  1. 제목이 한 줄인 경우 날짜 KOREN Overview 2007.11.15 Future Infrastructure Team

  2. Network Status Ⅰ Current Testbed Ⅱ Application Projects Remarks Ⅲ Ⅲ

  3. KOREN Overview • KOREN : KOREA Advanced REsearch Network • Non-profit research network • Funded by Goveronment [MIC] • Established in 1995 • NIA participate from 2002 • Support Network Service & R&D Porjects • Currently, 81 R&D Institutions • 9 funded R&D Projects in 2007 • o MIC : Ministry of Information and Communications • o NIA : National Information Society Agency

  4. Network Facilities • 6 Giga PoPs • PoPs : Seoul, Daejeon, Daegu, Pusan, Kwangju, Suwon • 5 Open Test-beds • Seoul (NIA), Daejeon (ICU), Daegu, Pusan, Kwangju • 10G ~ 20Gbps backbone • Seoul – Daejeon: 20G • Daegu – Daejeon - Kwangju - Pusan: 10G • Seoul – Suwon: 10G

  5. BcN KREONET NGIX MSPP MSPP MSPP MSPP MSPP MSPP C7609 C7609 ○ JGNII (Japan) Cheju KOREN Network • Physical Logical International R&E Network Seoul 1G IX CERNET 1G 155M QSS 1G TEIN2 (EU) User 622M 1G GSR 1G 10G Testbed PoP Yongin 10G QoS guaranteed NW 1G x 2 20G (2) QoS guaranteed Testbed Network 1G Daejeon User PoP QSS 1G C7609 10G Daegu QSS (1) Best-Effort R&D Network QoS Center 10G 10G 1G 10G Testbed 10G PoP QSS Gwangju Busan 1G 1G QSS QSS 10G 10G User 10G 10G Testbed 1G

  6. User Forum User Forum User User Organizational Changes • As-Is (~2007) To-Be (2008~) MIC MIC Plan Plan Policy Policy IITA IITA Committee Committee Audit Audit Advisory Advisory Contract Contract KISDI NIA NIA International (APII/TEIN2) International (APII/TEIN2) Administration Administration NOC KT KT NOC Operation Operation KOREN, APII/TEIN2 KOREN NIA will manage both KOREN and International links of APII/TEIN2 in Korea from 2008.

  7. 자재함 자재함 자재함 자재함 자재함 Open Lap Testbed Seoul Suwon 10G Open Testbed (NIA) BcN QoS Measurement, (VoIP), BcN Pilot Service Internetworking 20G DJ Daegu 10G Open Testbed Mobility, Security, Charging, AAA, Service Architecture Open Testbed Application Service Architecture 10G 10G 10G PS KJ Open Testbed u-Mobile, Wibro, WiFi,CDMA, Ad-hoc, Mesh, u-Sensor Open Testbed IPTV test, UCC, FTTH, Motion Deection

  8. KOREN : Future

  9. JP KR CN VN HK PH TH MY SG ID AU CN-KR & JP-KR and TEIN2 North America (via TransPAC2) (via GLORIAD) KOREN/APII KR-JP 10G 10G EU 2.5G(622M) 10G TEIN2 North/ORIENT 10G(2G) 622M+1G KREONET/ GLORIAD KR-CN 622 155 622 CN-KR & JP-KR and TEIN2 (2007.10) 45 622 622 EU 155 3 x 622 45 4 x 155 45 TEIN2 South

  10. Initial Monitoring Service Application Projects (1) • Limitations of memory and processing power  Sensors do not have enough descriptions for service discovery KOREN The Internet Service Directory WHAT IS AVAILABLE? (Service Discovery) 6LoWPAN GW WHO AM I? (Addr Autoconf) Monitoring Service 6LoWPAN GW Movement Service Type B Combining Basic Two Queries Type Based Address Configuration and Service Discovery

  11. Application Projects (2) Testbed Project Performance evaluation . TCP/UDP Data Throughput, Delay, Multi-hop analysis . Mesh management routing Algorithm . TCP PlanetLab Over KOREN . PlanetLab Testing over KOREN Consortium: SNU, HP-USA (Mobile Media System Lab) Testbed Configuration . SNU Mesh – KOREN – Abilene - HP Mesh . SNU PlanetLab node – KOREN – Abilene - HP PlanetLab node

  12. Application Projects (3) Testbed Project WMN based multi-hop, Multimedia transmission technology . HD multimedia data transmission technology on Wireless and wired convergence network Scheduling technology for minimum interference in WSN network Consortium: GIST, SKU, OSU, UIUC Testbed Configuration . WMN with KOREN interconnected Server Routers IEEE802.15.4/Zigbee-based Sensor node Testbed (7X7 Grid Topology) . GIST-KOREN-SKU

  13. Application Projects (4) Welfare Support System for u-Lifecare DataBase Management Analysis Action Pattern (Acceleration + Location Data) IT Village (High-Speed Network) ④ Providing Services (Web) Real-Time Information Monitoring 911 ZigBee Gateway Vaious Sensers (Including Image Sensors for Patients with Severe Dementia) ③Server Transmission (KOREN) Family Nursing Homes Location Detection (Using Ultrasonic Data) Service Server DataBase Management ① Information Sensing Medical Doctor KOREN Data Transmission (Sensor ↔ KOREN) FTTH(100M) Analysis Action Pattern (Using Acceleration Data) ②Information Collection Interface (for Wireless Device) House of Living-Alone Elderly Person APII Gloriad Senior Hospitals

  14. Application Projects (4) Welfare Support System for u-Lifecare

  15. Application Projects (5) < ETRI Kwangju FTTH > <Seoul> QSS120 • FTTH Service System • IPTV (multicast) • VoD • e-Learning • Private TV • etc… Router STB <Y.I> QSS120 KOREN STB <Pusan> <Daegu> <Daejeon> QSS120 QSS120 QSS120 STB STB STB

  16. Remarks • From 2008, NIA will manage both KOREN and APII/TEIN2 in Korea. • Need to collaborate with Asian researchers, and identify international research activities in application areas.

  17. . Thanks Ijkim@nia.or.kr
