  36. Double and Tripple DES Lack of trust with DES 56-bit key length Development of double encryption for greater secrecy Two keys perform two encryptions thus making it hard to unlock [C=E(k2, E(k1,m))] Unfortunately the assumption is false Three keys adds significant strength [C = E(k3, E(k2, E(k1,m)))] SE571 Security in Computing Dr. Ogara

  37. Double and Tripple DES 1997 researchers using over 3,500 machines in parallel were able to infer a DES key in four months’ work 1998 for approximately $100,000, researchers built a special “DES cracker” machine that could find a DES key in approximately four days Hence need for better and stronger algorithm SE571 Security in Computing Dr. Ogara

  38. AES Algorithm is called Rijndael – named after the two creators (Vincent Rijmen and Joan Daemen) Adopted in 2001 Uses substitution; transposition; and the shift, exclusive OR, and addition operations Keys based on 128, 192 and 256 bits SE571 Security in Computing Dr. Ogara

  39. AES Does it have flaws? How long will it remain sound? Cryptanalysts have not found any flaws yet SE571 Security in Computing Dr. Ogara

  40. Rives-Shamir-Adelman Encryption (RAS) Public key system introduced in 1978 Named after three inventors Uses two keys for encryption and dceryption SE571 Security in Computing Dr. Ogara

  41. Four applications of encryption Hash functions Key exchange Digital signatures Certificates SE571 Security in Computing Dr. Ogara

  42. Hash Functions • Important for integrity • Put a shield or seal around a file by computing a cryptographic function called hash or checksum or message digest of a file • Examples: • MD4, MD5 (Message Digest) – produce 128 bit • SHA/SHS (Secure Algorithm or Standards) – produce 160-bit digest SE571 Security in Computing Dr. Ogara

  43. Key exchange Example: Web browser connecting to shopping website Encrypted session must be established S = sender of protected information R = receiver of protected information Establish assurance that information came from S Public key cryptography can help here SE571 Security in Computing Dr. Ogara

  44. Key exchange Use lockboxes and keys S puts protected information into lockbox that can be opened by S public key S puts lockbox into another one that can be opened by ONLY by R’s private key R uses private key to open outer box and S public key to open inner box (proof it came from S) SE571 Security in Computing Dr. Ogara

  45. Diffie–Hellman key exchange protocol Does not require preshared public keys S and R uses simple arithmetic to exchange a secret They agree on field number n and starting number g Each thinks of a secret number, say, s and r. S sends to R gs and R sends to S gr. Then S computes (gr)s and R computes (gs)r, which are the same, so grs = gsr becomes their shared secret. SE571 Security in Computing Dr. Ogara

  46. Digital Signatures Provide reliable means to ensure the origin of data Cryptographic hash codes are used to support digital signatures Cryptographic hash codes offer a fast, fairly reliable way of determining whether a piece of data has been modified between sender and receiver SE571 Security in Computing Dr. Ogara

  47. Digital Signatures It must be unforgeable It must be authentic It is not alterable It is not reusable SE571 Security in Computing Dr. Ogara

  48. Public Key Encryption Ideally suited to digital signatures If S wishes to send M to R, S uses the authenticity transformation to produce D(M, KS). S then sends D(M, KS) to R. R decodes the message with the public key transformation of S SE571 Security in Computing Dr. Ogara

  49. Cetificates Binds a public key and users’ identity Signed by Certificate of Authority (CA) Example – Two people Edward posts his public key in public but retains private key Diana creates public key and includes it into message with her identity Edward signs (affirms Diana’s public key and identity) by creating has value and then encrypting message and hash value with private key SE571 Security in Computing Dr. Ogara
