  1. MIT App Inventor Lesson 1 – Getting Started with App Inventor

  2. Agenda • What is App Inventor? • Getting Started • Designing User Interfaces (Design) • Creating Blocks (Code) • Emulator (Test) • Handling Events • Buttons (Action) • Components (Behaviour)

  3. What is App Inventor? App Inventor is a visual programming environment used to create mobile applications for Android devices (phones/tablets). Facts • Originally created by Google Labs • Now hosted at MIT • Project is open source

  4. Explore – Setup / Tutorials http://appinventor.mit.edu Click on Explore to learn about App Inventor.

  5. Where do I get the Installer? http://appinventor.mit.edu/learn/setup/setupwindows.html http://appinventor.mit.edu/learn/setup/setupmac.html

  6. AI - Projects Click on Invent to create/modify App Inventor Projects.

  7. App Inventor- Tools AI consists of three (3) tools that work together: • Component Designer Define Graphical User Interface (GUI) and Non-GUI components • Blocks Editor Determine the behaviour (algorithms and data structures) of the components • Android phone or emulator Platform for testing/using apps

  8. App Inventor Development Cycle • Paper / Pencil • Component Designer • Blocks Editor • Blocks Editor • Phone/Emulator

  9. What do I need to get started? • GMail enabled account • Browser (anything but IE) • Install the App Inventor Setup program for your platform (Windows, Mac OS X, Linux) • provides Android emulator • Recent version of Java (v6+) • Internet connectivity optional • Android phone/tablet • device driver for Android device for live testing

  10. Classroom environment Development Steps • Open browser (Firefox or Chrome) appinventor.mit.edu • Start emulator from desktop shortcut • Start Blocks Editor Java application • Connect Blocks Editorto emulator for testing Notes: Emulator takes a few minutes to start. Each code change will be reflected in emulator.

  11. Get Developing - Projects • An App Inventor Project is a collection of components and blocks. • Open website • Log in using your GMAIL account • Available Actions • Import existing project into new project • Create new project • Save/Export project

  12. AI – Projects Page

  13. AI Components / Events Event based programming • Components are visible or non-visible "objects" with defined properties and behaviours. • Set the initial properties of components in the Component Designer

  14. AI Component Designer Palette - Available component types Viewer - "rough" visualization of app Components - actual components in project Properties - initial properties for component

  15. Palette • Grouped by type • Action • select component and drag it to the Viewer • Note: Default name given • click RENAME button in Component section to give it a MEANINGFUL NAME • Change default property values (if desired)

  16. Screens • Properties • Defaults – Comp Designer • BackgroundImage • may need to be resized • Icon • Used on devices only (50x50) • ScreenOrientation • can be fixed or flexible • Scrollable • Title – ALWAYS change • exception is Screen1 • VersionCode - new • VersionName – new • Multiple Screens (later)

  17. Designing Apps • typical phone is 300 x 400 pixels • GUI components • default position is top and left, but can be changed • location can be adjusted • Screen Arrangements (later) • Properties (common) • Text • Width – Fill Parent • Height

  18. Best Practices - Naming • Every component has a name • If component will be used in your algorithm • CHANGE ITS NAME • Naming Conventions • btnName – buttons • txtName – textbox (later) Note: "Name" is decided by the programmer

  19. Behaviour • Represents the logic of your application • Programs consist of 3 types of structures • Sequential operations • Conditional operations (decisions) • Repeated operations Use the Blocks Editor to define the app behaviour.

  20. Component : Button • Buttons are GUI components • Typical Use: Input • Take an Action / React to a User Initiated Event • Example: Reset Score button • Actions would be defined in Blocks Editor using Blocks/Code Reset Score

  21. Button actions Event - when click do • This action occurs once for each button click. • Example: Change screen color

  22. Blocks Editor

  23. Blocks Editor: Built-In • Definition • variables, procedures • Text • String library • Lists • List library • Math • Math operators • Logic • relational operators, conditionals • Control • screens, loops • Colors • color library

  24. Blocks Editor: My Blocks Choose your component • Set the default properties for each component

  25. Dynamically Changing Properties Properties are initially set in Component Designer • Blocks can change the properties of any components in your Project Blocks Editor • Locate the component (Screen1) • Locate the set block and provide a valid value for the property (BackgroundColor in this example)

  26. Hello KittyDemo

  27. Lab 1 - ColourMe ObjectiveCreate an interactive app that changes the colour of the screen on the computer. • Components • Buttons • Screen1 • Algorithms • When "red" button is clicked (Event) change the screen colour to red (Event Handler). • Include buttons for "Green", "Blue" • Initially • The app should have a "white" background when it starts and the "Reset" button will reset the screen • Include a "Quit" button to close the application.

  28. Lab 1 - ColourMe App Inventor Skills • Screens • properties • BackGroundColor • Buttons • properties • Text • Events • WhenClicked

  29. Take it with you !! If students have phones. Three ways to get the app on a phone. • Create a QR code • download to a phone (using developer email) • Download to the computer • save a an Android install file (APK) on your development computer • Download to Connected Phone • install the APK directly on the phone
